Electrode plasma transport into the gap of high-current Z-pinch accelerators
Phys. Rev. Accel. Beams 29, 093301 – Published 1 September, 2026
DOI: https://doi.org/10.1103/prpw-f8lt
Abstract
In the pulsed-power accelerators that drive Z-pinch implosions, multi-MA currents rapidly heat the electrodes above the threshold for plasma formation. When these surface plasmas are transported into the transmission line gap, they shunt some portion of the driver current away from the load, referred to as “current loss.” In highly magnetized systems, current loss is well approximated by a Hall current proportional to the minimum plasma density in the gap and the electric field [N. Bennett, D. R. Welch, G. Laity, D. V. Rose, and M. E. Cuneo, Magnetized particle transport in multi-MA accelerators, Phys. Rev. Accel. Beams , 060401 (2021)]. This paper explores the mechanism that drives the initial plasma transport into the gap, which is difficult to isolate in large-scale power-flow simulations but is instrumental in seeding the current-loss mechanism. The stability and dynamics of an electron sheath emitted from a resistive cathode plasma in the presence of large magnetic fields are investigated using semianalytic theory and simulation. A dispersion analysis determines that the instability growth rate scales inversely to ion mass and magnetic field strength. This scaling is confirmed in kinetic models of an electron sheath and resistive plasma using the relativistic electromagnetic particle-in-cell code CHICAGO. The simulations are initiated with field magnitudes representative of the final feed of a Z-pinch driver and demonstrate that a resistive plasma instability grows on ns timescales, generating perturbed electric fields of sufficient strength to rapidly accelerate plasma ions into the gap. Although the resulting plasma density in the gap is 2 orders of magnitude below the surface density, it is sufficient to generate the published current losses.
Physics Subject Headings (PhySH)
Article Text
References (20)
- W. A. Stygar, M. E. Cuneo, D. I. Headley, H. C. Ives, R. J. Leeper, M. G. Mazarakis, C. L. Olson, J. L. Porter, T. C. Wagoner, and J. R. Woodworth, Architecture of petawatt-class z-pinch accelerators, Phys. Rev. ST Accel. Beams 10, 030401 (2007).
- D. H. McDaniel, M. G. Mazarakis, D. E. Bliss, J. M. Elizondo, H. C. Harjes, H. C. Ives, D. L. Kitterman, J. E. Maenchen, T. D. Pointon, S. E. Rosenthal, D. L. Smith, K. W. Struve, W. A. Stygar, E. A. Weinbrecht, D. L. Johnson, and J. P. Corely, in The ZR refurbishment project, Proceedings of the 5th International Conference on Dense Z-Pinches, edited by J. Davis (AIP, New York, 2002), p. 23.
- M. E. Savage et al., An overview of pulse compression and power flow in the upgraded Z pulsed power driver, in Proceedings of the 16th IEEE Pulsed Power and Plasma Science Conference, Albuquerque, NM (2007), p. 979.
- D. V. Rose, D. R. Welch, E. A. Madrid, C. L. Miller, R. E. Clark, W. A. Stygar, M. E. Savage, G. A. Rochau, J. E. Bailey, T. J. Nash, M. E. Sceiford, K. W. Struve, P. A. Corcoran, and B. A. Whitney, Three-dimensional electromagnetic model of the pulsed-power Z-pinch accelerator, Phys. Rev. ST Accel. Beams 13, 010402 (2010).
- I. Langmuir, The effect of space charge and residual gases on thermionic currents in high vacuum, Phys. Rev. 2, 450 (1913).
- D. V. Rose, E. M. Waisman, M. P. Desjarlais, M. E. Cuneo, B. T. Hutsel, D. R. Welch, N. Bennett, and G. R. Laity, Numerical simulations of enhanced ion current losses in the inner magnetically insulated transmission line of the Z accelerator, Phys. Rev. Accel. Beams 23, 080401 (2020).
- N. Bennett, D. R. Welch, G. Laity, D. V. Rose, and M. E. Cuneo, Magnetized particle transport in multi-MA accelerators, Phys. Rev. Accel. Beams 24, 060401 (2021).
- G. V. Vogman and J. H. Hammer, Two-fluid and kinetic transport physics of Kelvin–Helmholtz instabilities in nonuniform low-beta plasmas, Phys. Plasmas 28, 062103 (2021).
- C. Thoma, D. R. Welch, R. E. Clark, D. V. Rose, and I. E. Golovkin, Hybrid-PIC modeling of laser-plasma interactions and hot electron generation in gold hohlraum walls, Phys. Plasmas 24, 062707 (2017).
- J. Swegle and E. Ott, Instability of the Brillouin-flow equilibrium in magnetically insulated structures, Phys. Fluids 24, 1981 (1821).
- D. P. Chernin, Resistive wall effect on the stability of planar relativistic Brillouin flow, Phys. Fluids 25, 1342 (1982).
- C. L. Chang, T. M. Antonsen, Jr., E. Ott, and A. T. Drobot, Instabilities in magnetically insulated gaps with resistive electrode plasmas, Phys. Fluids 27, 2545 (1984).
- D. R. Welch, N. Bennett, T. C. Genoni, D. V. Rose, C. Thoma, C. Miller, and W. A. Stygar, Electrode contaminant plasma effects in -A pinch accelerators, Phys. Rev. Accel. Beams 22, 070401 (2019).
- D. V. Rose, T. C. Genoni, R. E. Clark, D. R. Welch, and W. A. Stygar, Electron flow stability in magnetically insulated vacuum transmission lines, Phys. Plasmas 18, 033108 (2011).
A shooting method reduces a boundary value problem to an initial value problem. For a given value of , imaginary is adjusted until satisfying the boundary conditions.
- S. I. Braginskii, Reviews of Plasma Physics, edited by M. A. Leontovich (Consultants Bureau, New York, 1965), Vol. 1, p. 205.
- R. C. Davidson, Physics of Non-Neutral Plasmas (Addison-Wesley, Redwood City CA, 1990).
- N. Bennett, D. R. Welch, K. Cochrane, K. Leung, C. Thoma, M. E. Cuneo, and G. Frye-Mason, Electrode plasma formation and melt in Z-pinch accelerators, Phys. Rev. Accel. Beams 24, 040401 (2023).
- D. R. Welch, N. Bennett, T. C. Genoni, C. Thoma, and D. V. Rose, Fast hybrid particle-in-cell technique for pulsed-power accelerators, Phys. Rev. Accel. Beams 23, 110401 (2020).
- R. Revolinsky, C. Swenson, N. Jordan, Y. Y. Lau, and R. Gilgenbach, On the two-dimensional Brillouin flow, Phys. Plasmas 31, 053109 (2024).
