Stability of vortex lattices in rotating flows

Julián Amette Estrada1,2,*, Alexandros Alexakis3,†, Marc E. Brachet3,‡, and Pablo D. Mininni1,2,4,§

  • *Contact author: julianamette@df.uba.ar
  • †Contact author: alexandros.alexakis@phys.ens.fr
  • ‡Contact author: brachet@phys.ens.fr
  • §Contact author: mininni@df.uba.ar
PDF

Phys. Rev. Fluids 11, 074401 – Published 10 July, 2026

DOI: https://doi.org/10.1103/k8zw-s6kj

Abstract

Vortex lattices—highly ordered arrays of vortices—are known to arise in quantum systems such as type II superconductors and Bose-Einstein condensates. More recently, similar arrangements have been reported in classical rotating fluids. However, the mechanisms governing their formation, stability, and eventual breakdown remain poorly understood. We explore the dynamical stability of vortex lattices in three-dimensional rotating flows. To that end we construct controlled initial conditions consisting of vortex lattices superimposed on turbulent backgrounds. We then characterize their evolution across different Rossby numbers and domain geometries. By introducing an Ekman drag we are able to reach a steady state where vortex lattices persist with near constant amplitude up until spontaneous breakup of the lattice, or an equivalent of “melting,” occurs. We examine an ensemble of runs in order to determine the mean lifetime of the lattice as a function of the system parameters. Our results reveal that the stability of the lattices is a memory-less random process whose mean lifetime depends sensitively on the system parameters that if finely tuned can lead to very long-lived lattice states. These metastable states exhibit statistical properties reminiscent of critical systems and can offer insight into long-lived vortex patterns observed in planetary atmospheres.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (47)

  1. Q. Ouyang and H. L. Swinney, Transition from a uniform state to hexagonal and striped Turing patterns, Nature (London) 352, 610 (1991).
  2. M. Golubitsky, J. Swift, and E. Knobloch, Symmetries and pattern selection in Rayleigh-Bénard convection, Physica D 10, 249 (1984).
  3. H.-J. Herrmann, Pattern formation of dunes, Nonlinear Dyn. 44, 315 (2006).
  4. M. Ichihara, P. D. Mininni, S. Ravichandran, C. Cimarelli, and C. Vagasky, Multiphase turbulent flow explains lightning rings in volcanic plumes, Commun. Earth Env. 4, 417 (2023).
  5. V. Fernandez-Gonzalez, M. Clerc, G. González-Cortés, P. Hidalgo, and J. Vergara, Abrikosov clusters in chiral liquid crystal droplets, Rep. Prog. Phys. 87, 120502 (2024).
  6. A. Alexakis, R. Marino, P. D. Mininni, A. van Kan, R. Foldes, and F. Feraco, Large-scale self-organization in dry turbulent atmospheres, Science 383, 1005 (2024).
  7. N. W. Ashcroft and N. D. Mermin, Solid State Physics, Vol. 116 (Saunders College Publishing, Philadelphia, 1976), p. 217.
  8. A. A. Abrikosov, The magnetic properties of superconducting alloys, J. Phys. Chem. Solids 2, 199 (1957).
  9. E. H. Brandt, Elastic and plastic properties of the flux-line lattice in type-II superconductors, Phys. Rev. B 34, 6514 (1986).
  10. R. S. Severino, P. D. Mininni, E. Fradkin, V. Bekeris, G. Pasquini, and G. S. Lozano, Vortices in a Ginzburg-Landau theory of superconductors with nematic order, Phys. Rev. B 106, 094512 (2022).
  11. A. L. Fetter, Rotating trapped Bose-Einstein condensates, Rev. Mod. Phys. 81, 647 (2009).
  12. J. Amette Estrada, M. E. Brachet, and P. D. Mininni, Thermalized Abrikosov lattices from decaying turbulence in rotating BECs, AVS Quantum Sci. 4, 046201 (2022).
  13. J. Amette Estrada, M. E. Brachet, and P. D. Mininni, Vortex-lattice melting and critical temperature shift in rotating Bose-Einstein condensates, Phys. Rev. A 111, 023304 (2025).
  14. X. M. de Wit, M. Fruchart, T. Khain, F. Toschi, and V. Vitelli, Pattern formation by turbulent cascades, Nature (London) 627, 515 (2024).
  15. C. Floyd, A. R. Dinner, and S. Vaikuntanathan, Pattern formation in odd viscoelastic fluids, Phys. Rev. Res. 6, 033100 (2024).
  16. I. H. Riedel, K. Kruse, and J. Howard, A self-organized vortex array of hydrodynamically entrained sperm cells, Science 309, 300 (2005).
  17. M. James, W. J. T. Bos, and M. Wilczek, Turbulence and turbulent pattern formation in a minimal model for active fluids, Phys. Rev. Fluids 3, 061101(R) (2018).
  18. M. James, D. A. Suchla, J. Dunkel, and M. Wilczek, Emergence and melting of active vortex crystals, Nat. Commun. 12, 5630 (2021).
  19. H. Xu and Y. Wu, Self-enhanced mobility enables vortex pattern formation in living matter, Nature (London) 627, 553 (2024).
  20. B. M. Boubnov and G. S. Golitsyn, Experimental study of convective structures in rotating fluids, J. Fluid Mech. 167, 503 (1986).
  21. B. M. Boubnov and G. S. Golitsyn, Temperature and velocity field regimes of convective motions in a rotating plane fluid layer, J. Fluid Mech. 219, 215 (1990).
  22. A. van Kan, B. Favier, K. Julien, and E. Knobloch, From a vortex gas to a vortex crystal in instability-driven two-dimensional turbulence, J. Fluid Mech. 984, A41 (2024).
  23. P. Clark Di Leoni, A. Alexakis, L. Biferale, and M. Buzzicotti, Phase transitions and flux-loop metastable states in rotating turbulence, Phys. Rev. Fluids 5, 104603 (2020).
  24. G. Marchetti and P. D. Mininni, Spontaneous vortex crystal formation in classical rotating flows, Phys. Rev. Fluids 10, 084603 (2025).
  25. A. Adriani, A. Mura, G. Orton, C. Hansen, F. Altieri, M. L. Moriconi, J. Rogers, G. Eichstädt, T. Momary, A. P. Ingersoll, et al., Clusters of cyclones encircling Jupiter's poles, Nature (London) 555, 216 (2018).
  26. M. E. O'Neill, K. A. Emanuel, and G. R. Flierl, Polar vortex formation in giant-planet atmospheres due to moist convection, Nat. Geosci. 8, 523 (2015).
  27. R. K. Yadav and J. Bloxham, Deep rotating convection generates the polar hexagon on Saturn, Proc. Natl. Acad. Sci. USA 117, 13991 (2020).
  28. J.-Q. Zhong, M. D. Patterson, and J. S. Wettlaufer, Streaks to rings to vortex grids: Generic patterns in transient convective spin up of an evaporating fluid, Phys. Rev. Lett. 105, 044504 (2010).
  29. F. Moisy, C. Morize, M. Rabaud, and J. Sommeria, Decay laws, anisotropy and cyclone–anticyclone asymmetry in decaying rotating turbulence, J. Fluid Mech. 666, 5 (2011).
  30. B. Gallet, A. Campagne, P.-P. Cortet, and F. Moisy, Scale-dependent cyclone-anticyclone asymmetry in a forced rotating turbulence experiment, Phys. Fluids 26, 035108 (2014).
  31. H. Aref and D. L. Vainchtein, Point vortices exhibit asymmetric equilibria, Nature (London) 392, 769 (1998).
  32. C. Cambon, R. Rubinstein, and F. S. Godeferd, Advances in wave turbulence: Rapidly rotating flows, New J. Phys. 6, 73 (2004).
  33. A. Sen, P. D. Mininni, D. Rosenberg, and A. Pouquet, Anisotropy and nonuniversality in scaling laws of the large-scale energy spectrum in rotating turbulence, Phys. Rev. E 86, 036319 (2012).
  34. E. Deusebio, G. Boffetta, E. Lindborg, and S. Musacchio, Dimensional transition in rotating turbulence, Phys. Rev. E 90, 023005 (2014).
  35. A. van Kan and A. Alexakis, Critical transition in fast-rotating turbulence within highly elongated domains, J. Fluid Mech. 899, A33 (2020).
  36. A. Alexakis and L. Biferale, Cascades and transitions in turbulent flows, Phys. Rep. 767–769, 1 (2018).
  37. A. Celani, S. Musacchio, and D. Vincenzi, Turbulence in more than two and less than three dimensions, Phys. Rev. Lett. 104, 184506 (2010).
  38. S. J. Benavides and A. Alexakis, Critical transitions in thin layer turbulence, J. Fluid Mech. 822, 364 (2017).
  39. H. Aref, P. Newton, M. Stremler, T. Tokieda, and D. Vainchtein, Vortex crystals, Adv. Appl. Mech. 39, 1 (2003).
  40. P. D. Mininni, D. Rosenberg, R. Reddy, and A. Pouquet, A hybrid MPI–OpenMP scheme for scalable parallel pseudospectral computations for fluid turbulence, Parallel Comput. 37, 316 (2011).
  41. D. Rosenberg, P. D. Mininni, R. Reddy, and A. Pouquet, GPU parallelization of a hybrid pseudospectral geophysical turbulence framework using CUDA, Atmosphere 11, 178 (2020).
  42. K. Seshasayanan and B. Gallet, Onset of three-dimensionality in rapidly rotating turbulent flows, J. Fluid Mech. 901, R5 (2020).
  43. C. S. Lohani, S. K. Nayak, and K. Seshasayanan, Effect of confinement on the transition from two-to three-dimensional fast-rotating turbulent flows, Phys. Rev. Fluids 9, 034604 (2024).
  44. A. Das, M. Sharma, A. Ranjan, and M. K. Verma, Bursting of columnar structures in forced rotating turbulence, Phys. Rev. Fluids 10, 084803 (2025).
  45. E. J. Yarmchuk, M. J. V. Gordon, and R. E. Packard, Observation of stationary vortex arrays in rotating superfluid Helium, Phys. Rev. Lett. 43, 214 (1979).
  46. S. Kragset, E. Babaev, and A. Sudbø, Thermal fluctuations of vortex matter in trapped Bose-Einstein condensates, Phys. Rev. Lett. 97, 170403 (2006).
  47. J. Amette Estrada, M. Brachet, and P. Mininni, Dataset for Stability of vortex lattices in rotating flows [Data set], Zenodo, 2025, https://doi.org/10.5281/zenodo.17282201.
