Physical meaning of k in the logarithmic layer for Reynolds-averaged Navier-Stokes models

Xiang I. A. Yang1,*, Ruifeng Hu2, Rahul Deshpande3, Robert Kunz1, and George Huang4

  • 1Mechanical Engineering, Pennsylvania State University, State College, Pennsylvania 16802, USA
  • 2Center for Particle-Laden Turbulence, Key Laboratory of Mechanics on Disaster and Environment in Western China, Ministry of Education, College of Civil Engineering and Mechanics, Lanzhou University, Lanzhou 730000, Gansu, People's Republic of China
  • 3Department of Mechanical Engineering, The University of Melbourne, Parkville Victoria 3010, Australia
  • 4Wright State University, Dayton, Ohio 45435, USA

  • *Contact author: xzy48@psu.edu
PDF

Phys. Rev. Fluids 11, 064606 – Published 8 June, 2026

DOI: https://doi.org/10.1103/wk3c-xrdn

Abstract

Two-equation models introduce auxiliary transport equations to estimate a velocity scale and a length scale, whose combination yields the eddy viscosity. The velocity scale is typically associated with the variable k, often interpreted as the turbulent kinetic energy (TKE). Using high-Reynolds-number data that were not available at the time of model development, we affirm that the modeled k does not, in fact, represent the total TKE. Rather, it exhibits scaling behavior similar to that of the kinetic energy contained in the active motions—those responsible for producing Reynolds shear stress. To separate active and inactive motions, we propose and validate decomposition methods that segregate turbulent motions into active and inactive components across different levels of data availability. The decompositions are shown to obey the expected scalings of active motions. We further derive the energy budgets of the active and inactive components under the attached eddy hypothesis, revealing that the former are governed by the usual balance between production and dissipation, while the latter contains mean convection, viscous diffusion, dissipation, and the energy transferred from active motions. Analysis of the k equation in two-equation models reveals that it admits both the total TKE and the energy in active motions as asymptotic solutions; the fact that two-equation models select the latter arises from the structure of the dissipation equation. Finally, we introduce a transport equation that governs the kinetic energy in the inactive motions in the logarithmic region, providing a path toward reconciling model outputs with physical turbulence quantities.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (53)

  1. H. Choi and P. Moin, Grid-point requirements for large eddy simulation: Chapman's estimates revisited, Phys. Fluids 24, 011702 (2012).
  2. X. I. A. Yang and K. P. Griffin, Grid-point and time-step requirements for direct numerical simulation and large-eddy simulation, Phys. Fluids 33, 015108 (2021).
  3. J.-Q. Li, X. I. A. Yang, and R. F. Kunz, Grid-point and time-step requirements for large-eddy simulation and Reynolds-averaged Navier–Stokes of stratified wakes, Phys. Fluids 34, 115125 (2022).
  4. M. Mani and A. J. Dorgan, A perspective on the state of aerospace computational fluid dynamics technology, Annu. Rev. Fluid Mech. 55, 431 (2023).
  5. P. A. Durbin, Some recent developments in turbulence closure modeling, Annu. Rev. Fluid Mech. 50, 77 (2018).
  6. B. E. Launder and D. B. Spalding, The numerical computation of turbulent flows, Comput. Methods Appl. Mech. Eng. 3, 269 (1974).
  7. D. C. Wilcox, Formulation of the k−ω turbulence model revisited, AIAA J. 46, 2823 (2008).
  8. K.-Y. Chien, Predictions of channel and boundary-layer flows with a low-Reynolds-number turbulence model, AIAA J. 20, 33 (1982).
  9. F. R. Menter, Two-equation eddy-viscosity turbulence models for engineering applications, AIAA J. 32, 1598 (1994).
  10. X. Hu, G. Huang, R. Kunz, and X. I. A. Yang, Data-guided low-Reynolds-number corrections for two-equation models, J. Fluids Eng. 147, 021502 (2025).
  11. Y. Bin, X. Hu, J. Li, S. J. Grauer, and X. I. A. Yang, Constrained re-calibration of two-equation Reynolds-averaged Navier–Stokes models, Theor. Appl. Mech. Lett. 14, 100503 (2024).
  12. D. C. Wilcox, Turbulence Modeling for CFD, 3rd ed. (DCW Industries, La Canada, CA, 2006).
  13. K. Duraisamy, G. Iaccarino, and H. Xiao, Turbulence modeling in the age of data, Annu. Rev. Fluid Mech. 51, 357 (2019).
  14. A. A. Townsend, Equilibrium layers and wall turbulence, J. Fluid Mech. 11, 97 (1961).
  15. A. Townsend, The Structure of Turbulent Shear Flow, 2nd ed. (Cambridge University Press, Cambridge, 1976).
  16. R. L. Panton, Composite asymptotic expansions and scaling wall turbulence, Phil. Trans. R. Soc. A 365, 733 (2007).
  17. R. Deshpande, J. P. Monty, and I. Marusic, Active and inactive components of the streamwise velocity in wall-bounded turbulence, J. Fluid Mech. 914, A5 (2021).
  18. R. Deshpande, R. Vinuesa, J. Klewicki, and I. Marusic, Active and inactive contributions to the wall pressure and wall-shear stress in turbulent boundary layers, J. Fluid Mech. 1003, A24 (2025).
  19. I. Marusic and J. P. Monty, Attached eddy model of wall turbulence, Annu. Rev. Fluid Mech. 51, 49 (2019).
  20. P. Bradshaw, ‘Inactive’ motion and pressure fluctuations in turbulent boundary layers, J. Fluid Mech. 30, 241 (1967).
  21. G. G. Katul, J. D. Albertson, M. B. Parlange, C.-I. Hsieh, P. S. Conklin, J. T. Sigmon, and K. R. Knoerr, The ‘inactive’ eddy motion and the large-scale turbulent pressure fluctuations in the dynamic sublayer, J. Atmos. Sci. 53, 2512 (1996).
  22. W. J. Baars and I. Marusic, Data-driven decomposition of the streamwise turbulence kinetic energy in boundary layers. Part 1. Energy spectra, J. Fluid Mech. 882, A25 (2020).
  23. W. J. Baars and I. Marusic, Data-driven decomposition of the streamwise turbulence kinetic energy in boundary layers. Part 2. Integrated energy and A1, J. Fluid Mech. 882, A26 (2020).
  24. Turbulence Model Benchmarking Working Group, 2D fully-developed channel flow at high Reynolds number validation, Turbulence Modeling Resource (2026), https://tmbwg.github.io/turbmodels/channelflow_val.html.
  25. Y. Bin, G. Huang, and X. I. A. Yang, Data-enabled recalibration of the Spalart-Allmaras model, AIAA J. 61, 4852 (2023).
  26. M. Lee and R. D. Moser, Direct numerical simulation of turbulent channel flow up to Reτ≈5200, J. Fluid Mech. 774, 395 (2015).
  27. M. Hultmark, M. Vallikivi, S. C. C. Bailey, and A. J. Smits, Turbulent pipe flow at extreme Reynolds numbers, Phys. Rev. Lett. 108, 094501 (2012).
  28. I. Marusic, J. Monty, M. Hultmark, and A. Smits, On the logarithmic region in wall turbulence, J. Fluid Mech. 716, R3 (2013).
  29. M. Ono, N. Furuichi, and Y. Tsuji, Reynolds number dependence of turbulent kinetic energy and energy balance of 3-component turbulence intensity in a pipe flow, J. Fluid Mech. 975, A9 (2023).
  30. C. Morsbach, M. Franke, and F. di Mare, Application of a low Reynolds differential Reynolds stress model to a compressor cascade tip-leakage flow, in Differential Reynolds Stress Modeling for Separating Flows in Industrial Aerodynamics, Springer Tracts in Mechanical Engineering, edited by B. Eisfeld (Springer, Cham, 2015), pp. 1–17.
  31. B. Eisfeld, C. Rumsey, and V. Togiti, Verification and validation of a second-moment-closure model, AIAA J. 54, 1524 (2016).
  32. A. V. Johansson and M. Hallbäck, Modelling of rapid pressure—strain in reynolds-stress closures, J. Fluid Mech. 269, 143 (1994).
  33. T. Knopp, N. Reuther, M. Novara, D. Schanz, E. Schülein, A. Schröder, and C. J. Kähler, Modification of the SSG/LRR-Omega model for turbulent boundary layer flows in an adverse pressure gradient, Flow, Turbul. Combust. 111, 409 (2023).
  34. N. Jain, X. L. D. Huang, J. L. Li, X. I. A. Yang, and R. Kunz, An assessment of second moment closure modeling for stratified wakes using direct numerical simulations ensembles, J. Fluids Eng. 145, 091502 (2023).
  35. X. I. A. Yang, I. Marusic, and C. Meneveau, Hierarchical random additive process and logarithmic scaling of generalized high order, two-point correlations in turbulent boundary layer flow, Phys. Rev. Fluids 1, 024402 (2016).
  36. X. I. A. Yang and C. Meneveau, Hierarchical random additive model for wall-bounded flows at high Reynolds numbers, Fluid Dyn. Res. 51, 011405 (2019).
  37. R. Deshpande, J. P. Monty, and I. Marusic, Active and inactive motions in wall turbulence, in Proceedings of the 22nd Australasian Fluid Mechanics Conference (AFMC2020), edited by H. Chanson and R. Brown (The University of Queensland, Brisbane, Australia, 2020).
  38. C. E. Tinney, F. Coiffet, J. Delville, A. M. Hall, P. Jordan, and M. N. Glauser, On spectral linear stochastic estimation, Expt. Fluids 41, 763 (2006).
  39. S. B. Pope, Turbulent Flows (Cambridge University Press, Cambridge, 2000).
  40. M. Cho, Y. Hwang, and H. Choi, Scale interactions and spectral energy transfer in turbulent channel flow, J. Fluid Mech. 854, 474 (2018).
  41. J. D. Woodcock and I. Marusic, The statistical behaviour of attached eddies, Phys. Fluids 27, 015104 (2015).
  42. J. Jiménez, Cascades in wall-bounded turbulence, Annu. Rev. Fluid Mech. 44, 27 (2012).
  43. P. E. Smirnov and F. R. Menter, Sensitization of the SST turbulence model to rotation and curvature by applying the Spalart–Shur correction term, J. Turbomach. 131, 041010 (2009).
  44. P. Spalart, The conjecture of a general law of the wall for classical turbulence models, implying a structural limitation, Flow, Turbul. Combust. 112, 443 (2024).
  45. P. A. Durbin, Separated flow computations with the k-epsilon-v-squared model, AIAA J. 33, 659 (1995).
  46. P. Schlatter, R. Örlü, Q. Li, G. Brethouwer, J. Fransson, A. Johansson, P. Alfredsson, and D. Henningson, Turbulent boundary layers up to Reθ = 2500 studied through simulation and experiment, Phys. Fluids 21, 051702 (2009).
  47. T. Knopp, N. Reuther, M. Novara, D. Schanz, E. Schülein, A. Schröder, and C. Kähler, Experimental analysis of the log law at adverse pressure gradient, J. Fluid Mech. 918, A17 (2021).
  48. K. Joseph, R. Sandberg, T. Knopp, W. Devenport, D. Fritsch, V. Vishwanathan, R. Volino, S. Toxopeus, B. McKeon, and L. Eca, On the physical structure, modelling and computation-based prediction of two-dimensional, smooth-wall turbulent boundary layers subjected to streamwise pressure gradients, J. Turbul. 25, 2392572 (2024).
  49. X. I. Yang, P. E. Chen, W. Zhang, and R. Kunz, Predictive near-wall modelling for turbulent boundary layers with arbitrary pressure gradients, J. Fluid Mech. 993, A1 (2024).
  50. P. R. Spalart, Philosophies and fallacies in turbulence modeling, Prog. Aerosp. Sci. 74, 1 (2015).
  51. X. I. A. Yang, R. Hu, R. Deshpande, R. Kunz, and G. Huang, Data for “the physical meaning of k in the logarithmic layer for Reynolds-averaged Navier-Stokes models”, GitHub repository (2026), https://github.com/xzy48/Data_K2EQ.
  52. R. Hu, X. I. A. Yang, and X. Zheng, Wall-attached and wall-detached eddies in wall-bounded turbulent flows, J. Fluid Mech. 885, A30 (2020).
  53. R. Baidya, J. Philip, N. Hutchins, J. P. Monty, and I. Marusic, Distance-from-the-wall scaling of turbulent motions in wall-bounded flows, Phys. Fluids 29, 020712 (2017).
