Rupture dynamics of dense granular films: From liquidlike bursting to solidlike fracturing
Phys. Rev. Fluids 11, 094301 – Published 8 September, 2026
DOI: https://doi.org/10.1103/c9bz-d2yg
Abstract
We investigate the bursting dynamics of dense granular films punctured at imposed controlled liquid pressure. Using high-speed imaging, we reveal a two-stage opening process. At early times, the hole expands in a liquidlike manner with a nearly circular shape and a constant velocity, though significantly lower than the Taylor-Culick speed. This velocity is modeled by a balance between surface tension and effective surface viscosity, which depends on particle size and liquid depression. We show that as liquid pressure decreases, the initial opening slows down progressively until it ultimately reaches a jamming state. As the opening progresses, the film undergoes a transition to a solidlike regime, where faceting occurs due to fracture propagation within the granular skeleton. We show that the characteristic fracture size follows a scaling, consistent with a balance between surface energy release and viscous dissipation induced by liquid redistribution within the 2D granular network. These findings advance our understanding of the mechanics of granular films and their transition between fluidlike and solidlike behaviors.
Physics Subject Headings (PhySH)
Article Text
References (32)
- J. Bico, Cracks in bursting soap films, J. Fluid Mech. 778, 1 (2015).
- I. Cantat, S. Cohen-Addad, F. Elias, F. Graner, R. Höhler, O. Pitois, F. Rouyer, and A. Saint-Jalmes, Liquids Foams: Structure and Dynamic (Oxford University Press, Oxford, 2013).
- G. Debregeas, P.-G. de Gennes, and F. Brochard-Wyart, The life and death of bare viscous bubbles, Science 279, 1704 (1998).
- M. P. Brenner, D. Gueyffier, On the bursting of viscous films, Phys. Fluids 11, 737 (1999).
- N. Savva and J. W. M. Bush, Viscous sheet retraction, J. Fluid Mech. 626, 211 (2009).
- P. C. Petit, M. Le Merrer, and A.-L. Biance, Holes and cracks in rigid foam films, J. Fluid Mech. 774, R3 (2015).
- M. De Corato, D. Tammaro, P. L. Maffettone, and N. Fueyo, Retraction of thin films coated by insoluble surfactants, J. Fluid Mech. 942, A55 (2022).
- J. Lu and C. M. Corvalan, Dynamical transitions during the collapse of inertial holes, Sci. Rep. 9, 14649 (2019).
- G. I. Taylor, The dynamics of thin sheets of fluid. III. Disintegration of fluid sheets, Proc. R. Soc. A 253, 313 (1959).
- F. E. C. Culick, Comments on a Ruptured Soap Film, J. Appl. Phys. 31, 1128 (1960).
- H. Lhuissier and E. Villermaux, Soap films burst like flapping flags, Phys. Rev. Lett. 103, 054501 (2009).
- W. R. McEntee and K. J. Mysels, Bursting of soap films. I. An experimental study, J. Phys. Chem. 73, 3018 (1969).
- P. Shah, E. Ward, S. Arora, and M. M. Driscoll, Rupture dynamics of flat colloidal films, Phys. Rev. Fluids 8, 024002 (2023).
- Y. Timounay, E. Lorenceau, and F. Rouyer, Opening and retraction of particulate soap films, Europhys. Lett. 111, 26001 (2015).
- Y. Timounay and F. Rouyer, Viscosity of particulate soap films: Approaching the jamming of 2D capillary suspensions, Soft Matter 13, 3449 (2017).
- N. Retailleau, Y. Khidas, and F. Rouyer, Pressure threshold for inhibition of dense granular film opening, RSC Adv. 13, 30905 (2023).
- G. Morris, M. R. Pursell, S. J. Neethling, and J. J. Cilliers, The effect of particle hydrophobicity, separation distance and packing patterns on the stability of a thin film, J. Colloid Interface Sci. 327, 138 (2008).
- J. Lalieu, A. Seguin, and G. Gauthier, Rheology of a 2D granular film, Soft Matter 19, 6838 (2023).
- D. Vella, P. Aussillous, and L. Mahadevan, Elasticity of an interfacial particle raft, Europhys. Lett. 68, 212 (2004).
- P. Cicuta and D. Vella, Granular character of particle rafts, Phys. Rev. Lett. 102, 138302 (2009).
- A. Varshney, A. Sane, S. Ghosh, and S. Bhattacharya, Amorphous to amorphous transition in particle rafts, Phys. Rev. E 86, 031402 (2012).
- D. Vella, H.-Young Kim, P. Aussillous, and L. Mahadevan, Dynamics of surfactant-driven fracture of particle rafts, Phys. Rev. Lett. 96, 178301 (2006).
- M. M. Bandi, T. Tallinen, and L. Mahadevan, Shock-driven jamming and periodic fracture of particulate rafts, Europhys. Lett. 96, 36008 (2011).
- C. Peco, W. Chen, Y. Liu, M. M. Bandi, J. E. Dolbow, and E. Fried, Influence of surface tension in the surfactant-driven fracture of closely-packed particulate monolayers, Soft Matter 13, 5832 (2017).
- K.-Î. Tô and S. R. Nagel, Rifts in rafts, Soft Matter 19, 905 (2023).
- K.-Î Tô, Cluster formation and relaxation in particle rafts under uniform radial expansion, Phys. Rev. E 108, 024801 (2023).
- K. J. Mysels and M. N. Jones, Direct measurement of the variation of double-layer repulsion with distance, Discuss. Faraday Soc. 42, 42 (1966).
- C. Planchette, E. Lorenceau, and A.-Laure Biance, Surface wave on a particle raft, Surface wave on a particle raft, Soft Matter 8, 2444 (2012).
- G. Gauthier, L. Claus, J. Lalieu, Y. Khidas, O. Pitois, A. Seguin, and F. Rouyer, Effective viscosity of granular soap films highlighted by the pinch-off process (unpublished).
- S. Moulinet and M. Adda-Bedia, Popping balloons: A case study of dynamical fragmentation, Phys. Rev. Lett. 115, 184301 (2015).
- B. P. Binks and S. O. Lumsdon, Effects of oil type and aqueous phase composition on oil–water mixtures containing particles of intermediate hydrophobicity, Phys. Chem. Chem. Phys. 2, 2959 (2000).
- E. Guyon, J.-P. Hulin, L. Petit, and C. D. Mitescu, Physical Hydrodynamics, 2nd ed. (Oxford University Press, Oxford,2015).
