Ambient air pressure controls spray cloud formation
Phys. Rev. Fluids 11, L062301 – Published 4 June, 2026
DOI: https://doi.org/10.1103/ysbc-7qd2
Abstract
We present an experimental study of sprays produced from microfabricated spray nozzles as a function of nozzle geometry, flow rate, and ambient pressure. Our findings reveal that spray cloud formation is driven by friction with the surrounding air, resulting in a conical structure whose spatial extent scales as the square root of time. We identify a critical pressure threshold below which the characteristic fanning out of spray clouds, attributed to the Kelvin-Helmholtz instability, fails to occur.
Physics Subject Headings (PhySH)
Article Text
References (24)
- W. A. Sirignano, Fuel droplet vaporization and spray combustion theory, Prog. Energy Combust. Sci. 9, 291 (1983).
- G. Faeth, Spray combustion phenomena, Symp. (Int.) Combust. 26, 1593 (1996).
- A. H. Lefebvre and V. G. McDonell, Atomization and Sprays (CRC Press, Boca Raton, FL, 2017).
- S. Zaleski, J. Li, and S. Succi, Two-dimensional Navier-Stokes simulation of deformation and breakup of liquid patches, Phys. Rev. Lett. 75, 244 (1995).
- P. Marmottant and E. Villermaux, On spray formation, J. Fluid Mech. 498, 73 (2004).
- M. Gorokhovski and M. Herrmann, Modeling primary atomization, Annu. Rev. Fluid Mech. 40, 343 (2008).
- S. S. Sazhin, G. Feng, and M. Heikal, A model for fuel spray penetration, Fuel 80, 2171 (2001).
- S. Sazhin, Droplets and Sprays (Springer, London, 2014).
- L. Bourouiba, E. Dehandschoewercker, and J. W. Bush, Violent expiratory events: On coughing and sneezing, J. Fluid Mech. 745, 537 (2014).
- G. Faeth, L.-P. Hsiang, and P.-K. Wu, Structure and breakup properties of sprays, Int. J. Multiphase Flow 21, 99 (1995).
- E. Villermaux, Fragmentation, Annu. Rev. Fluid Mech. 39, 419 (2007).
- N. Ashgriz, Handbook of Atomization and Sprays: Theory and Applications (Springer, New York, 2011).
- J. Eggers and E. Villermaux, Physics of liquid jets, Rep. Prog. Phys. 71, 036601 (2008).
- S. P. Lin and R. D. Reitz, Drop and spray formation from a liquid jet, Annu. Rev. Fluid Mech. 30, 85 (1998).
- D. R. Guildenbecher, C. López-Rivera, and P. E. Sojka, Secondary atomization, Exp. Fluids 46, 371 (2009).
- N. Dombrowski and P. C. Hooper, The effect of ambient density on drop formation in sprays, Chem. Eng. Sci. 17, 291 (1962).
- H. B. Squire, Investigation of the instability of a moving liquid film, Br. J. Appl. Phys. 4, 167 (1953).
- S. Kooij, R. Sijs, M. M. Denn, E. Villermaux, and D. Bonn, What determines the drop size in sprays? Phys. Rev. X 8, 031019 (2018).
- C. C. Porco, P. Helfenstein, P. Thomas, A. Ingersoll, J. Wisdom, R. West, G. Neukum, T. Denk, R. Wagner, T. Roatsch, et al., Cassini observes the active south pole of Enceladus, Science 311, 1393 (2006).
- S. Chandrasekhar, Hydrodynamic and Hydromagnetic Stability (Dover, New York, 2013).
- S. Kooij, D. T. A. Jordan, C. J. M. van Rijn, N. M. Ribe, and D. Bonn, What determines the breakup length of a jet? Phys. Rev. Lett. 135, 214001 (2025).
- J. Hoepffner, R. Blumenthal, and S. Zaleski, Self-similar wave produced by local perturbation of the Kelvin-Helmholtz shear-layer instability, Phys. Rev. Lett. 106, 104502 (2011).
- A. Parrenin, S. Kooij, C. J. M. van Rijn, and D. Bonn, Effect of coalescence on the propagation of water droplets from a jet, Phys. Fluids 36, 103323 (2024).
- L. Xu, W. W. Zhang, and S. R. Nagel, Drop splashing on a dry smooth surface, Phys. Rev. Lett. 94, 184505 (2005).
