Downslope granular flow past a single cylindrical obstacle

Haozhe Geng, Wen-Li Chen, Hui Li, and Donglai Gao*

  • *Contact author: donglai.gao@outlook.com
PDF

Phys. Rev. Fluids 11, 063801 – Published 3 June, 2026

DOI: https://doi.org/10.1103/yg2z-p1tg

Abstract

Gravity-driven geophysical flows, such as landslides and avalanches, pose significant hazards due to their instability and destructive potential. A mechanistic understanding of the obstacle-granular interaction processes and their coupled effects on deposition dynamics is crucial for designing engineered barriers. This study investigates the postimpact evolution of downslope granular flow and its subsequent deposition dynamics on horizontal base within a two-dimensional channel configuration. Through laboratory experiments and particle image velocimetry measurements, we identify a “third jump” phenomenon arising from late-stage lateral particle convergence. Furthermore, we demonstrate the complete elimination of the granular vacuum zone behind the obstacle, a phenomenon driven by subcritical basal flow and the low hysteresis of glass beads, which allows particles to “creep” into the void. Our results reveal a fundamental decoupling between localized obstacle-induced disturbances and global deposition dynamics, which remain primarily governed by the initial mass. We provide robust scaling laws for deposit height, run-out distance, and spreading velocity, advancing the predictive framework for geophysical hazard assessment beyond existing unobstructed flow models.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (51)

  1. S. Perkins, Death toll from landslides vastly underestimated, Nature News 8 (2012).
  2. D. Petley, Global patterns of loss of life from landslides, Geology 40, 927 (2012).
  3. A. K. Turner, Social and environmental impacts of landslides, Innov. Infrastruct. Solut. 3, 70 (2018).
  4. R. Delannay, A. Valance, A. Mangeney, O. Roche, and P. Richard, Granular and particle-laden flows: From laboratory experiments to field observations, J. Phys. D: Appl. Phys. 50, 053001 (2017).
  5. W. Sarlin, C. Morize, A. Sauret, and P. Gondret, Collapse dynamics of dry granular columns: From free-fall to quasistatic flow, Phys. Rev. E 104, 064904 (2021).
  6. V. J. Langlois, A. Quiquerez, and P. Allemand, Collapse of a two-dimensional brittle granular column: Implications for understanding dynamic rock fragmentation in a landslide, J. Geophys. Res.: Earth Surf. 120, 1866 (2015).
  7. M. Rauter, The compressible granular collapse in a fluid as a continuum: Validity of a Navier–Stokes model with-rheology, J. Fluid Mech. 915, A87 (2021).
  8. N. Gaudel, S. Kiesgen de Richter, N. Louvet, M. Jenny, and S. Skali-Lami, Granular avalanches down inclined and vibrated planes, Phys. Rev. E 94, 032904 (2016).
  9. H. M. Fritz, W. H. Hager, H.-E. Minor, Lituya Bay case: Rockslide impact and wave run-up, Sci. Tsunami Hazards 19, 3 (2001).
  10. Y. Wu, T. Pähtz, Z. Guo, L. Jing, Z. Duan, and Z. He, Unified flow rule of undeveloped and fully developed dense granular flows down rough inclines, Phys. Rev. Lett. 134, 028201 (2025).
  11. A. C. Santomaso, S. Volpato, and F. Gabrieli, Collapse and runout of granular columns in pendular state, Phys. Fluids 30, 063301 (2018).
  12. O. Pouliquen, Scaling laws in granular flows down rough inclined planes, Phys. Fluids 11, 542 (1999).
  13. B. Andreotti, A. Daerr, and S. Douady, Scaling laws in granular flows down a rough plane, Phys. Fluids 14, 415 (2002).
  14. X. Cui and J. Gray, Gravity-driven granular free-surface flow around a circular cylinder, J. Fluid Mech. 720, 314 (2013).
  15. S. Viroulet, J. Baker, A. Edwards, C. G. Johnson, C. Gjaltema, P. Clavel, and J. Gray, Multiple solutions for granular flow over a smooth two-dimensional bump, J. Fluid Mech. 815, 77 (2017).
  16. M. Farin, A. Mangeney, and O. Roche, Fundamental changes of granular flow dynamics, deposition, and erosion processes at high slope angles: Insights from laboratory experiments, J. Geophys. Res.: Earth Surf. 119, 504 (2014).
  17. G. Lube, H. E. Huppert, R. S. J. Sparks, and A. Freundt, Granular column collapses down rough, inclined channels, J. Fluid Mech. 675, 347 (2011).
  18. T. Man, H. E. Huppert, and S. A. Galindo-Torres, Run-out scaling of granular column collapses on inclined planes, J. Fluid Mech. 1002, A50 (2025).
  19. T.-T. Vo, T. D. Minh, N. H. Nguyen, T.-K. Nguyen, and T. Q. Bui, Scaling behavior of granular columns collapse on erodible-inclined surfaces, Powder Technol. 433, 119274 (2024).
  20. G. Crosta, S. Imposimato, and D. Roddeman, Granular flows on erodible and non erodible inclines, Granular Matter 17, 667 (2015).
  21. R. T. Cerbus, L. Brivady, T. Faug, and H. Kellay, Granular scaling approach to landslide runout, Phys. Rev. Lett. 132, 254101 (2024).
  22. K. J. Hsu, Catastrophic debris streams (sturzstroms) generated by rockfalls, Geol. Soc. Am. Bull. 86, 129 (1975).
  23. X. Cui, J. N. T. Gray, and T. Johannesson, Deflecting dams and the formation of oblique shocks in snow avalanches at Flateyri, Iceland, J. Geophys. Res.: Earth Surf. 112, F4 (2007).
  24. S. Hauksson, M. Pagliardi, M. Barbolini, and T. Jóhannesson, Laboratory measurements of impact forces of supercritical granular flow against mast-like obstacles, Cold Reg. Sci. Technol. 49, 54 (2007).
  25. B. Sovilla, M. Schaer, M. Kern, and P. Bartelt, Impact pressures and flow regimes in dense snow avalanches observed at the Vallée de la Sionne test site, J. Geophys. Res.: Earth Surf. 113, 2006JF000688 (2008).
  26. T. Faug, P. Gauer, K. Lied, and M. Naaim, Overrun length of avalanches overtopping catching dams: Cross-comparison of small-scale laboratory experiments and observations from full-scale avalanches, J. Geophys. Res.: Earth Surf. 113, 2007JF000854 (2008).
  27. J. Gray, Y.-C. Tai, and S. Noelle, Shock waves, dead zones and particle-free regions in rapid granular free-surface flows, J. Fluid Mech. 491, 161 (2003).
  28. S. B. Savage, Gravity flow of cohesionless granular materials in chutes and channels, J. Fluid Mech. 92, 53 (1979).
  29. A. K. Mathews, A. Khan, B. Sharma, S. Kumar, and R. Kumar, A numerical investigation of granular shock waves over a circular cylinder using the discrete element method, J. Fluid Mech. 936, A11 (2022).
  30. J. Benito, Y. Bertho, I. Ippolito, and P. Gondret, Stability of a granular layer on an inclined “fakir plane”, Europhys. Lett. 100, 34004 (2012).
  31. T. H. Luong, J. L. Baker, and I. Einav, Spread-out and slow-down of granular flows through model forests, Granular Matter 22, 15 (2020).
  32. A. Khan, S. Verma, P. Hankare, R. Kumar, and S. Kumar, Shock–shock interactions in granular flows, J. Fluid Mech. 884, R4 (2020).
  33. Y. Jaiswal, A. Khan, R. Kumar, and S. Kumar, Shocked confined-granular flow over obstacles, J. Fluid Mech. 960, A21 (2023).
  34. B. Darbois Texier, Y. Bertho, and P. Gondret, Downslope granular flow through a forest of obstacles, Phys. Rev. Fluids 8, 034303 (2023).
  35. Z. Chen, D. Rickenmann, Y. Zhang, and S. He, Effects of obstacle's curvature on shock dynamics of gravity-driven granular flows impacting a circular cylinder, Eng. Geol. 293, 106343 (2021).
  36. X. Wang, S. Yang, W. Yu, X. Yang, and Q. Liu, Runout and deflection of granular flow past an array of obstacles on a slope, Eur. J. Mech. B Fluids 94, 37 (2022).
  37. Z. Liang, C. E. Choi, Y. Zhao, Y. Jiang, and J. Choo, Revealing the role of forests in the mobility of geophysical flows, Comput. Geotech. 155, 105194 (2023).
  38. H. Geng, W.-L. Chen, H. Li, and D. Gao, Granular collapse on a rough slope, Phys. Rev. Fluids 10, 063801 (2025).
  39. G. Lube, H. E. Huppert, R. S. J. Sparks, and M. A. Hallworth, Axisymmetric collapses of granular columns, J. Fluid Mech. 508, 175 (2004).
  40. I. R. Ionescu, A. Mangeney, F. Bouchut, and O. Roche, Viscoplastic modeling of granular column collapse with pressure-dependent rheology, J. Non-Newtonian Fluid Mech. 219, 1 (2015).
  41. A. Khan, P. Hankare, S. Verma, Y. Jaiswal, R. Kumar, and S. Kumar, Detachment of strong shocks in confined granular flows, J. Fluid Mech. 935, A13 (2022).
  42. X. Cui, M. Harris, M. Howarth, D. Zealey, R. Brown, and J. Shepherd, Granular flow around a cylindrical obstacle in an inclined chute, Phys. Fluids 34, 093308 (2022).
  43. P. Richard, A. Valance, R. Delannay, and P. Boltenhagen, Granular surface flows confined between flat, frictional walls. Part 1. Kinematics, J. Fluid Mech. 940, A30 (2022).
  44. T. Man, Z. Zhang, H. E. Huppert, and S. A. Galindo-Torres, Axisymmetric column collapses of bi-frictional granular mixtures, J. Fluid Mech. 963, A4 (2023).
  45. W. Thielicke and R. Sonntag, Particle image velocimetry for MATLAB: Accuracy and enhanced algorithms in PIVlab, J. Open Res. Softw. 9, 12 (2021).
  46. D. Gollin, W. Brevis, E. T. Bowman, and P. Shepley, Performance of PIV and PTV for granular flow measurements, Granular Matter 19, 42 (2017).
  47. L. Sarno, M. N. Papa, Y. Tai, A. Carravetta, and R. Martino, A reliable PIV approach for measuring velocity profiles of highly sheared granular flows, energy, environmental and structural engineering series (2014).
  48. M. Robbe-Saule, Modélisation Expérimentale de Génération de Tsunami par Effondrement Granulaire, Ph.D. thesis, Université Paris Saclay (COmUE), 2019.
  49. C. Johnson and J. Gray, Granular jets and hydraulic jumps on an inclined plane, J. Fluid Mech. 675, 87 (2011).
  50. C. Tregaskis, C. Johnson, X. Cui, and J. Gray, Subcritical and supercritical granular flow around an obstacle on a rough inclined plane, J. Fluid Mech. 933, A25 (2022).
  51. F. Legros, Can dispersive pressure cause inverse grading in grain flows? J. Sediment. Res. 72, 166 (2002).

Outline

Information

Phys. Rev. Fluids 11, 063801– Published 3 June, 2026
  • Received 26 February 2026
  • Accepted 19 May 2026
