Effect of Langmuir adsorption on the dynamics of a miscible blob in a porous media flow

Ajay Jangid and Manoranjan Mishra*

  • *Contact author: manoranjan@iitrpr.ac.in
PDF

Phys. Rev. Fluids 11, 064002 – Published 1 June, 2026

DOI: https://doi.org/10.1103/d8gs-pnbn

Abstract

Solute transport in porous media is strongly influenced by both hydrodynamic instabilities and physicochemical interactions, such as adsorption. In this study, we investigate the coupled dynamics of a finite solute blob subjected to Langmuir type nonlinear adsorption and viscous fingering (VF) instabilities during miscible displacement. To resolve the complex interplay between adsorption and instability, we solved the governing equations using a high-resolution Fourier pseudospectral method. While linear adsorption leads to symmetric blob spreading, the nonlinear Langmuir regime exhibits highly asymmetric solute profiles characterized by the formation of a rear rarefaction wave and a sharp leading shock layer. Additionally, the net advection of the blob is noticeably reduced in the upstream direction as the Langmuir adsorption parameter b increases. We have found that for the range of adsorption parameters for a given suitable log mobility ratio, the VF instability was suppressed and introduced a new comet shape structure. Furthermore, we examine the impact of adsorption on mixing by tracking the degree of mixing over time. Interestingly, we observe a nonmonotonic dependence of mixing on the Langmuir parameter for a suitable log mobility ratio. The coupled effect of VF at the rear interface and of Langmuir adsorption provides a powerful mechanism to enhance or reduce the mixing and VF depending on the need of the application.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (49)

  1. J. Rouquerol, F. Rouquerol, P. Llewellyn, G. Maurin, and K. Sing, Adsorption by Powders and Porous Solids: Principles, Methodology, and Applications (Academic Press, San Diego, 2013).
  2. J. R. de Andrade, M. F. Oliveira, M. G. da Silva, and M. G. Vieira, Adsorption of pharmaceuticals from water and wastewater using nonconventional low-cost materials: A review, Ind. Eng. Chem. Res. 57, 3103 (2018).
  3. H. I. Essaid, B. A. Bekins, and I. M. Cozzarelli, Organic contaminant transport and fate in the subsurface: Evolution of knowledge and understanding, Water Resour. Res. 51, 4861 (2015).
  4. G. Guiochon, D. G. Shirazi, and A. Felinger, Fundamentals of Preparative and Nonlinear Chromatography (Academic Press, Amsterdam, 2006), Vol. 9.
  5. V. F. Kiselev and O. V. Krylov, Adsorption and Catalysis on Transition Metals and their Oxides (Spriner-Verlag, Berlin, 1989).
  6. A. Skvortsov and A. Gorvunov, Adsorption effects in the chromatography of polymers, J. Chromatogr. A 358, 77 (1986).
  7. L. Pang and M. E. Close, Nonequilibrium transport of Cd in alluvial gravels, J. Contam. Hydrol. 36, 185 (1999).
  8. C.-T. Hsu, C.-H. Chang, and S.-Y. Lin, Comments on the adsorption isotherm and determination of adsorption kinetics, Langmuir 13, 6204 (1997).
  9. S. Kalam, S. A. Abu-Khamsin, M. S. Kamal, and S. Patil, Surfactant adsorption isotherms: A review, ACS Omega 6, 32342 (2021).
  10. D. R. Burris, R. M. Allen-King, V. S. Manoranjan, T. J. Campbell, G. A. Loraine, and B. Deng, Chlorinated ethene reduction by cast iron: Sorption and mass transfer, J. Environ. Eng. 124, 1012 (1998).
  11. M. L. Brusseau, The effect of nonlinear sorption on transformation of contaminants during transport in porous media, J. Contam. Hydrol. 17, 277 (1995).
  12. K. G. Akpomie, J. Conradie, K. A. Adegoke, K. O. Oyedotun, J. O. Ighalo, J. F. Amaku, C. Olisah, A. O. Adeola, and K. O. Iwuozor, Adsorption mechanism and modeling of radionuclides and heavy metals onto ZnO nanoparticles: A review, Appl. Water Sci. 13, 20 (2023).
  13. R. P. Schwarzenbach, B. I. Escher, K. Fenner, T. B. Hofstetter, C. A. Johnson, U. Von Gunten, and B. Wehrli, The challenge of micropollutants in aquatic systems, Science 313, 1072 (2006).
  14. D. M. Ruthven, Principles of Adsorption and Adsorption Processes (John Wiley & Sons, New York, 1984).
  15. G. M. Homsy, Viscous fingering in porous media, Annu. Rev. Fluid Mech. 19, 271 (1987).
  16. C. T. Tan and G. M. Homsy, Stability of miscible displacements in porous media: Rectilinear flow, Phys. Fluids 29, 3549 (1986).
  17. A. Kumar and M. Mishra, Boundary effects on the onset of miscible viscous fingering in a Hele-Shaw flow, Phys. Rev. Fluids 4, 104004 (2019).
  18. T. E. Videbæk and S. R. Nagel, Diffusion-driven transition between two regimes of viscous fingering, Phys. Rev. Fluids 4, 033902 (2019).
  19. B. Dong, Y. Yan, and W. Li, LBM simulation of viscous fingering phenomenon in immiscible displacement of two fluids in porous media, Transp. Porous Med. 88, 293 (2011).
  20. B. H. Kueper and E. O. Frind, An overview of immiscible fingering in porous media, J. Contam. Hydrol. 2, 95 (1988).
  21. P. H. Krumrine, J. S. Falcone, and T. C. Campbell, Surfactant flooding 1: The effect of alkaline additives on IFT, surfactant adsorption, and recovery efficiency, Soc. Pet. Eng. J. 22, 503 (1982).
  22. B. Yadali Jamaloei and R. Kharrat, Analysis of microscopic displacement mechanisms of dilute surfactant flooding in oil-wet and water-wet porous media, Transp. Porous Med. 81, 1 (2010).
  23. A. Sayari and Y. Belmabkhout, Stabilization of amine-containing CO2 adsorbents: Dramatic effect of water vapor, J. Am. Chem. Soc. 132, 6312 (2010).
  24. S. P. Gupta and R. A. Greenkorn, Dispersion during flow in porous media with bilinear adsorption, Water Resour. Res. 9, 1357 (1973).
  25. S. P. Gupta and R. A. Greenkorn, Determination of dispersion and nonlinear adsorption parameters for flow in porous media, Water Resour. Res. 10, 839 (1974).
  26. C. Rana and M. Mishra, Interaction between shock layer and viscous fingering in a Langmuir adsorbed solute, Phys. Fluids 29, 032108 (2017).
  27. C. Rana, S. Pramanik, M. Martin, A. De Wit, and M. Mishra, Influence of Langmuir adsorption and viscous fingering on transport of finite size samples in porous media, Phys. Rev. Fluids 4, 104001 (2019).
  28. M. Mishra, M. Martin, and A. De Wit, Miscible viscous fingering with linear adsorption on the porous matrix, Phys. Fluids 19, 073101 (2007).
  29. M. L. Dickson, T. T. Norton, and E. J. Fernandez, Chemical imaging of multicomponent viscous fingering in chromatography, AIChE J. 43, 409 (1997).
  30. F. G. Helfferich and P. W. Carr, Nonlinear waves in chromatography: I. Waves, shocks, and shapes, J. Chromatogr. A 629, 97 (1993).
  31. C. Rana, W. De Malsche, and A. De Wit, Decreased peak tailing during transport of solutes in porous media with alternate adsorption properties, Chem. Eng. Sci. 203, 415 (2019).
  32. C. Welty, A. C. Kane III, and L. J. Kauffman, Stochastic analysis of transverse dispersion in density-coupled transport in aquifers, Water Resour. Res. 39, 1150 (2003).
  33. A. De Wit and G. Homsy, Viscous fingering in reaction-diffusion systems, J. Chem. Phys. 110, 8663 (1999).
  34. C.-Y. Chen and S.-W. Wang, Miscible displacement of a layer with finite width in porous media, Int. J. Numer. Methods Heat Fluid Flow 11, 761 (2001).
  35. R. Maes, G. Rousseaux, B. Scheid, M. Mishra, P. Colinet, and A. De Wit, Experimental study of dispersion and miscible viscous fingering of initially circular samples in Hele-Shaw cells, Phys. Fluids 22, 123104 (2010).
  36. C.-Y. Chen, L. Wang, and E. Meiburg, Miscible droplets in a porous medium and the effects of Korteweg stresses, Phys. Fluids 13, 2447 (2001).
  37. S. Pramanik, A. De Wit, and M. Mishra, Viscous fingering and deformation of a miscible circular blob in a rectilinear displacement in porous media, J. Fluid Mech. 782, R2 (2015).
  38. S. Molins, D. Trebotich, C. I. Steefel, and C. Shen, An investigation of the effect of pore scale flow on average geochemical reaction rates using direct numerical simulation, Water Resour. Res. 48, W03527 (2012).
  39. A. De Wit, Y. Bertho, and M. Martin, Viscous fingering of miscible slices, Phys. Fluids 17, 054114 (2005).
  40. H. J. Catchpoole, R. A. Shalliker, G. R. Dennis, and G. Guiochon, Visualising the onset of viscous fingering in chromatography columns, J. Chromatogr. A 1117, 137 (2006).
  41. R. A. Shalliker, H. J. Catchpoole, G. R. Dennis, and G. Guiochon, Visualising viscous fingering in chromatography columns: High viscosity solute plug, J. Chromatogr. A 1142, 48 (2007).
  42. B. S. Broyles, R. A. Shalliker, D. E. Cherrak, and G. Guiochon, Visualization of viscous fingering in chromatographic columns, J. Chromatogr. A 822, 173 (1998).
  43. M. de Freitas Souza, A. C. Langaro, A. B. R. de Jesus Passos, H. A. Lins, T. S. Silva, V. Mendonça, A. A. da Silva, and D. V. Silva, Adsorption mechanisms of atrazine isolated and mixed with glyphosate formulations in soil, PLoS One 15, e0242350 (2020).
  44. J.-H. Park, Y. S. Ok, S.-H. Kim, J.-S. Cho, J.-S. Heo, R. D. Delaune, and D.-C. Seo, Competitive adsorption of heavy metals onto sesame straw biochar in aqueous solutions, Chemosphere 142, 77 (2016).
  45. G. Gerber, M. Bensouda, D. A. Weitz, and P. Coussot, Self-limited accumulation of colloids in porous media, Phys. Rev. Lett. 123, 158005 (2019).
  46. C. T. Tan and G. M. Homsy, Simulation of nonlinear viscous fingering in miscible displacement, Phys. Fluids 31, 1330 (1988).
  47. W. Zimmerman and G. Homsy, Nonlinear viscous fingering in miscible displacement with anisotropic dispersion, Phys. Fluids 3, 1859 (1991).
  48. B. Jha, L. Cueto-Felgueroso, and R. Juanes, Fluid mixing from viscous fingering, Phys. Rev. Lett. 106, 194502 (2011).
  49. A. Jangid and M. Mishra, The effect of Langmuir adsorption on the dynamics of a miscible blob in a porous media flow, Zenodo, 2026, https://doi.org/10.5281/zenodo.19726149.
