Effect of finite extensibility on the hoop-stress instability in viscoelastic Taylor-Couette flow

Pratyush Kumar Mohanty*, P. S. D. Surya Phani Tej*, Gade Sanjana, and V. Shankar†

  • *These authors contributed equally to this work.
  • †Contact author: vshankar@iitk.ac.in
PDF

Phys. Rev. Fluids 11, 083302 – Published 10 August, 2026

DOI: https://doi.org/10.1103/w8zr-bmkx

Abstract

We use the FENE-P constitutive model to revisit the hoop-stress-driven linear instability in viscoelastic Taylor-Couette flow, considering both inertialess and inertial regimes. The FENE-P model is appropriate for dilute polymer solutions, with the finite extensibility of the polymer leading to shear thinning of both viscosity and the first-normal-stress coefficient. Shear thinning weakens elastic effects and is generally expected to stabilize the hoop-stress mode (HSM), as suggested by the Pakdel-McKinley scaling criterion. Our numerical results confirm this expectation for small values of the ratio of the gap width to the radius of the inner cylinder (ε<1). Unexpectedly, for ε>1, finite-extensiblity-induced increase in shear rates at the inner rotating cylinder results in a destabilizing effect on the HSM. We compare our theoretical predictions with relatively recent experimental observations on viscoelastic Taylor-Couette flow for a range of elasticity numbers (E) with ε∈[0.25−0.4]. In this regime, the experimental results for the onset of instability are well predicted both by the Oldroyd-B and FENE-P (with experimentally realistic polymer extensibility parameter values) models, with finite extensibility playing only a secondary role. Our theory predicts that for very dilute solutions with β=0.98, the hoop-stress instability is suppressed for realistic values of extensibility parameters. Overall, we show that the predictions of the FENE-P model will be qualitatively different from those of the Oldroyd-B model both for very low ε"s (suppression of HSM) and for ε>1 (destabilization of HSM). Further, we also show that the FENE-P predictions for the instability onset are in significant disagreement with experiments carried out using highly concentrated polymer solutions, underscoring the need for the use of more realistic rheological models appropriate for such systems.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (80)

  1. S. J. Muller, R. G. Larson, and E. S. Shaqfeh, A purely elastic transition in Taylor-Couette flow, Rheol. Acta 28, 499 (1989).
  2. R. G. Larson, E. S. G. Shaqfeh, and S. J. Muller, A purely elastic instability in Taylor–Couette flow, J. Fluid Mech. 218, 573 (1990).
  3. E. S. G. Shaqfeh, S. J. Muller, and R. G. Larson, The effects of gap width and dilute solution properties on the viscoelastic Taylor-Couette instability, J. Fluid Mech. 235, 285 (1992).
  4. R. Larson, S. Muller, and E. Shaqfeh, The effect of fluid rheology on the elastic Taylor-Couette instability, J. Non-Newtonian Fluid Mech. 51, 195 (1994).
  5. V. Steinberg, New direction and perspectives in elastic instability and turbulence in various viscoelastic flow geometries without inertia, Low Temp. Phys. 48, 492 (2022).
  6. H. A. Castillo Sánchez, M. R. Jovanović, S. Kumar, A. Morozov, V. Shankar, G. Subramanian, and H. J. Wilson, Understanding viscoelastic flow instabilities: Oldroyd-B and beyond, J. Non-Newtonian Fluid Mech. 302, 104742 (2022).
  7. S. S. Datta, A. M. Ardekani, P. E. Arratia, A. N. Beris, I. Bischofberger, G. H. McKinley, J. G. Eggers, J. E. López-Aguilar, S. M. Fielding, A. Frishman, M. D. Graham, J. S. Guasto, S. J. Haward, A. Q. Shen, S. Hormozi, A. Morozov, R. J. Poole, V. Shankar, E. S. G. Shaqfeh, H. Stark, et al., Perspectives on viscoelastic flow instabilities and elastic turbulence, Phys. Rev. Fluids 7, 080701 (2022).
  8. S. J. Muller, Elastically-influenced instabilities in Taylor-Couette and other flows with curved streamlines: A review, Korea Aust. Rheol. J. 20, 117 (2008).
  9. G. H. McKinley, P. Pakdel, and A. Oztekin, Rheological and geometric scaling of purely elastic flow instabilities, J. Non-Newtonian Fluid Mech. 67, 19 (1996).
  10. P. Pakdel and G. H. McKinley, Elastic instability and curved streamlines, Phys. Rev. Lett. 77, 2459 (1996).
  11. M. A. Fardin, T. J. Ober, C. Gay, G. Grégoire, G. H. McKinley, and S. Lerouge, Criterion for purely elastic Taylor-Couette instability in the flows of shear-banding fluids, Europhys. Lett. 96, 44004 (2011).
  12. Y. L. Joo and E. S. G. Shaqfeh, Observations of purely elastic instabilities in the Taylor–Dean flow of a Boger fluid, J. Fluid Mech. 262, 27 (1994).
  13. Y. L. Joo and E. S. G. Shaqfeh, The effects of inertia on the viscoelastic Dean and Taylor–Couette flow instabilities with application to coating flows, Phys. Fluids 4, 2415 (1992).
  14. M. Avgousti and A. N. Beris, Nonaxisymmetric modes in viscoelastic Taylor-Couette flow, J. Non-Newtonian Fluid Mech. 50, 225 (1993).
  15. M. Avgousti and A. N. Beris, Viscoelastic Taylor-Couette flow: Bifurcation analysis in the presence of symmetries, Proc. R. Soc. A 443, 17 (1993).
  16. M. D. Graham, Effect of axial flow on viscoelastic Taylor–Couette instability, J. Fluid Mech. 360, 341 (1998).
  17. E. S. Shaqfeh and B. Khomami, The Oldroyd-B fluid in elastic instabilities, turbulence and particle suspensions, J. Non-Newtonian Fluid Mech. 298, 104672 (2021).
  18. R. Bird, P. Dotson, and N. Johnson, Polymer solution rheology based on a finitely extensible bead—spring chain model, J. Non-Newtonian Fluid Mech. 7, 213 (1980).
  19. M. Rubinstein and R. H. Colby (Oxford University Press, Oxford, Clarendon, 2003).
  20. M. Khalid, A. Badoni, D. Dutta, P. Naidu, G. Subramanian, and V. Shankar, Role of finite extensibility on the centre-mode instability in viscoelastic channel flow, J. Fluid Mech. 1009, A28 (2025).
  21. R. Ghanbari and B. Khomami, The onset of purely elastic and thermo-elastic instabilities in Taylor–Couette flow: Influence of gap ratio and fluid thermal sensitivity, J. Non-Newtonian Fluid Mech. 208-209, 108 (2014).
  22. N. Liu and B. Khomami, Elastically induced turbulence in Taylor–Couette flow: Direct numerical simulation and mechanistic insight, J. Fluid Mech. 737, R4 (2013).
  23. J. Song, Z.-H. Wan, N. Liu, X.-Y. Lu, and B. Khomami, A reverse transition route from inertial to elasticity-dominated turbulence in viscoelastic Taylor–Couette flow, J. Fluid Mech. 927, A10 (2021).
  24. J. Song, N. Liu, X.-Y. Lu, and B. Khomami, Direct numerical simulation of elastic turbulence in the Taylor–Couette flow: transition pathway and mechanistic insight, J. Fluid Mech. 949, A49 (2022).
  25. J. Song, F. Lin, Y. Zhu, Z.-H. Wan, N. Liu, X.-Y. Lu, and B. Khomami, Self-sustaining cycle of purely elastic turbulence, Phys. Rev. Fluids 8, 014602 (2023).
  26. F. Lin, J. Song, Z.-M. Liao, N. Liu, X.-Y. Lu, and B. Khomami, Asymptotic drag reduction states in turbulent Taylor vortex flow of dilute polymeric solutions: Interplay between large-scale structures and polymer chains dynamics, J. Fluid Mech. 1009, A24 (2025).
  27. F. Lin, J. Song, N. Liu, L. Liu, X. Lu, and B. Khomami, Keplerian turbulence in Taylor–Couette flow of dilute polymeric solutions, J. Fluid Mech. 1000, R3 (2024).
  28. N. Liu and B. Khomami, Polymer-induced drag enhancement in turbulent Taylor-Couette flows: Direct numerical simulations and mechanistic insight, Phys. Rev. Lett. 111, 114501 (2013).
  29. J. Song, H. Teng, N. Liu, H. Ding, X.-Y. Lu, and B. Khomami, The correspondence between drag enhancement and vortical structures in turbulent Taylor–Couette flows with polymer additives: A study of curvature dependence, J. Fluid Mech. 881, 602 (2019).
  30. F. Lin, J. Song, N. Liu, Z. Wan, X.-Y. Lu, and B. Khomami, Maximum drag enhancement asymptote in turbulent Taylor–Couette flow of dilute polymeric solutions, J. Non-Newtonian Fluid Mech. 323, 105172 (2024).
  31. A. Groisman and V. Steinberg, Couette-Taylor flow in a dilute polymer solution, Phys. Rev. Lett. 77, 1480 (1996).
  32. A. Groisman and V. Steinberg, Elastic turbulence in curvilinear flows of polymer solutions, New J. Phys. 6, 29 (2004).
  33. V. Steinberg and A. Groisman, Elastic versus inertial instability in Couette-Taylor flow of a polymer solution, Philos. Mag. B 78, 253 (1998).
  34. A. Groisman and V. Steinberg, Solitary vortex pairs in viscoelastic Couette flow, Phys. Rev. Lett. 78, 1460 (1997).
  35. B. M. Baumert and S. J. Muller, Flow visualization of the elastic Taylor-Couette instability in Boger fluids, Rheol. Acta 34, 147 (1995).
  36. B. M. Baumert and S. J. Muller, Flow regimes in model viscoelastic fluids in a circular Couette system with independently rotating cylinders, Phys. Fluids 9, 566 (1997).
  37. B. M. Baumert and S. J. Muller, Axisymmetric and non-axisymmetric elastic and inertio-elastic instabilities in Taylor–Couette flow, J. Non-Newtonian Fluid Mech. 83, 33 (1999).
  38. C. S. Dutcher and S. J. Muller, Effects of weak elasticity on the stability of high Reynolds number co- and counter-rotating Taylor-Couette flows, J. Rheol. 55, 1271 (2011).
  39. C. S. Dutcher and S. J. Muller, Effects of moderate elasticity on the stability of co- and counter-rotating Taylor–Couette flows, J. Rheol. 57, 791 (2013).
  40. T. Boulafentis, T. Lacassagne, N. Cagney, and S. Balabani, Coherent structures of elastoinertial instabilities in Taylor–Couette flows, J. Fluid Mech. 986, A27 (2024).
  41. T. Boulafentis, T. Lacassagne, N. Cagney, and S. Balabani, Experimental insights into elasto-inertial transitions in Taylor–Couette flows, Philos. Trans. R. Soc. A 381, 20220131 (2023).
  42. J. M. White and S. J. Muller, Viscous heating and the stability of Newtonian and viscoelastic Taylor-Couette flows, Phys. Rev. Lett. 84, 5130 (2000).
  43. J. M. White and S. J. Muller, Experimental studies on the effect of viscous heating on the hydrodynamic stability of viscoelastic Taylor–Couette flow, J. Rheol. 47, 1467 (2003).
  44. U. A. Al-Mubaiyedh, R. Sureshkumar, and B. Khomami, Linear stability of viscoelastic Taylor–Couette flow: Influence of fluid rheology and energetics, J. Rheol. 44, 1121 (2000).
  45. C. Schäfer, A. Morozov, and C. Wagner, Geometric scaling of elastic instabilities in the Taylor–Couette geometry: A theoretical, experimental and numerical study, J. Non-Newtonian Fluid Mech. 259, 78 (2018).
  46. O. Crumeyrolle, I. Mutabazi, and M. Grisel, Experimental study of inertioelastic Couette–Taylor instability modes in dilute and semidilute polymer solutions, Phys. Fluids 14, 1681 (2002).
  47. C. G. Feugaing, O. Crumeyrolle, K.-S. Yang, and I. Mutabazi, Destabilization of the Couette–Taylor flow by modulation of the inner cylinder rotation, Eur. J. Mech. B Fluids 44, 82 (2014).
  48. N. Latrache, O. Crumeyrolle, and I. Mutabazi, Transition to turbulence in a flow of a shear-thinning viscoelastic solution in a Taylor-Couette cell, Phys. Rev. E 86, 056305 (2012).
  49. T. Lacassagne, T. Boulafentis, N. Cagney, and S. Balabani, Modulation of elasto-inertial transitions in Taylor–Couette flow by small particles, J. Fluid Mech. 929, R2 (2021).
  50. T. Lacassagne, N. Cagney, and S. Balabani, Shear-thinning mediation of elasto-inertial Taylor–Couette flow, J. Fluid Mech. 915, A91 (2021).
  51. T. Lacassagne, N. Cagney, J. J. J. Gillissen, and S. Balabani, Vortex merging and splitting: A route to elastoinertial turbulence in Taylor-Couette flow, Phys. Rev. Fluids 5, 113303 (2020).
  52. T. Lacassagne, N. Cagney, T. Boulafentis, and S. Balabani, Elasto inertia transitions in Taylor Couette flows, Science Talks 5, 100115 (2023).
  53. Y. Bai, N. Latrache, F. Kelai, O. Crumeyrolle, and I. Mutabazi, Viscoelastic instabilities of Taylor–Couette flows with different rotation regimes, Philos. Trans. R. Soc. A 381, 20220133 (2023).
  54. Y. Bai, O. Crumeyrolle, and I. Mutabazi, Viscoelastic Taylor-Couette instability as analog of the magnetorotational instability, Phys. Rev. E 92, 031001(R) (2015).
  55. Y.-B. Zhang, L. Li, Y. Fan, J. Su, H.-D. Xi, and C. Sun, Experimental evidence for the continuous transition between elastic and elastoinertial turbulence, Proc. Natl. Acad. Sci. USA 122, e2505007122 (2025).
  56. M. Khalid, V. Shankar, and G. Subramanian, Continuous pathway between the elasto-inertial and elastic turbulent states in viscoelastic channel flow, Phys. Rev. Lett. 127, 134502 (2021).
  57. R. V. More, R. Patterson, E. Pashkovski, and G. H. McKinley, Elasto-inertial instability in torsional flows of shear-thinning viscoelastic fluids, J. Fluid Mech. 985, A37 (2024).
  58. D. F. James, Boger fluids, Annu. Rev. Fluid Mech. 41, 129 (2009).
  59. P. Shakeri, M. Jung, and R. Seemann, Scaling purely elastic instability of strongly shear thinning polymer solutions, Phys. Rev. E 105, L052501 (2022).
  60. M. Beneitez, J. Page, and R. R. Kerswell, Polymer diffusive instability leading to elastic turbulence in plane Couette flow, Phys. Rev. Fluids 8, L101901 (2023).
  61. M. Beneitez, S. Mrini, and R. R. Kerswell, Linear instability in planar viscoelastic Taylor–Couette flow with and without explicit polymer diffusion, J. Non-Newtonian Fluid Mech. 345, 105459 (2025).
  62. R. van Buel, C. Schaaf, and H. Stark, Elastic turbulence in two-dimensional Taylor-Couette flows, Europhys. Lett. 124, 14001 (2018).
  63. P. S. D. Surya Phani Tej, P. Kumar Mohanty, and V. Shankar, Hoop stress and polymer diffusive instabilities in viscoelastic Taylor–Couette flow, Proc. R. Soc. A 481, 20250455 (2025).
  64. R. B. Bird, R. C. Armstrong, and O. Hassager, Dynamics of Polymeric Liquids, Vol. 2: Kinetic Theory (John Wiley, New York, 1977).
  65. A. Peterlin, Hydrodynamics of macromolecules in a velocity field with longitudinal gradient, J. Polym. Sci. B Polym. Lett. 4, 287 (1966).
  66. P. S. D. Surya Phani Tej, P. K. Mohanty, and V. Shankar, Master curves for unidirectional flows of FENE-P fluids in rectilinear and curvilinear geometries, J. Non-Newtonian Fluid Mech. 334, 105332 (2024).
  67. S. Yamani and G. H. McKinley, Master curves for FENE-P fluids in steady shear flow, J. Non-Newtonian Fluid Mech. 313, 104944 (2023).
  68. P. K. Mohanty, P. S. D. Surya Phani Tej, G. Subramanian, and V. Shankar, Nature of continuous spectra in wall-bounded shearing flows of FENE-P fluids Phys. Rev. Fluids 11, 053304 (2026).
  69. M. D. Graham, Microhydrodynamics, Brownian Motion, and Complex Fluids, Cambridge Texts in Applied Mathematics (Cambridge University Press, Cambridge, UK, 2018).
  70. H. J. Wilson, M. Renardy, and Y. Y. Renardy, Structure of the spectrum in zero Reynolds number shear flow of the UCM and Oldroyd-B liquids, J. Non-Newtonian Fluid Mech. 80, 251 (1999).
  71. G. Buza, J. Page, and R. R. Kerswell, Weakly nonlinear analysis of the viscoelastic instability in channel flow for finite and vanishing Reynolds numbers, J. Fluid Mech. 940, A11 (2022).
  72. A. Öztekin, R. A. Brown, and G. H. McKinley, Quantitative prediction of the viscoelastic instability in cone-and-plate flow of a Boger fluid using a multi-mode Giesekus model, J. Non-Newtonian Fluid Mech. 54, 351 (1994).
  73. G. H. McKinley, A. Oztekin, J. A. Byars, and R. A. Brown, Self-similar spiral instabilities in elastic flows between a cone and a plate, J. Fluid Mech. 285, 123 (1995).
  74. G. H. Choueiri, J. M. Lopez, A. Varshney, S. Sankar, and B. Hof, Experimental observation of the origin and structure of elastoinertial turbulence, Proc. Natl. Acad. Sci. USA 118, e2102350118 (2021).
  75. R. S. Graham, A. E. Likhtman, T. C. McLeish, and S. T. Milner, Microscopic theory of linear, entangled polymer chains under rapid deformation including chain stretch and convective constraint release, J. Rheol. 47, 1171 (2003).
  76. A. E. Likhtman and G. R. S, Simple constitutive equation for linear polymer melts derived from molecular theory: Rolie–Poly equation, J. Non-Newtonian Fluid Mech. 114, 1 (2003).
  77. Y. Renardy and M. Renardy, A singular perturbation study of the Rolie-Poly model, J. Non-Newtonian Fluid Mech. 262, 52 (2018).
  78. G. Bishko, T. C. B. McLeish, O. G. Harlen, and R. G. Larson, Theoretical molecular rheology of branched polymers in simple and complex flows: The pom-pom model, Phys. Rev. Lett. 79, 2352 (1997).
  79. T. C. B. McLeish and R. G. Larson, Molecular constitutive equations for a class of branched polymers: The pom-pom polymer, J. Rheol. 42, 81 (1998).
  80. W. M. Verbeeten, G. W. Peters, and F. P. Baaijens, Differential constitutive equations for polymer melts: The extended pom–pom model, J. Rheol. 45, 823 (2001).
