Ray-tracing image simulations of transparent objects with complex shape and inhomogeneous refractive index

Armin Kalita1, Bryan Oller1, Thomas Paula2, Alexander Bußmann2,3, Sebastian Marte1, Gabriel Blaj4, Raymond G. Sierra5, Sandra Mous5, Kirk A. Larsen5 et al.

Xinxin Cheng5, Matt J. Hayes5, Kelsey Banta5, Stella Lisova5, Peter Nguyen5, Serge A. H. Guillet5, Divya Thanasekaran5, Silke Nelson5, Mengning Liang5, Stefan Adami2, Nikolaus A. Adams2,3, and Claudiu A. Stan1,*

  • *Contact author: claudiu.stan@rutgers.edu
PDF

Phys. Rev. Fluids 11, 044908 – Published 20 April, 2026

DOI: https://doi.org/10.1103/cbtx-sfc4

Abstract

Optical images of transparent three-dimensional objects can be different from a replica of the object's cross section in the image plane due to refraction at the surface or in the body of the object. Simulations of the object's image are thus needed for the visualization and validation of physical models. We report ray-tracing image simulations that achieved high physical fidelity, reproducing optical behaviors and image features not rendered in previous studies. We replicated brightfield microscopy images of drops with complex shapes and images of pressure and shock waves traveling inside them. For high physical fidelity, the simulations must replicate the spatial and angular distribution of illumination rays, and both the experiment and the simulation must be designed for accurate optical modeling. The simulations are highly sensitive to the properties of the drops and can be used to diagnose and refine fluid dynamics models. The simulated images can also be optimized to extract multiple 3D properties from experimental images. Compared to specialized single-shot 3D imaging methods, this approach has the advantage that it preserves the experimental simplicity, the high resolution, and the visual interpretability characteristic to basic optical imaging. The techniques introduced here are directly applicable to optical microscopy, so they can be used in other fields, such as microfluidics and biology, to expand the type and the accuracy of three-dimensional information that can be extracted from basic optical images.
