Moment gas kinetic flux solver for simulation of flows from continuum regime to rarefied regime

Zhenyu Yuan (袁震宇)1 and Chang Shu (舒昌)2,*

  • *Contact author: mpeshuc@nus.edu.sg
PDF

Phys. Rev. Fluids 11, 063401 – Published 22 June, 2026

DOI: https://doi.org/10.1103/2grk-9fqf

Abstract

This paper proposes the moment gas kinetic flux solver (MGKFS) for the simulation of flows from a continuum regime to a rarefied regime. Its fundamental innovation lies in the dual-flux strategy, which extends the conventional gas kinetic flux solver (GKFS) paradigm by directly calculating numerical fluxes not only for the conservation equations (mass, momentum, and energy) but also for the high-order moment equations (stress and heat flux) at cell interfaces. Thus, MGKFS effectively overcomes the critical limitation identified in the Grad-13-based GKFS (G13-GKFS). G13-GKFS locally interpolates stress and heat flux at cell centers from their values at cell interfaces. This approach neglects their global evolution equations, leading to insufficient global accuracy. MGKFS directly captures the evolution of these high-order moments with flux reconstruction from the local solution of the Boltzmann equation at the cell interface. Numerical validations demonstrate that MGKFS significantly outperforms G13-GKFS, achieving superior accuracy. This improvement is particularly notable in boundary layers, where global fidelity is essential.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (49)

  1. Z. Yuan, W. Zhao, Z. Jiang, W. Chen, and R. K. Agarwal, Modified nonlinear coupled constitutive relations model for hypersonic nonequilibrium flows, J. Thermophys. Heat Tr. 34, 848 (2020).
  2. Z. Jiang, W. Zhao, Z. Yuan, W. Chen, and R. Myong, Computation of hypersonic flows over flying configurations using a nonlinear constitutive model, AIAA J. 57, 5252 (2019).
  3. Y. Zhang, S. Dou, J. Qi, X. Xu, J. Qiu, and Z. Wei, Experimental study on slip flow of nitrogen through microchannels at atmospheric pressure, Microfluid. Nanofluid. 27, 7 (2023).
  4. M. Akbari and M. Ghasemi, A novel kinetic-based slip velocity boundary condition suitable for compressible gas flows in micro-/nanochannels, Acta Mech. 229, 4471 (2018).
  5. S. Varoutis, D. Valougeorgis, O. Sazhin, and F. Sharipov, Rarefied gas flow through short tubes into vacuum, J. Vac. Sci. Technol. A 26, 228 (2008).
  6. O. Sazhin, Rarefied gas flow into vacuum through a channel with sudden contraction or expansion, Microfluid. Nanofluid. 24, 76 (2020).
  7. G. A. Bird, Molecular Gas Dynamics and the Direct Simulation of Gas Flows (Clarendon Press, Oxford, 1994).
  8. Z. Yuan, W. Zhao, and W. Chen, Numerical study of heat flux reduction mechanism of the counterflowing jet in rarefied flows, in AIP Conference Proceedings (AIP Publishing, Glasgow, UK, 2019), p. 030003.
  9. M. H. Gorji and P. Jenny, A Fokker–Planck based kinetic model for diatomic rarefied gas flows, Phys. Fluids 25, 062002 (2013).
  10. F. Fei, Z. Liu, J. Zhang, and C. Zheng, A particle Fokker-Planck algorithm with multiscale temporal discretization for rarefied and continuum gas flows, Commun. Comput. Phys. 22, 338 (2017).
  11. C. Liu, Y. Zhu, and K. Xu, Unified gas-kinetic wave-particle methods I: Continuum and rarefied gas flow, J. Comput. Phys. 401, 108977 (2020).
  12. Y. Zhu, C. Liu, C. Zhong, and K. Xu, Unified gas-kinetic wave-particle methods. II. Multiscale simulation on unstructured mesh, Phys. Fluids 31, 067105 (2019).
  13. S. Liu, C. Zhong, and M. Fang, Simplified unified wave-particle method with quantified model-competition mechanism for numerical calculation of multiscale flows, Phys. Rev. E 102, 013304 (2020).
  14. L. Yang, C. Shu, J. Wu, and Y. Wang, Numerical simulation of flows from free molecular regime to continuum regime by a DVM with streaming and collision processes, J. Comput. Phys. 306, 291 (2016).
  15. L. Yang, C. Shu, W. Yang, Z. Chen, and H. Dong, An improved discrete velocity method (DVM) for efficient simulation of flows in all flow regimes, Phys. Fluids 30, 062005 (2018).
  16. X. Gu and D. Emerson, A high-order moment approach for capturing non-equilibrium phenomena in the transition regime, J. Fluid Mech. 636, 177 (2009).
  17. A. Rana, M. Torrilhon, and H. Struchtrup, A robust numerical method for the R13 equations of rarefied gas dynamics: Application to lid driven cavity, J. Comput. Phys. 236, 169 (2013).
  18. A. Rana, A. Mohammadzadeh, and H. Struchtrup, A numerical study of the heat transfer through a rarefied gas confined in a microcavity, Continuum Mech. Therm. 27, 433 (2015).
  19. K. Xu and J. Huang, A unified gas-kinetic scheme for continuum and rarefied flows, J. Comput. Phys. 229, 7747 (2010).
  20. S. Liu, P. Yu, K. Xu, and C. Zhong, Unified gas-kinetic scheme for diatomic molecular simulations in all flow regimes, J. Comput. Phys. 259, 96 (2014).
  21. W. Su, L. Zhu, and L. Wu, Fast convergence and asymptotic preserving of the general synthetic iterative scheme, SIAM J. Sci. Comput. 42, B1517 (2020).
  22. J. Zeng, R. Yuan, Y. Zhang, Q. Li, and L. Wu, General synthetic iterative scheme for polyatomic rarefied gas flows, Computers & Fluids 265, 105998 (2023).
  23. Z. Guo, R. Wang, and K. Xu, Discrete unified gas kinetic scheme for all Knudsen number flows. II. Thermal compressible case, Phys. Rev. E 91, 033313 (2015).
  24. Z. Xin, Y. Zhang, C. Zhang, and Z. Guo, Multiscale discrete Maxwell boundary condition for the discrete unified gas kinetic scheme for all Knudsen number flows, Phys. Rev. E 112, 045316 (2025).
  25. Z. Liu, L. Yang, C. Shu, S. Chen, M. Wan, W. Liu, and Z. Yuan, Explicit formulations of G13-based gas kinetic flux solver (G13-GKFS) for simulation of continuum and rarefied flows, Phys. Fluids 33, 037133 (2021).
  26. Z. Liu, C. Shu, S. Chen, W. Liu, Z. Yuan, and L. Yang, Development of explicit formulations of G45-based gas kinetic scheme for simulation of continuum and rarefied flows, Phys. Rev. E 105, 045302 (2022).
  27. Z. Yuan, C. Shu, and Z. Liu, Grad's distribution functions-based gas kinetic scheme for simulation of flows beyond Navier–Stokes level, Phys. Fluids 33, 122007 (2021).
  28. Z. Liu, C. Shu, S. Chen, L. Yang, M. Wan, and W. Liu, A novel solver for simulation of flows from continuum regime to rarefied regime at moderate Knudsen number, J. Comput. Phys. 415, 109548 (2020).
  29. Z. Yuan, L. Yang, C. Shu, K. Jiang, and Z. Chen, Complete third-order polynomial expansion-based gas kinetic flux solver for flows from continuum regime to rarefied regime, Phys. Fluids 35, 122011 (2023).
  30. Z. Yuan, Z. Chen, C. Shu, Y. Liu, and Z. Zhang, A novel construction of distribution function through second-order polynomial approximation in terms of particle mass, momentum and energy, Adv. Appl. Math. Mech. 16, 738 (2024).
  31. Y. Liu, L. Yang, C. Shu, Z. Zhang, and Z. Yuan, An implicit high-order radial basis function-based differential quadrature-finite volume method on unstructured grids to simulate incompressible flows with heat transfer, J. Comput. Phys. 467, 111461 (2022).
  32. Z. Yuan, L. Yang, C. Shu, Z. Liu, and W. Liu, A novel gas kinetic flux solver for simulation of continuum and slip flows, Int. J. Numer. Meth. Fl 93, 2863 (2021).
  33. Z. Yuan, W. Zhao, Z. Jiang, and W. Chen, Numerical simulation of hypersonic reaction flows with nonlinear coupled constitutive relations, Aerosp. Sci. Technol. 112, 106591 (2021).
  34. S. Zeng, Z. Yuan, W. Zhao, and W. Chen, Numerical simulation of hypersonic thermochemical nonequilibrium flows using nonlinear coupled constitutive relations, Chin. J. Aeronaut. 36, 63 (2023).
  35. S. Zeng, J. Yang, W. Zhao, Z. Yuan, G. Fan, and W. Chen, Nonlinear coupled constitutive relations for hypersonic reacting flows with thermal nonequilibrium effect, Phys. Fluids 37, 016116 (2025).
  36. Z. Yuan, K. Jiang, S. Zeng, Z. Jiang, and W. Chen, Topology of Nonlinear Coupled Constitutive Relations and Comparison of Different Iterative Methods, in International Conference on Computational & Experimental Engineering and Sciences (Springer, 2024), pp. 389–406.
  37. Z. Yuan, Z. Jiang, W. Zhao, and W. Chen, Analysis of gas flow over a cylinder at all Knudsen numbers based on non-Newtonian constitutive models, Int. J. Mod. Phys. B 34, 2040076 (2020).
  38. G. Golub and J. Welsch, Calculation of Gauss quadrature rules, Math. Comput. 23, 221 (1969).
  39. B. Shizgal, A Gaussian quadrature procedure for use in the solution of the Boltzmann equation and related problems, J. Comput. Phys. 41, 309 (1981).
  40. H. Struchtrup and M. Torrilhon, Regularization of Grad's 13 moment equations: Derivation and linear analysis, Phys. Fluids 15, 2668 (2003).
  41. C. Cercignani and M. Lampis, Kinetic models for gas-surface interactions, Transport Theor. Stat. 1, 101 (1971).
  42. Z. Li, W. Hu, A. Peng, J. Wu, and C. Lee, Gas-kinetic unified algorithm for plane external force-driven flows covering all flow regimes by modeling of Boltzmann equation, Int. J. Numer. Meth. Fl 92, 922 (2020).
  43. X. Gu and D. Emerson, A computational strategy for the regularized 13 moment equations with enhanced wall-boundary conditions, J. Comput. Phys. 225, 263 (2007).
  44. M. Torrilhon and H. Struchtrup, Boundary conditions for regularized 13-moment-equations for micro-channel-flows, J. Comput. Phys. 227, 1982 (2008).
  45. W. Liu, Y. Liu, L. Yang, Z. Liu, Z. Yuan, C. Shu, and C. Teo, Coupling improved discrete velocity method and G13-based gas kinetic flux solver: A hybrid method and its application for non-equilibrium flows, Phys. Fluids 33, 092007 (2021).
  46. Z. Yuan, L. Yang, C. Shu, K. Jiang, and L. Zhang, A variant of improved discrete velocity method for efficient simulation of flows in entire Knudsen number regimes, Phys. Fluids 36, 022018 (2024).
  47. U. Ghia, K. N. Ghia, and C. T. Shin, High-Re solutions for incompressible flow using the Navier-Stokes equations and a multigrid method, J. Comput. Phys. 48, 387 (1982).
  48. W. Yang, X. Gu, D. R. Emerson, Y. Zhang, and S. Tang, Modelling thermally induced non-equilibrium gas flows by coupling kinetic and extended thermodynamic methods, Entropy 21, 816 (2019).
  49. Z. Yuan, Z. Jiang, W. Zhao, and W. Chen, Multiple temperature model of nonlinear coupled constitutive relations for hypersonic diatomic gas flows, AIP Advances 10, 055023 (2020).

Outline

Information

Phys. Rev. Fluids 11, 063401– Published 22 June, 2026
  • Received 30 August 2025
  • Accepted 17 April 2026
Crossmark - Check for updates button

©2026 American Physical Society
