Interaction of a vortex pair with a polymeric fluid layer

Rabia Sonmez*

Robert A. Handler

David B. Goldstein, Anton Burtsev, and Ryan Kelly

Saikishan Suryanarayanan

  • *Contact author: rsonmez@gmu.edu
PDF

Phys. Rev. Fluids 11, 073301 – Published 6 July, 2026

DOI: https://doi.org/10.1103/qbb2-g6p6

Abstract

The interaction of vortical structures with boundaries has been extensively studied in Newtonian fluids, where conditions such as no-slip walls, free surfaces, or contaminated surfaces dictate whether vortices rebound, dissipate, or generate secondary structures. In this work, we investigate a related but fundamentally different problem: the interaction of a vortex pair with a finite, nonuniform layer of polymeric fluid. Numerical simulations employing the finitely extensible nonlinear elastic-Peterlin model are used to examine the effects of polymer concentration, relaxation time, polymer layer thickness, and maximum polymer extension on the evolution of kinetic energy and enstrophy. The results show that, while the polymeric fluid dissipates vortical motion, vortex-polymer layer interactions can also generate new coherent structures. In particular, the formation of secondary and tertiary vortices coincides with transient increases in kinetic energy, a behavior absent in the Newtonian case. Unlike classical vortex-boundary interactions, where the primary vortex survives, we find that under certain conditions it completely dissipates upon interaction with the polymer layer. These findings emphasize that fluids with nonuniform polymer concentrations act not only as dissipative agents but also as sources of vorticity, extending the traditional view of polymer-induced drag reduction and providing insights into vortex-polymer interactions.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (32)

  1. J. Walker, C. Smith, A. Cerra, and T. Doligalski, The impact of a vortex ring on a wall, J. Fluid Mech. 181, 99 (1987).
  2. P. Orlandi and R. Verzicco, Vortex rings impinging on walls: Axisymmetric and three-dimensional simulations, J. Fluid Mech. 256, 615 (1993).
  3. J. D. Swearingen, J. D. Crouch, and R. A. Handler, Dynamics and stability of a vortex ring impacting a solid boundary, J. Fluid Mech. 297, 1 (1995).
  4. W. T. Tsai and D. K. P. Yue, Effects of soluble and insoluble surfactant on laminar interactions of vortical flows with a free surface, J. Fluid Mech. 289, 315 (1995).
  5. A. Hirsa and W. W. Willmarth, Measurements of vortex pair interaction with a clean or contaminated free surface, J. Fluid Mech. 259, 25 (1994).
  6. G. B. Smith, R. J. Volino, R. A. Handler, and R. I. Leighton, The thermal signature of a vortex pair impacting a free surface, J. Fluid Mech. 444, 49 (2001).
  7. J. Han, R. Kelly, D. Goldstein, R. Handler, S. Suryanarayanan, and A. Burtsev, Simulations of a lamb–oseen vortex in the presence of a concentrated region of polymeric fluid, Phys. Fluids 37, 071706 (2025).
  8. R. Kelly, D. B. Goldstein, S. Suryanarayanan, R. A. Handler, and R. Sonmez, Smart targeting particles for efficient polymer drag reduction, in Proceedings of the 14th International Symposium on Turbulence and Shear Flow Phenomena (TSFP13) (Montreal, Canada, 2024).
  9. R. Kelly, D. Goldstein, A. Burtsev, S. Suryanarayanan, R. Handler, and R. Sonmez, Efficient turbulent drag reduction using targeted polymer additives, J. Fluid Mech. 1024, A60 (2025).
  10. R. A. Handler and M. J. Buckingham, Numerical simulation and linearized theory of vortex waves in a viscoelastic, polymeric fluid, Fluids 6, 325 (2021).
  11. R. A. Handler, E. Blaisten-Barojas, P. M. Ligrani, P. Dong, and M. Paige, Vortex generation in a finitely extensible nonlinear elastic Peterlin fluid initially at rest, Eng. Rep. 2, e12135 (2020).
  12. R. Sonmez, R. A. Handler, R. Kelly, D. B. Goldstein, and S. Suryanarayanan, Generation of laminar vortex rings by an impulsive body force, Phys. Rev. Fluids 8, 094701 (2023).
  13. R. Bird, C. Curtiss, R. Armstrong, and O. Hassager, Dynamics of Polymeric Liquids: Kinetic theory, 2nd ed. (Wiley, New York, 1987), Vol. 2.
  14. R. Tanner, Engineering Rheology, Oxford Engineering Science Series (Oxford University Press, Oxford, 2000).
  15. L. Xi, Turbulent drag reduction by polymer additives: Fundamentals and recent advances, Phys. Fluids 31, 121302 (2019).
  16. Y. Dubief, V. E. Terrapon, and B. Hof, Elasto-inertial turbulence, Annu. Rev. Fluid Mech. 55, 675 (2023).
  17. R. Sureshkumar and A. N. Beris, Effect of artificial stress diffusivity on the stability of numerical calculations and the flow dynamics of time-dependent viscoelastic flows, J. Non-Newtonian Fluid Mech. 60, 53 (1995).
  18. T. Min, J. Yoo, and H. Choi, Effect of spatial discretization schemes on numerical solutions of viscoelastic fluid flows, J. Non-Newtonian Fluid Mech. 100, 27 (2001).
  19. R. Fattal and R. Kupferman, Time-dependent simulation of viscoelastic flows at high Weissenberg number using the log-conformation representation, J. Non-Newtonian Fluid Mech. 126, 23 (2005).
  20. A. Shekar, R. M. McMullen, S. N. Wang, B. J. McKeon, and M. D. Graham, Critical-layer structures and mechanisms in elastoinertial turbulence, Phys. Rev. Lett. 122, 124503 (2019).
  21. B. Nsom and N. Latrache, Measurement of drag reduction in dilute polymer solution using triboelectric effect, Appl. Rheol. 28, 201825922 (2018).
  22. A Roshko, On the development of turbulent wakes from vortex streets, Tech. Rep. NACA-TN-2913, California Institute of Technology, Pasadena, CA, USA, 1953.
  23. R. Handler, J. Saylor, R. Leighton, and A. Rovelstad, Transport of a passive scalar at a shear-free boundary in fully developed turbulent open channel flow, Phys. Fluids 11, 2607 (1999).
  24. R. Sonmez, Interaction of a vortex pair with a passive scalar layer (2025), https://www.youtube.com/watch?v=zPm_PoZazAI.
  25. R. Sonmez, Interaction of a vortex pair with a polymer layer (concentration = 100 ppm) (2025), https://www.youtube.com/watch?v=n3yySQ8P4_Q.
  26. R. Sonmez, Interaction of a vortex pair with a polymer layer (2025), https://www.youtube.com/watch?v=tyhxA9Rt8Lc.
  27. J. L. Lumley, Drag reduction by additives, Annu. Rev. Fluid Mech. 1, 367 (1969).
  28. P. S. Virk, Drag reduction fundamentals, AIChE J. 21, 625 (1975).
  29. P. De Gennes, Towards a scaling theory of drag reduction, Physica A 140, 9 (1986).
  30. T. Min, J. Yul Yoo, H. Choi, and D. D. Joseph, Drag reduction by polymer additives in a turbulent channel flow, J. Fluid Mech. 486, 213 (2003).
  31. F. Serafini, F. Battista, P. Gualtieri, and C. Casciola, The role of polymer parameters and configurations in drag-reduced turbulent wall-bounded flows: Comparison between FENE and FENE-P, Int. J. Multiphase Flow 165, 104471 (2023).
  32. J. L. Lumley, Drag reduction in turbulent flow by polymer additives, J. Polym. Sci. Macromol. Rev. 7, 263 (1973).
