When JIMWLK evolution really matters: The example of incoherent diffraction

T. Lappi1,2,* and D. N. Triantafyllopoulos3,†

  • *Contact author: tuomas.v.v.lappi@jyu.fi
  • †Contact author: trianta@ectstar.eu
PDF

Phys. Rev. D 114, 014036 – Published 17 July, 2026

DOI: https://doi.org/10.1103/m4h9-s6y6

Abstract

We consider high energy scattering in the effective theory of the color glass condensate. The most convenient degrees of freedom are Wilson lines encoding multiple gluon exchanges, whose evolution with energy follows the JIMWLK equation. Instead of using the latter, very often one resorts to a Gaussian approximation (GA), which is known to be remarkably accurate in describing a wide class of multigluon correlators whose expansion in the weak scattering limit starts with an exchange of only two gluons. Here we demonstrate, both analytically and numerically, that such an approximation is not valid for correlators which start with an exchange of four gluons. As a main example, we focus on incoherent diffraction in photon-nucleus collisions and we show that the discrepancy between the JIMWLK and the GA results is driven by weak scattering and further persists in the regime where unitarity corrections begin to become important. The JIMWLK calculation leads to cross sections which are systematically larger in all kinematic regimes of interest.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (68)

  1. J. Jalilian-Marian, A. Kovner, A. Leonidov, and H. Weigert, The BFKL equation from the Wilson renormalization group, Nucl. Phys. B504, 415 (1997).
  2. J. Jalilian-Marian, A. Kovner, A. Leonidov, and H. Weigert, The Wilson renormalization group for low x physics: Towards the high density regime, Phys. Rev. D 59, 014014 (1998).
  3. H. Weigert, Unitarity at small Bjorken x, Nucl. Phys. A703, 823 (2002).
  4. E. Iancu, A. Leonidov, and L. D. McLerran, Nonlinear gluon evolution in the color glass condensate. 1., Nucl. Phys. A692, 583 (2001).
  5. E. Iancu, A. Leonidov, and L. D. McLerran, The renormalization group equation for the color glass condensate, Phys. Lett. B 510, 133 (2001).
  6. I. Balitsky, Operator expansion for high-energy scattering, Nucl. Phys. B463, 99 (1996).
  7. I. Balitsky, High-energy QCD and Wilson lines, arXiv:hep-ph/0101042.
  8. Y. V. Kovchegov, Small x F(2) structure function of a nucleus including multiple pomeron exchanges, Phys. Rev. D 60, 034008 (1999).
  9. Y. V. Kovchegov, Unitarization of the BFKL pomeron on a nucleus, Phys. Rev. D 61, 074018 (2000).
  10. E. Iancu, K. Itakura, and L. McLerran, A Gaussian effective theory for gluon saturation, Nucl. Phys. A724, 181 (2003).
  11. Y. V. Kovchegov, J. Kuokkanen, K. Rummukainen, and H. Weigert, Subleading-N(c) corrections in non-linear small-x evolution, Nucl. Phys. A823, 47 (2009).
  12. E. Iancu and D. N. Triantafyllopoulos, Higher-point correlations from the JIMWLK evolution, J. High Energy Phys. 11 (2011) 105.
  13. E. Iancu and D. N. Triantafyllopoulos, JIMWLK evolution in the Gaussian approximation, J. High Energy Phys. 04 (2012) 025.
  14. A. Dumitru, J. Jalilian-Marian, T. Lappi, B. Schenke, and R. Venugopalan, Renormalization group evolution of multi-gluon correlators in high energy QCD, Phys. Lett. B 706, 219 (2011).
  15. L. D. McLerran and R. Venugopalan, Computing quark and gluon distribution functions for very large nuclei, Phys. Rev. D 49, 2233 (1994).
  16. L. D. McLerran and R. Venugopalan, Gluon distribution functions for very large nuclei at small transverse momentum, Phys. Rev. D 49, 3352 (1994).
  17. L. D. McLerran and R. Venugopalan, Green’s functions in the color field of a large nucleus, Phys. Rev. D 50, 2225 (1994).
  18. J. P. Blaizot, F. Gelis, and R. Venugopalan, High-energy pA collisions in the color glass condensate approach. 2. Quark production, Nucl. Phys. A743, 57 (2004).
  19. H. Weigert, Evolution at small x(bj): The color glass condensate, Prog. Part. Nucl. Phys. 55, 461 (2005).
  20. F. Dominguez, C. Marquet, and B. Wu, On multiple scatterings of mesons in hot and cold QCD matter, Nucl. Phys. A823, 99 (2009).
  21. F. Dominguez, C. Marquet, B.-W. Xiao, and F. Yuan, Universality of unintegrated gluon distributions at small x, Phys. Rev. D 83, 105005 (2011).
  22. T. Lappi and H. Mantysaari, Forward dihadron correlations in deuteron-gold collisions with the Gaussian approximation of JIMWLK, Nucl. Phys. A908, 51 (2013).
  23. T. Lappi, H. Mäntysaari, and A. Ramnath, Next-to-leading order Balitsky-Kovchegov equation beyond large Nc, Phys. Rev. D 102, 074027 (2020).
  24. H. Mäntysaari, N. Mueller, F. Salazar, and B. Schenke, Multigluon correlations and evidence of saturation from dijet measurements at an Electron-Ion Collider, Phys. Rev. Lett. 124, 112301 (2020).
  25. C. Marquet, E. Petreska, and C. Roiesnel, Transverse-momentum-dependent gluon distributions from JIMWLK evolution, J. High Energy Phys. 10 (2016) 065.
  26. S. Cali, K. Cichy, P. Korcyl, P. Kotko, K. Kutak, and C. Marquet, On systematic effects in the numerical solutions of the JIMWLK equation, Eur. Phys. J. C 81, 663 (2021).
  27. T. Lappi, Gluon spectrum in the glasma from JIMWLK evolution, Phys. Lett. B 703, 325 (2011).
  28. S. Schlichting and B. Schenke, The shape of the proton at high energies, Phys. Lett. B 739, 313 (2014).
  29. B. Schenke, S. Schlichting, and P. Singh, Rapidity dependence of initial state geometry and momentum correlations in p+Pb collisions, Phys. Rev. D 105, 094023 (2022).
  30. H. Mäntysaari and P. Singh, Energy dependence of the deformed nuclear structure at small-x, Eur. Phys. J. C 85, 1449 (2025).
  31. H. Mäntysaari, N. Mueller, and B. Schenke, Diffractive dijet production and Wigner distributions from the color glass condensate, Phys. Rev. D 99, 074004 (2019).
  32. T. Lappi, B. Schenke, S. Schlichting, and R. Venugopalan, Tracing the origin of azimuthal gluon correlations in the color glass condensate, J. High Energy Phys. 01 (2016) 061.
  33. E. A. Kuraev, L. N. Lipatov, and V. S. Fadin, The pomeranchuk singularity in nonAbelian gauge theories, Sov. Phys. JETP 45 (1977) 199.
  34. I. I. Balitsky and L. N. Lipatov, The pomeranchuk singularity in quantum chromodynamics, Sov. J. Nucl. Phys. 28 (1978) 822.
  35. S. Demirci, T. Lappi, and S. Schlichting, Proton hot spots and exclusive vector meson production, Phys. Rev. D 106, 074025 (2022).
  36. A. H. Mueller, Soft gluons in the infinite momentum wave function and the BFKL pomeron, Nucl. Phys. B415, 373 (1994).
  37. J. Jalilian-Marian and Y. V. Kovchegov, Inclusive two-gluon and valence quark-gluon production in DIS and pA, Phys. Rev. D 70, 114017 (2004); 71, 079901(E) (2005).
  38. J.-P. Blaizot, E. Iancu, and H. Weigert, Nonlinear gluon evolution in path integral form, Nucl. Phys. A713, 441 (2003).
  39. K. Rummukainen and H. Weigert, Universal features of JIMWLK and BK evolution at small x, Nucl. Phys. A739, 183 (2004).
  40. T. Lappi and H. Mäntysaari, On the running coupling in the JIMWLK equation, Eur. Phys. J. C 73, 2307 (2013).
  41. T. Lappi, A. Ramnath, K. Rummukainen, and H. Weigert, JIMWLK evolution of the odderon, Phys. Rev. D 94, 054014 (2016).
  42. M. Alvioli, G. Soyez, and D. N. Triantafyllopoulos, Testing the Gaussian approximation to the JIMWLK equation, Phys. Rev. D 87, 014016 (2013).
  43. C. Marquet and H. Weigert, New observables to test the color glass condensate beyond the large- Nc limit, Nucl. Phys. A843, 68 (2010).
  44. B. Rodriguez-Aguilar, D. N. Triantafyllopoulos, and S. Y. Wei, Incoherent diffractive dijet production in electron DIS off nuclei at high energy, Phys. Rev. D 107, 114007 (2023).
  45. B. Rodriguez-Aguilar, D. N. Triantafyllopoulos, and S. Y. Wei, Incoherent diffractive production of jets in electron DIS off nuclei at high energy, Phys. Rev. D 110, 074018 (2024).
  46. T. Lappi and H. Mantysaari, Incoherent diffractive J/Psi-production in high energy nuclear DIS, Phys. Rev. C 83, 065202 (2011).
  47. H. Mäntysaari and B. Schenke, Evidence of strong proton shape fluctuations from incoherent diffraction, Phys. Rev. Lett. 117, 052301 (2016).
  48. E. Iancu and D. N. Triantafyllopoulos, A Langevin equation for high energy evolution with pomeron loops, Nucl. Phys. A756, 419 (2005).
  49. E. Iancu and D. N. Triantafyllopoulos, Non-linear QCD evolution with improved triple-pomeron vertices, Phys. Lett. B 610, 253 (2005).
  50. A. Kovner and M. Lublinsky, In pursuit of pomeron loops: The JIMWLK equation and the Wess-Zumino term, Phys. Rev. D 71, 085004 (2005).
  51. Y. Hatta, E. Iancu, C. Marquet, G. Soyez, and D. N. Triantafyllopoulos, Diffusive scaling and the high-energy limit of deep inelastic scattering in QCD at large N(c), Nucl. Phys. A773, 95 (2006).
  52. A. Bzdak and K. Dusling, Probing proton fluctuations with asymmetric rapidity correlations, Phys. Rev. C 93, 031901 (2016).
  53. L. McLerran and P. Tribedy, Intrinsic fluctuations of the proton saturation momentum scale in high multiplicity p+p collisions, Nucl. Phys. A945, 216 (2016).
  54. A. D. Le, Rapidity gap distribution in diffractive dissociation: Predictions for future electron-ion colliders, Phys. Rev. D 104, 014014 (2021).
  55. A. D. Le, A. H. Mueller, and S. Munier, Analytical asymptotics for hard diffraction, Phys. Rev. D 104, 034026 (2021).
  56. T. Lappi, Wilson line correlator in the MV model: Relating the glasma to deep inelastic scattering, Eur. Phys. J. C 55, 285 (2008).
  57. D. N. Triantafyllopoulos, Pomeron loops in high energy QCD, Acta Phys. Pol. B 36, 3593 (2005).
  58. K. J. Golec-Biernat and M. Wusthoff, Saturation effects in deep inelastic scattering at low Q2 and its implications on diffraction, Phys. Rev. D 59, 014017 (1998).
  59. D. N. Triantafyllopoulos, The energy dependence of the saturation momentum from RG improved BFKL evolution, Nucl. Phys. B648, 293 (2003).
  60. H. Mäntysaari and B. Schenke, Probing subnucleon scale fluctuations in ultraperipheral heavy ion collisions, Phys. Lett. B 772, 832 (2017).
  61. T. Lappi and A. Ramnath, Unequal rapidity correlators in the dilute limit of the JIMWLK evolution, Phys. Rev. D 100, 054003 (2019).
  62. E. Iancu, A. H. Mueller, D. N. Triantafyllopoulos, and S. Y. Wei, Gluon dipole factorisation for diffractive dijets, J. High Energy Phys. 10 (2022) 103.
  63. E. Iancu, A. H. Mueller, D. N. Triantafyllopoulos, and S. Y. Wei, Probing gluon saturation via diffractive jets in ultra-peripheral nucleus-nucleus collisions, Eur. Phys. J. C 83, 1078 (2023).
  64. S. Hauksson, E. Iancu, A. H. Mueller, D. N. Triantafyllopoulos, and S. Y. Wei, TMD factorisation for diffractive jets in photon-nucleus interactions, J. High Energy Phys. 06 (2024) 180.
  65. K. Dusling, F. Gelis, T. Lappi, and R. Venugopalan, Long range two-particle rapidity correlations in A+ A collisions from high energy QCD evolution, Nucl. Phys. A836, 159 (2010).
  66. K. Dusling and R. Venugopalan, Comparison of the color glass condensate to dihadron correlations in proton-proton and proton-nucleus collisions, Phys. Rev. D 87, 094034 (2013).
  67. E. Iancu and D. N. Triantafyllopoulos, JIMWLK evolution for multi-particle production in Langevin form, J. High Energy Phys. 11 (2013) 067.
  68. https://arxiv.org/abs/2604.26123.
