Total enthalpy transformation in compressible turbulence recovering the incompressible law of the wall

Xianliang Chen1,2, Zhiye Zhao3, Jianping Gan1,2, and Lin Fu1,3,*

  • *Contact author: linfu@ust.hk
PDF

Phys. Rev. Fluids 11, 084608 – Published 17 August, 2026

DOI: https://doi.org/10.1103/p2jq-t1gn

Abstract

Accurate scaling of heat energy is critical for compressible turbulence modeling. In addition to the temperature-velocity relation, temperature transformations have received increasing interest recently, but their overall accuracy is still inferior to the velocity counterparts. In this work, we propose to use total enthalpy H instead of temperature to construct the compressible law of the wall for heat energy. A critical justification is the structural resemblance between the equations of compressible H and incompressible passive scalars. Also, H reduces to static enthalpy at zero Mach number, meeting the requirement of self-consistency for transformations. To build the transformation, we first define and uncover the scalings of laminar and turbulent Prandtl numbers for H, and then reveal the strong analogy of heat flux budgets between compressible H and incompressible passive scalars. Finally, a semilocal total enthalpy transformation of no fitted parameters is constructed for channel flows, which is structurally analogous and comparable in accuracy to the Trettel-Larsson velocity transformation. This new transformation can potentially serve as a wall model for energy equations to accurately predict the enthalpy or temperature in compressible turbulence.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (48)

  1. R. A. Gowen and J. W. Smith, The effect of the Prandtl number on temperature profiles for heat transfer in turbulent pipe flow, Chem. Eng. Sci. 22, 1701 (1967).
  2. B. A. Kader, Temperature and concentration profiles in fully turbulent boundary layers, Int. J. Heat Mass Transfer 24, 1541 (1981).
  3. A. S. Monin and A. M. Yaglom, Statistical Fluid Mechanics: The Mechanics of Turbulence (MIT Press, Cambridge, 1971), p. 769.
  4. S. Pirozzoli, An explicit representation for mean profiles and fluxes in forced passive scalar convection, J. Fluid Mech. 968, R1 (2023).
  5. S. K. Lele, Compressibility effects on turbulence, Annu. Rev. Fluid Mech. 26, 211 (1994).
  6. P. G. Huang, G. N. Coleman, and P. Bradshaw, Compressible turbulent channel flows: DNS results and modelling, J. Fluid Mech. 305, 185 (1995).
  7. L. Duan and M. P. Martín, Direct numerical simulation of hypersonic turbulent boundary layers. Part 4. Effect of high enthalpy, J. Fluid Mech. 684, 25 (2011).
  8. P. Bradshaw, G. P. Huang, and B. E. Launder, The law of the wall in turbulent flow, Proc. R. Soc. London, Ser. A 451, 165 (1995).
  9. C. Cheng, X. Chen, W. Zhu, W. Shyy, and L. Fu, Progress in physical modeling of compressible wall-bounded turbulent flows, Acta Mech. Sin. 40, 323663 (2024).
  10. X. Chen, A. Ying, J. Gan, and L. Fu, Uncovering the forcing statistics in stochastic linear models for compressible wall-bounded turbulence, J. Fluid Mech. 1015, A40 (2025).
  11. E. R. van Driest, Turbulent boundary layer in compressible fluids, J. Aeronaut. Sci. 18, 145 (1951).
  12. A. Trettel and J. Larsson, Mean velocity scaling for compressible wall turbulence with heat transfer, Phys. Fluids 28, 026102 (2016).
  13. K. P. Griffin, L. Fu, and P. Moin, Velocity transformation for compressible wall-bounded turbulent flows with and without heat transfer, Proc. Natl. Acad. Sci. USA 118, e2111144118 (2021).
  14. A. Patel, B. J. Boersma, and R. Pecnik, Scalar statistics in variable property turbulent channel flows, Phys. Rev. Fluids 2, 084604 (2017).
  15. D. Modesti and S. Pirozzoli, Friction and heat transfer in forced air convection with variable physical properties, J. Fluid Mech. 1001, A27 (2024).
  16. P. E. S. Chen, G. P. Huang, Y. Shi, X. I. A. Yang, and Y. Lv, A unified temperature transformation for high-Mach-number flows above adiabatic and isothermal walls, J. Fluid Mech. 951, A38 (2022).
  17. P. G. Huang, G. N. Coleman, P. R. Spalart, and X. I. A. Yang, Velocity and temperature scalings leading to compressible laws of the wall, J. Fluid Mech. 977, A49 (2023).
  18. C. Cheng and L. Fu, Mean temperature scalings in compressible wall turbulence, Phys. Rev. Fluids 9, 054610 (2024).
  19. X. Zhu, Y. Song, X. Yang, Y. Ji, and Z. Xia, Enhancing temperature transformations with improved mean velocity scalings in canonical compressible wall-bounded turbulent flows, J. Fluid Mech. 1024, A44 (2025).
  20. Y. Xu, S. J. Schmidt, and N. A. Adams, Temperature transformation recovering the compressible law of the wall for turbulent channel flow, Phys. Fluids 38, 035113 (2026).
  21. T. Wan, P.-X. Jiang, P. Zhao, and X. Wang, Enthalpy transformation for wall-bounded supercritical flows with heat transfer, J. Fluid Mech. 1026, A36 (2026).
  22. M. V. Morkovin, Effects of compressibility on turbulent flows, in The Mechanics of Turbulence (1962).
  23. T. B. Gatski and J.-P. Bonnet, Compressibility, Turbulence and High Speed Flow (Academic Press, New York, 2013).
  24. T. Gibis, C. Wenzel, M. Kloker, and U. Rist, Self-similar compressible turbulent boundary layers with pressure gradients. Part 2. Self-similarity analysis of the outer layer, J. Fluid Mech. 880, 284 (2019).
  25. X. Chen, J. Gan, and L. Fu, Mean temperature-velocity relation and a new temperature wall model for compressible laminar and turbulent flows, J. Fluid Mech. 1009, A39 (2025).
  26. The layer closest to the wall here is formally termed molecular transport sublayer, but nearly collapses with the viscous sublayer if Pr∼1. Therefore, no distinction is made in this work as the working fluid is only air.
  27. F. Alcántara-Ávila, S. Hoyas, and M. J. Pérez-Quiles, Direct numerical simulation of thermal channel flow for Reτ=5000 and Pr=0.71, J. Fluid Mech. 916, A29 (2021).
  28. S. Pirozzoli, M. Bernardini, and P. Orlandi, Passive scalars in turbulent channel flow at high Reynolds number, J. Fluid Mech. 788, 614 (2016).
  29. J. Kim and P. Moin, Transport of passive scalars in a turbulent channel flow, in Turbulent Shear Flows 6, edited by J. C. André, J. Cousteix, F. Durst, B. E. Launder, F. W. Schmidt, and J. H. Whitelaw (Springer, Berlin, Heidelberg, 1989), pp. 85–96.
  30. R. A. Antonia, H. Abe, and H. Kawamura, Analogy between velocity and scalar fields in a turbulent channel flow, J. Fluid Mech. 628, 241 (2009).
  31. J. Yao and F. Hussain, Turbulence statistics and coherent structures in compressible channel flow, Phys. Rev. Fluids 5, 084603 (2020).
  32. X. Zhu, Y. Song, P. Zhang, X. Yang, Y. Ji, and Z. Xia, Influences of streamwise driving forces on turbulent statistics in direct numerical simulations of compressible turbulent channel flows, Phys. Rev. Fluids 10, 064616 (2025).
  33. X. Chen, C. Cheng, J. Gan, and L. Fu, Study of the linear models in estimating coherent velocity and temperature structures for compressible turbulent channel flows, J. Fluid Mech. 973, A36 (2023).
  34. Y.-S. Zhang, W.-T. Bi, F. Hussain, and Z.-S. She, A generalized Reynolds analogy for compressible wall-bounded turbulent flows, J. Fluid Mech. 739, 392 (2014).
  35. H. Abe, H. Kawamura, and Y. Matsuo, Surface heat-flux fluctuations in a turbulent channel flow up to Reτ=1020 with Pr = 0.025 and 0.71, Int. J. Heat Fluid Flow 25, 404 (2004).
  36. P. Chen, W. Zhang, M. Wan, S. Chen, X. Yang, and Z. Xia, Mean flow transformation for incompressible wall-bounded flows at low and high Reynolds numbers, Acta Mech. Sin. 42, 325136 (2026).
  37. D. Modesti and S. Pirozzoli, Direct numerical simulation of supersonic pipe flow at moderate Reynolds number, Int. J. Heat Fluid Flow 76, 100 (2019).
  38. V. Kumar and J. Larsson, Modular method for estimation of velocity and temperature profiles in high-speed boundary layers, AIAA J. 60, 5165 (2022).
  39. Y. Song, P. Zhang, and Z. Xia, Predicting mean profiles in compressible turbulent channel and pipe flows, Phys. Rev. Fluids 8, 034604 (2023).
  40. X. Chen, C. Cheng, L. Fu, and J. Gan, Linear response analysis of supersonic turbulent channel flows with a large parameter space, J. Fluid Mech. 962, A7 (2023).
  41. A. M. Hasan, J. Larsson, S. Pirozzoli, and R. Pecnik, Estimating mean profiles and fluxes in high-speed turbulent boundary layers using inner/outer-layer scalings, AIAA J. 62, 848 (2024).
  42. K. P. Griffin, L. Fu, and P. Moin, Near-wall model for compressible turbulent boundary layers based on an inverse velocity transformation, J. Fluid Mech. 970, A36 (2023).
  43. X. Chen, J. Gan, and L. Fu, An improved Baldwin-Lomax algebraic wall model for high-speed canonical turbulent boundary layers using established scalings, J. Fluid Mech. 987, A7 (2024).
  44. F. Mo and Z. Gao, A new wall function method for hypersonic laminar boundary layers, J. Fluid Mech. 981, A9 (2024).
  45. J. Shen, X. Chen, and L. Fu, Development and assessment of an improved Baldwin-Lomax turbulence model for complex hypersonic flows in two and three dimensions, Comput. Fluids 305, 106917 (2026).
  46. X. Chen, Y. Xi, J. Ren, and S. Fu, Cross-flow vortices and their secondary instabilities in hypersonic and high-enthalpy boundary layers, J. Fluid Mech. 947, A25 (2022).
  47. Y. Song, P. Zhang, Y. Liu, and Z. Xia, Central mean temperature scaling in compressible turbulent channel flows with symmetric isothermal boundaries, Phys. Rev. Fluids 7, 044606 (2022).
  48. D. J. Lusher and G. N. Coleman, Numerical study of compressible wall-bounded turbulence—The effect of thermal wall conditions on the turbulent Prandtl number in the low-supersonic regime, Int. J. Comput. Fluid Dyn. 36, 797 (2022).
