Added-mass and added-moment-of-inertia tensors of porous fractal flocs

Lucja Stawikowska1, Samuel Briney2, Xiao Yu3, and S. Balachandar1,3,*

  • 1Department of Mechanical and Aerospace Engineering, University of Florida, Gainesville, Florida, USA
  • 2Corvid Technologies, Mooresville, North Carolina, USA
  • 3Engineering School of Sustainable Infrastructure and Environment, Gainesville, Florida, USA

  • *Contact author: bala1s@ufl.edu
PDF

Phys. Rev. Fluids 11, 094303 – Published 10 September, 2026

DOI: https://doi.org/10.1103/58rw-pvt4

Abstract

Fractal flocs are highly porous aggregates whose hydrodynamic response differs fundamentally from that of solid particles of comparable size and shape. In particular, the fluid trapped within the porous structure alters the effective added inertia and rotational coupling experienced by the aggregate, thereby influencing its translational and rotational dynamics in unsteady flows. In this work we investigate the added-mass and added-moment-of-inertia tensors of fractal flocs generated over a broad range of floc sizes and fractal dimensions using a binary-superposition-based computational framework. Large statistical ensembles are used to characterize both the mean behavior and the morphology-induced variability of the inertia tensors. The results show that the principal added-mass and added-moment-of-inertia coefficients exhibit systematic scaling with floc size and fractal morphology while displaying substantial deviations from equivalent solid ellipsoids. Despite significant geometric irregularity at the level of individual particles, the variability among different realizations decreases with increasing aggregate size, revealing an emergent self-averaging behavior for large flocs. Due to their highly anisotropic and porous structure, flocs with smaller fractal dimension exhibit substantially larger added-moment-of-inertia coefficients, which could influence their orientation dynamics in accelerating or turbulent environments. Based on these observations, reduced-order stochastic representations are developed to model the tensor statistics using a small number of physically meaningful parameters. The statistical framework developed here provides a foundation for incorporating morphology-dependent added-inertia effects into large-scale simulations of particle-laden and multiphase flows, including applications involving sediment transport, marine aggregates, aerosols, and industrial particulate systems.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (38)

  1. K. R. Dyer, Sediment processes in estuaries: Future research requirements, J. Geophys. Res.: Oceans 94, 14327 (1989).
  2. W. Lick, H. Huang, and R. Jepsen, Flocculation of fine-grained sediments due to differential settling, J. Geophys. Res.: Oceans 98, 10279 (1993).
  3. J. F. Zhang and Q. H. Zhang, Lattice Boltzmann simulation of the flocculation process of cohesive sediment due to differential settling, Cont. Shelf Res. 31, S94 (2011).
  4. B. Vowinckel, P. Zhao, L. Ye, A. J. Manning, T.-J. Hsu, E. Meiburg, and B. Bai, Physics of cohesive sediment flocculation and transport: State-of-the-art experimental and numerical techniques, in Sediment Transport-Recent Advances (IntechOpen, London, 2022), pp. 1–34.
  5. J. C. Winterwerp, A simple model for turbulence induced flocculation of cohesive sediment, J. Hydraul. Res. 36, 309 (1998).
  6. M. Yu, X. Yu, S. Balachandar, and A. J. Manning, Floc size distributions of cohesive sediment in homogeneous isotropic turbulence, Front. Earth Science 10, 815652 (2022).
  7. X. Yu, M. Yu, S. Balachandar, and A. J. Manning, Shielding effects of neighbor particles on flocculation dynamics of cohesive sediment, Phys. Fluids 37, 033369 (2025).
  8. K. Zhao, F. Pomes, B. Vowinckel, T.-J. Hsu, B. Bai, and E. Meiburg, Flocculation of suspended cohesive particles in homogeneous isotropic turbulence, J. Fluid Mech. 921, A17 (2021).
  9. V. Becker, E. Schlauch, M. Behr, and H. Briesen, Restructuring of colloidal aggregates in shear flows and limitations of the free-draining approximation, J. Colloid Interface Sci. 339, 362 (2009).
  10. M. Vlieghe, C. Frances, C. Coufort-Saudejaud, and A. Liné, Morphological properties of flocs under turbulent break-up and restructuring processes, AIChE J. 63, 3706 (2017).
  11. M. Yu, X. Yu, A. J. Mehta, A. J. Manning, F. Khan, and S. Balachandar, Persistent reshaping of cohesive sediment towards stable flocs by turbulence, Sci. Rep. 13, 1760 (2023).
  12. M. R. Maxey and J. J. Riley, Equation of motion for a small rigid sphere in a nonuniform flow, Phys. Fluids 26, 883 (1983).
  13. J. Happel and H. Brenner, Low Reynolds Number Hydrodynamics: With Special Applications to Particulate Media (Springer, Dordrecht, 1983).
  14. Hidetoshi Matsumoto, Y. Adachi, and K. Ooi, Studies on the drag coefficient of aggregates of colloidal particles, J. Colloid Interface Sci. 264, 82 (2003).
  15. C. Xu, D. Lee, and J. C. Winterwerp, Modelling the effects of multiple fractal dimensions on the flocculation and resuspension processes of cohesive sediment, Front. Mar. Sci. 8, 746630 (2021).
  16. B. Derjaguin and L. Landau, The theory of stability of highly charged lyophobic sols and coalescence of highly charged particles in electrolyte solutions, Acta Physicochim. URSS 14, 58 (1941).
  17. K. Kendall, The adhesion and surface energy of elastic solids, J. Phys. D: Appl. Phys. 4, 1186 (1971).
  18. S. Balachandar, A scaling analysis for point–particle approaches to turbulent multiphase flows, Int. J. Multiphase Flow 35, 801 (2009).
  19. Y. Ling, M. Parmar, and S. Balachandar, A scaling analysis of added-mass and history forces and their coupling in dispersed multiphase flows, Int. J. Multiphase Flow 57, 102 (2013).
  20. J. F. Brady and G. Bossis, Stokesian dynamics, Annu. Rev. Fluid Mech. 20, 111 (1988).
  21. M. Wang and J. F. Brady, Spectral Ewald acceleration of Stokesian dynamics for polydisperse suspensions, J. Comput. Phys. 306, 443 (2016).
  22. A. V. Filippov, Drag and torque on clusters of N arbitrary spheres at low Reynolds number, J. Colloid Interface Sci. 229, 184 (2000).
  23. J. Kim and S. Lee, Modeling drag force acting on the individual particles in low Reynolds number flow, Powder Technol. 261, 22 (2014).
  24. S. Briney, G. Akiki, F. M. Najjar, J. A. K. Horwitz, and S. Balachandar, Accurate models of the added mass force of a uniform random distribution of spherical particles or bubbles, J. Fluid Mech. 1002, A21 (2025).
  25. R. A. Helfinstine and C. Dalton, Unsteady potential flow past a group of spheres, Comput. Fluids 2, 99 (1974).
  26. A. S. Sangani, D. Z. Zhang, and A. Prosperetti, The added mass, Basset, and viscous drag coefficients in nondilute bubbly liquids undergoing small-amplitude oscillatory motion, Phys. Fluids A 3, 2955 (1991).
  27. L. M. Milne-Thompson, Theoretical Hydronamics, 4th ed. (Macmillan Company, New York, 1960).
  28. C. Béguin, E. Pelletier, and S. Étienne, Void fraction influence on added mass in a bubbly flow, Eur. J. Mech. B Fluids 56, 28 (2016).
  29. C. Béguin, S. Étienne, and M. J. Pettigrew, Effect of dispersed phase fraction on the drag coefficient of a droplet or a bubble in an idealized two-phase flow, Eur. J. Mech. B Fluids 65, 339 (2017).
  30. N. Zuber, On the dispersed two-phase flow in the laminar flow regime, Chem. Eng. Sci. 19, 897 (1964).
  31. X. Cai and G. B. Wallis, A more general cell model for added mass in two-phase flow, Chem. Eng. Sci. 49, 1631 (1994).
  32. S. Zoghlami, C. Béguin, A. Teyssedou, D. Scott, L. Bornard, and S. Etienne, Bubble cloud configuration effect on the added mass, Phys. Fluids 33, 053304 (2021).
  33. C. E. Brennen, A review of added mass and fluid inertial forces, Technical report, Naval Civil Engineering Laboratory, Port Hueneme, CA (1982).
  34. J. N. Newman, Marine Hydrodynamics (MIT Press, Cambridge, MA, 2018).
  35. J. Morán, A. Fuentes, F. Liu, and J. Yon, FracVAL: An improved tunable algorithm of cluster–cluster aggregation for generation of fractal structures formed by polydisperse primary particles, Comput. Phys. Commun. 239, 225 (2019).
  36. S. Balachandar, Fundamentals of Dispersed Multiphase Flows (Cambridge University Press, New York, 2024).
  37. S. Kim and S. J. Karrila, Microhydrodynamics: Principles and Selected Applications (Butterworth-Heinemann, 2013).
  38. D. C. Haworth and S. B. Pope, A generalized Langevin model for turbulent flows, Phys. Fluids 29, 387 (1986).
