Effect of slip boundary conditions on flow homogeneity in cone-and-plate geometries
Phys. Rev. Fluids 11, 074001 – Published 6 July, 2026
DOI: https://doi.org/10.1103/pdp6-zczm
Abstract
Cone-and-plate (CP) viscometry is now widely employed to quantify slip lengths on superhydrophobic surfaces owing to its sensitivity at the micrometer scale; however, the presence of wall slip disrupts its intrinsic flow homogeneity. In this study, we present a combined theoretical and numerical investigation on how different slip boundary formulations affect flow homogeneity and its consequences for non-Newtonian fluid flows. Semianalytical solutions are derived under both constant slip-length and constant wall-stress boundary conditions. Numerical simulations are performed to examine the spatial structure of velocity, shear rate, and apparent viscosity in non-Newtonian fluids. The results demonstrate that a fixed slip length induces pronounced spatial variations in shear rate and radial dependence of viscosity for Carreau fluids, whereas a stress-controlled slip condition restores a nearly uniform shear field despite the presence of slip. The drag reduction and effective slip length for shear-thinning Carreau fluids are shown to depend explicitly on the imposed shear rate, with maximum slip enhancement occurring in the intermediate shear-thinning regime. These findings clarify the fundamental limitations of conventional slip interpretations in CP rheometric systems and provide a physically consistent framework for a homogenous flow field.
Physics Subject Headings (PhySH)
Article Text
References (25)
- R. B. Bird, R. C. Armstrong, and O. Hassager, Dynamics of Polymeric Liquids, Fluid Mechanics Vol. 1 (John Wiley and Sons Inc., New York, NY, 1986).
- T. Hou, On the flow field of Newtonian liquids in the truncated-cone and plate rheometer, Rheol. Acta 20, 14 (1981).
- A. J. Giacomin and P. H. Gilbert, Exact-solution for cone-plate viscometry, J. Appl. Phys. 122, 175101 (2017).
- J. P. Rothstein, Slip on superhydrophobic surfaces, Annu. Rev. Fluid Mech. 42, 89 (2010).
- A. Y. Malkin and S. Patlazhan, Wall slip for complex liquids–phenomenon and its causes, Adv. Colloid Interface Sci. 257, 42 (2018).
- A. Maali, Y. Pan, B. Bhushan, and E. Charlaix, Hydrodynamic drag-force measurement and slip length on microstructured surfaces, Phys. Rev. E 85, 066310 (2012).
- G. Bolognesi, C. Cottin-Bizonne, and C. Pirat, Evidence of slippage breakdown for a superhydrophobic microchannel, Phys. Fluids 26, 082004 (2014).
- C. Lee, C.-H. Choi, and C.-J. Kim, Structured surfaces for a giant liquid slip, Phys. Rev. Lett. 101, 064501 (2008).
- L. Zhang, Y. A. Mehanna, C. R. Crick, and R. J. Poole, Surface tension and viscosity dependence of slip length over irregularly structured superhydrophobic surfaces, Langmuir 38, 11873 (2022).
- C. Lee, C.-H. Choi, and Chang Jin Kim, Superhydrophobic drag reduction in laminar flows: A critical review, Expt. Fluids 57, 176 (2016).
- P. Joseph and P. Tabeling, Direct measurement of the apparent slip length, Phys. Rev. E 71, 035303(R) (2005).
- K. T. Ahmmed and A.-M. Kietzig, Drag reduction on laser-patterned hierarchical superhydrophobic surfaces, Soft Matter 12, 4912 (2016).
- C.-H. Choi and C.-J. Kim, Large slip of aqueous liquid flow over a nanoengineered superhydrophobic surface, Phys. Rev. Lett. 96, 066001 (2006).
- H. A. Barnes, J. F. Hutton, and K. Walters, An Introduction to Rheology (Elsevier, Amsterdam, 1989), Vol. 3.
- L. Zhang, W. Zhou, C. R. Crick, H. C. -H. Ng, and R. J. Poole, Slip length and drag reduction of superhydrophobic surfaces in shear-thinning fluid flows, J. Colloid Interface Sci. 685, 468 (2025).
- S. Patlazhan and S. Vagner, Apparent slip of shear thinning fluid in a microchannel with a superhydrophobic wall, Phys. Rev. E 96, 013104 (2017).
- P. K. Ray, D. Bouvier, and D. T. Papageorgiou, Flow of shear-thinning liquids in channels with superhydrophobic surfaces, J. Non-Newtonian Fluid Mech. 319, 105091 (2023).
- O. Schnitzer and P. K. Ray, Giant superhydrophobic slip of shear-thinning liquids, Phys. Rev. Fluids 9, L112201 (2024).
- H. Xu, C. R. Crick, and R. J. Poole, Evaluating the resilience of superhydrophobic materials using the slip-length concept, J. Mater. Chem. A 6, 4458 (2018).
- K. T. Ahmmed, C. Patience, and A.-M. Kietzig, Internal and external flow over laser-textured superhydrophobic polytetrafluoroethylene (PTFE), ACS Appl. Mater. Interfaces 8, 27411 (2016).
- S. Imayama, P. H. Alfredsson, and R. J. Lingwood, On the laminar-turbulent transition of the rotating-disk flow: The role of absolute instability, J. Fluid Mech. 745, 132 (2014).
- D. Griffiths and K. Walters, On edge effects in rheometry, J. Fluid Mech. 42, 379 (1970).
- A. S. Haase, J. A. Wood, Lisette M. Sprakel, and Rob G. Lammertink, Inelastic non-Newtonian flow over heterogeneously slippery surfaces, Phys. Rev. E 95, 023105 (2017).
- D. Crowdy, Effect of shear thinning on superhydrophobic slip: Perturbative corrections to the effective slip length, Phys. Rev. Fluids 2, 124201 (2017).
- H. Rahmani and S. Taghavi, Poiseuille flow of a Bingham fluid in a channel with a superhydrophobic groovy wall, J. Fluid Mech. 948, A34 (2022).
