Large-eddy simulation of passive scalar with phase relaxation time in isotropic turbulence

Hiromichi Kobayashi1,2,* and Toshiyuki Gotoh2,3

  • 1Department of Physics, Hiyoshi Campus, Keio University, 4-1-1 Hiyoshi, Kohoku-ku, Yokohama 223-8521, Japan
  • 2Research and Education Center for Natural Sciences, Hiyoshi Campus, Keio University, 4-1-1 Hiyoshi, Kohoku-ku, Yokohama 223-8521, Japan
  • 3Department of Engineering, Nagoya Institute of Technology, Nagoya 466-8555, Japan

  • *Contact author: hkobayas@keio.jp
PDF

Phys. Rev. Fluids 11, 064613 – Published 18 June, 2026

DOI: https://doi.org/10.1103/zzrf-bclm

Abstract

Supersaturation in clouds was modeled as a passive scalar with the phase-relaxation time under mean uniform vertical gradient. The theoretical prediction that there exist two −5/3 power-law ranges in the supersaturation variance spectrum was examined using direct numerical simulation (DNS) and large-eddy simulation (LES). Although DNS at a Taylor microscale Reynolds number of 946 suggested the existence of two −5/3 ranges, the results were not conclusive because of the limited extent of the inertial-convective range. To achieve a wider inertial-convective range, LES was employed, and a modified eddy diffusivity model for a passive scalar without a phase-relaxation term was developed to yield a k−5/3-spectrum across a broad range of wave numbers. LES results obtained by varying the phase-relaxation time demonstrated the coexistence of two k−5/3 spectral ranges with different amplitudes. As the phase-relaxation time decreased, the transition between the two ranges shifted toward higher wave numbers, which is consistent with theoretical predictions. Furthermore, the probability density function (PDF) of the band-pass-filtered supersaturation indicated that the PDF tails at small scales became increasingly elongated depending on the ratio of the turbulence timescale to the phase-relaxation time.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (27)

  1. H. Gerber, J. B. Jensen, A. B. Davis, and A. Marshak, Spectral density of cloud liquid water content at high frequencies, J. Atmos. Sci. 58, 497 (2001).
  2. H. Siebert, K. Lehmann, and M. Wendisch, Observations of small-scale turbulence and energy dissipation rates in the cloudy boundary layer, J. Atmos. Sci. 63, 1451 (2006).
  3. H. Siebert, R. A. Shaw, and Z. Warhaft, Small-scale velocity fluctuations and internal intermittency in marine stratocumulus clouds, J. Atmos. Sci. 67, 262 (2010).
  4. H. Siebert, S. Gerashchenko, A. Gylfason, K. Lehmann, L. R. Collins, R. A. Shaw, and Z. Warhaft, Towards understanding the role of turbulence on droplets in clouds: In situ and laboratory measurements, Atmos. Res. 97, 426 (2010).
  5. P. K. Wang, Physics and Dynamics of Clouds and Precipitation (Cambridge University Press, Cambridge, UK, 2013).
  6. I. Saito and T. Gotoh, Turbulence and cloud droplets in cumulus clouds, New J. Phys. 20, 023001 (2018).
  7. T. Gotoh, I. Saito, and T. Watanabe, Spectra of supersaturation and liquid water content in cloud turbulence, Phys. Rev. Fluids 6, 110512 (2021).
  8. A. S. Lanotte, A. Seminara, and F. Toschi, Cloud droplet growth by condensation in homogeneous isotropic turbulence, J. Atmos. Sci. 66, 1685 (2009).
  9. G. Sardina, F. Picano, L. Brandt, and R. Caballero, Continuous growth of droplet size variance due to condensation in turbulent clouds, Phys. Rev. Lett. 115, 184501 (2015).
  10. I. Mazin, The effect of condensation and evaporation on turbulence in clouds, Atmos. Res. 51, 171 (1999).
  11. C. A. Jeffery, Effect of particle inertia on the viscous-convective subrange, Phys. Rev. E 61, 6578 (2000).
  12. C. A. Jeffery, Effect of condensation and evaporation on the viscous-convective subrange, Phys. Fluids 13, 713 (2001).
  13. C. A. Jeffery, Investigating the small scale structure of clouds using the δ correlated closure: Effect of particle inertia, condensation/evaporation and intermittency, Atmos. Res. 59-60, 199 (2001).
  14. T. Gotoh and T. Watanabe, Statistics of transfer fluxes of the kinetic energy and scalar variance, J. Turbul. 6, N33 (2005).
  15. T. Gotoh, D. Fukayama, and T. Nakano, Velocity field statistics in homogeneous steady turbulence obtained using a high-resolution direct numerical simulation, Phys. Fluids 14, 1065 (2002).
  16. T. Watanabe and T. Gotoh, Statistics of a passive scalar in homogeneous turbulence, New J. Phys. 6, 40 (2004).
  17. T. Gotoh, T. Watanabe, and Y. Suzuki, Universality and anisotropy in passive scalar fluctuations in turbulence with uniform mean gradient, J. Turbul. 12, N48 (2011).
  18. R. H. Kraichnan, Eddy viscosity in two and three dimensions, J. Atmos. Sci. 33, 1521 (1976).
  19. Y. Kaneda, Inertial range structure of turbulent velocity and scalar fields in a Lagrangian renormalized approximation, Phys. Fluids 29, 701 (1986).
  20. O. Metais and M. Lesieur, Spectral large-eddy simulations of isotropic and stably-stratified turbulence, J. Fluid Mech. 239, 157 (1992).
  21. C. Siewert, J. Bec, and G. Krstulovic, Statistical steady state in turbulent droplet condensation, J. Fluid Mech. 810, 254 (2017).
  22. H. Siebert, R. A. Shaw, J. Ditas, T. Schmeissner, S. P. Malinowski, E. Bodenschatz, and H. Xu, High-resolution measurement of cloud microphysics and turbulence at a mountaintop station, Atmos. Meas. Tech. 8, 3219 (2015).
  23. J. P. Chollet and M. Lesieur, Parameterization of small scales of three-dimensional isotropic turbulence utilizing spectral closures, J. Atmos. Sci. 38, 2747 (1981).
  24. J. P. Chollet, Two-point closure used for a sub-grid scale model in large eddy simulations, in Turbulent Shear Flows 4, edited by L. J. S. Bradbury et al. (Springer, Berlin, 1985), pp. 62–72.
  25. M. Lesieur and O. Metais, New trends in large-eddy simulations of turbulence, Annu. Rev. Fluid Mech. 28, 45 (1996).
  26. M. Lesieur, O. Metais, and P. Comte, Large Eddy Simulations of Turbulence (Cambridge University Press, Cambridge, 2005).
  27. J. A. Domaradzki, Large eddy simulations of high Reynolds number turbulence based on interscale energy transfer among resolved scales, Phys. Rev. Fluids 6, 044609 (2021).

Outline

Information

Phys. Rev. Fluids 11, 064613– Published 18 June, 2026
  • Received 7 January 2026
  • Revised 22 May 2026
  • Accepted 26 May 2026
