Quasinormal modes in dispersive photonic time crystals

Calvin M. Hooper*, Ian R. Hooper, and Simon A. R. Horsley

  • *Contact author: ch1122@exeter.ac.uk
PDF

Phys. Rev. A 113, 043526 – Published 29 April, 2026

DOI: https://doi.org/10.1103/m5ww-n7ws

Abstract

Quasinormal modes characterize the transient response of static optical cavities. Here we introduce the notion of a Floquet quasinormal mode to describe transient responses in photonic time crystals. Contrasting their static counterparts, exceptional points associated with symmetry transitions are an inherent feature, as modes spontaneously and nonperturbatively lock their phase to the oscillations of the material. We further investigate the limiting behavior of the Floquet quasinormal modes in large cavities. Distinct nonperturbative behavior arises in time-modulated systems as increasingly large time-crystal cavities come closer to achieving the maximum gain predicted from a bulk wave number band gap.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (73)

  1. E. Noether, Invariante Variationsprobleme, Nachr. d. Ges. d. Wiss. zu Göttingen, Math.-Phys. Kl. 1918, 235 (1918).
  2. E. Galiffi, R. Tirole, S. Yin, H. Li, S. Vezzoli, P. A. Huidobro, M. G. Silveirinha, R. Sapienza, A. Alù, and J. B. Pendry, Photonics of time-varying media, Adv. Photon. 4, 014002 (2022).
  3. C. Caloz and Z.-L. Deck-Léger, Spacetime metamaterials—part II: Theory and applications, IEEE Trans. Antennas Propag. 68, 1583 (2020).
  4. A. Cartella, T. F. Nova, M. Fechner, R. Merlin, and A. Cavalleri, Parametric amplification of optical phonons, Proc. Natl. Acad. Sci. USA 115, 12148 (2018).
  5. G. Castaldi, C. Rizza, N. Engheta, and V. Galdi, Multiple actions of time-resolved short-pulsed metamaterials, Appl. Phys. Lett. 122, 021701 (2023).
  6. X. Zhu, H.-W. Wu, Y. Zhuo, Z. Liu, and J. Li, Effective medium for time-varying frequency-dispersive acoustic metamaterials, Phys. Rev. B 108, 104303 (2023).
  7. J. C. Serra, E. Galiffi, P. A. Huidobro, J. B. Pendry, and M. G. Silveirinha, Particle-hole instabilities in photonic time-varying systems, Opt. Mater. Express 14, 1459 (2024).
  8. J. B. Pendry, Air conditioning for photons, Opt. Mater. Express 14, 407 (2024).
  9. Z. Dong, X. Chen, and L. Yuan, Extremely narrow band in moiré photonic time crystal, Phys. Rev. Lett. 135, 033803 (2025).
  10. E. Lustig, Y. Sharabi, and M. Segev, Topological aspects of photonic time crystals, Optica 5, 1390 (2018).
  11. A. C. Harwood, S. Vezzoli, T. V. Raziman, C. Hooper, R. Tirole, F. Wu, S. A. Maier, J. B. Pendry, S. A. R. Horsley, and R. Sapienza, Space-time optical diffraction from synthetic motion, Nat. Commun. 16, 5147 (2025).
  12. M. M. Asgari, P. Garg, X. Wang, M. S. Mirmoosa, C. Rockstuhl, and V. Asadchy, Theory and applications of photonic time crystals: A tutorial, Adv. Opt. Photon. 16, 958 (2024).
  13. D. L. Sounas and A. Alù, Non-reciprocal photonics based on time modulation, Nat. Photon. 11, 774 (2017).
  14. E. Lustig, O. Segal, S. Saha, C. Fruhling, V. M. Shalaev, A. Boltasseva, and M. Segev, Photonic time-crystals—Fundamental concepts, Opt. Express 31, 9165 (2023).
  15. H. He, S. Zhang, J. Qi, F. Bo, and H. Li, Faraday rotation in nonreciprocal photonic time-crystals, Appl. Phys. Lett. 122, 051703 (2023).
  16. J. G. Gaxiola-Luna and P. Halevi, Growing fields in a temporal photonic (time) crystal with a square profile of the permittivity ε(t), Appl. Phys. Lett. 122, 011702 (2023).
  17. G. Trainiti, Y. Xia, J. Marconi, G. Cazzulani, A. Erturk, and M. Ruzzene, Time-periodic stiffness modulation in elastic metamaterials for selective wave filtering: Theory and experiment, Phys. Rev. Lett. 122, 124301 (2019).
  18. C. M. Hooper, J. R. Capers, I. R. Hooper, and S. A. R. Horsley, Symmetry-protected lossless modes in dispersive time-varying media, Phys. Rev. A 111, 033507 (2025).
  19. E. Galiffi, A. C. Harwood, S. Vezzoli, R. Tirole, A. Alù, and R. Sapienza, Optical coherent perfect absorption and amplification in a time-varying medium, Nat. Photon. 20, 163 (2026).
  20. E. Hendry, C. M. Hooper, W. P. Wardley, and S. A. R. Horsley, Effects due to generation of negative frequencies during temporal diffraction, arXiv:2507.03491.
  21. X. Wang, M. S. Mirmoosa, V. S. Asadchy, C. Rockstuhl, S. Fan, and S. A. Tretyakov, Metasurface-based realization of photonic time crystals, Sci. Adv. 9, eadg7541 (2023).
  22. A. Vertiz-Conde, I. Liberal, and J. E. Vázquez-Lozano, Dispersion effects in thermal emission from temporal metamaterials: High-frequency cutoffs, Opt. Lett. 50, 1097 (2025).
  23. J. E. Vázquez-Lozano and I. Liberal, Incandescent temporal metamaterials, Nat. Commun. 14, 4606 (2023).
  24. S. A. R. Horsley and J. B. Pendry, Quantum electrodynamics of time-varying gratings, Proc. Natl. Acad. Sci. USA 120, e2302652120 (2023).
  25. S. A. R. Horsley and J. B. Pendry, Traveling wave amplification in stationary gratings, Phys. Rev. Lett. 133, 156903 (2024).
  26. J. Park, K. Lee, R.-Y. Zhang, H.-C. Park, J.-W. Ryu, G. Y. Cho, M. Y. Lee, Z. Zhang, N. Park, W. Jeon, J. Shin, C. T. Chan, and B. Min, Spontaneous emission decay and excitation in photonic time crystals, Phys. Rev. Lett. 135, 133801 (2025).
  27. S. A. R. Horsley, E. Galiffi, and Y.-T. Wang, Eigenpulses of dispersive time-varying media, Phys. Rev. Lett. 130, 203803 (2023).
  28. A. Tomadin, S. M. Hornett, H. I. Wang, E. M. Alexeev, A. Candini, C. Coletti, D. Turchinovich, M. Kläui, M. Bonn, F. H. L. Koppens, E. Hendry, M. Polini, and K.-J. Tielrooij, The ultrafast dynamics and conductivity of photoexcited graphene at different Fermi energies, Sci. Adv. 4, eaar5313 (2018).
  29. H. Moussa, G. Xu, S. Yin, E. Galiffi, Y. Ra'di, and A. Alù, Observation of temporal reflection and broadband frequency translation at photonic time interfaces, Nat. Phys. 19, 863 (2023).
  30. X. Wang, P. Garg, M. S. Mirmoosa, A. G. Lamprianidis, C. Rockstuhl, and V. S. Asadchy, Expanding momentum bandgaps in photonic time crystals through resonances, Nat. Photon. 19, 149 (2025).
  31. M. G. Ozlu, V. Mkhitaryan, C. B. Fruhling, A. Boltasseva, and V. M. Shalaev, Floquet engineering of polaritonic amplification in dispersive photonic time crystals, Phys. Rev. Res. 7, 023214 (2025).
  32. H. Benisty, J.-J. Greffet, and P. Lalanne, Basics of resonators and cavities, in Introduction to Nanophotonics (Oxford University Press, Oxford, 2022), pp. 159–196.
  33. J. Ren, S. Franke, and S. Hughes, Quasinormal mode theories and applications in classical and quantum nanophotonics, in Advances in Near-Field Optics, edited by R. Gordon (Springer International Publishing, Cham, 2023), pp. 87–135.
  34. P. T. Kristensen and S. Hughes, Modes and mode volumes of leaky optical cavities and plasmonic nanoresonators, ACS Photon. 1, 2 (2014).
  35. S. Franke, S. Hughes, M. K. Dezfouli, P. T. Kristensen, K. Busch, A. Knorr, and M. Richter, Quantization of quasinormal modes for open cavities and plasmonic cavity quantum electrodynamics, Phys. Rev. Lett. 122, 213901 (2019).
  36. S. Franke, J. Ren, and S. Hughes, Quantized quasinormal-mode theory of coupled lossy and amplifying resonators, Phys. Rev. A 105, 023702 (2022).
  37. B. VanDrunen, J. Ren, S. Franke, and S. Hughes, Gain-compensated metal cavity modes and a million-fold improvement of Purcell factors, Optica Quantum 2, 85 (2024).
  38. Z. Zhang, F. Zhang, Z. Xu, Y. Hu, H. Bao, and H. Shen, Realizing exceptional points by Floquet dissipative couplings in thermal atoms, Phys. Rev. Lett. 133, 133601 (2024).
  39. J. Ren, S. Franke, and S. Hughes, Quasinormal modes, local density of states, and classical Purcell factors for coupled loss-gain resonators, Phys. Rev. X 11, 041020 (2021).
  40. J. Ren, S. Franke, and S. Hughes, Connecting classical and quantum mode theories for coupled lossy cavity resonators using quasinormal modes, ACS Photon. 9, 138 (2022).
  41. A. C. Valero, S. Gladyshev, D. Globosits, S. Rotter, E. A. Muljarov, and T. Weiss, Resonant states of structured photonic time crystals, arXiv:2506.01472.
  42. B. Vial and R. V. Craster, Quasinormal modes of Floquet media slabs, Phys. Rev. B 112, 214201 (2025).
  43. M. V. Keldysh, On the completeness of the eigenfunctions of some classes of non-selfadjoint linear operators, Russ. Math. Surv. 26, 15 (1971).
  44. M. Renardy and R. C. Rogers, Operator theory, in An Introduction to Partial Differential Equations, edited by J. E. Marsden, L. Sirovich, and S. S. Antman (Springer, New York, 2004), p. 228.
  45. L. Fan, J. Wang, L. T. Varghese, H. Shen, B. Niu, Y. Xuan, A. M. Weiner, and M. Qi, An all-silicon passive optical diode, Science 335, 447 (2012).
  46. I. R. Hooper, D. B. Phillips, and S. A. R. Horsley, Harnessing the frequency eigenchannels of ultrafast time-varying media, arXiv:2508.12753.
  47. X. Wen, X. Zhu, H. W. Wu, and J. Li, Realizing spatiotemporal effective media for acoustic metamaterials, Phys. Rev. B 104, L060304 (2021).
  48. X. Wen, X. Zhu, A. Fan, W. Y. Tam, J. Zhu, H. W. Wu, F. Lemoult, M. Fink, and J. Li, Unidirectional amplification with acoustic non-Hermitian space-time varying metamaterial, Commun. Phys. 5, 18 (2022).
  49. M. Malléjac and R. Fleury, Experimental realization of an active time-modulated airborne acoustic circulator at audible frequencies, J. Sound Vib. 618, 119246 (2025).
  50. W. C. Wong, G. Chaplain, and J. Li, Eigenmode-guided amplification via spatiotemporal active acoustic metamaterials, arXiv:2506.17687v2.
  51. M. Koukouraki, P. Petitjeans, A. Maurel, and V. Pagneux, Characterization of temporal aiming for water waves with an anisotropic metabathymetry, Phys. Rev. B 112, 214301 (2025).
  52. V. Bacot, M. Labousse, A. Eddi, M. Fink, and E. Fort, Time reversal and holography with spacetime transformations, Nat. Phys. 12, 972 (2016).
  53. A. L. Cullen, A travelling-wave parametric amplifier, Nature (London) 181, 332 (1958).
  54. P. K. Tien, Parametric amplification and frequency mixing in propagating circuits, J. Appl. Phys. 29, 1347 (1958).
  55. F. Hyde, Varactor-diode parametric amplifiers, Electron. Power 10, 197 (1964).
  56. C. M. Bender and S. Boettcher, Real spectra in non-Hermitian Hamiltonians having PT symmetry, Phys. Rev. Lett. 80, 5243 (1998).
  57. W. D. Heiss, Exceptional points of non-Hermitian operators, J. Phys. A: Math. Gen. 37, 2455 (2004).
  58. C. Sauvan, T. Wu, R. Zarouf, E. A. Muljarov, and P. Lalanne, Normalization, orthogonality, and completeness of quasinormal modes of open systems: The case of electromagnetism, Opt. Express 30, 6846 (2022).
  59. M. Lyubarov, Y. Lumer, A. Dikopoltsev, E. Lustig, Y. Sharabi, and M. Segev, Amplified emission and lasing in photonic time crystals, Science 377, 425 (2022).
  60. B. Dixon, C. M. Hooper, I. R. Hooper, and S. A. R. Horsley, Scattering in time-varying Drude-Lorentz models, J. Opt. 28, 035101 (2026).
  61. D. M. Solís and N. Engheta, Functional analysis of the polarization response in linear time-varying media: A generalization of the Kramers-Kronig relations, Phys. Rev. B 103, 144303 (2021).
  62. Y. Sun, S. Fan, and G. Hu, Formulation of dispersive and dissipative time-varying media as a Floquet matrix eigenproblem, Phys. Rev. Lett. 135, 156903 (2025).
  63. I. Kiorpelidis, F. K. Diakonos, G. Theocharis, and V. Pagneux, Transient amplification in stable Floquet media, Phys. Rev. B 110, 134315 (2024).
  64. Q.-h. Wang, 2×2PT-symmetric matrices and their applications, Philos. Trans. R. Soc. A 371, 20120045 (2013).
  65. C. M. Hooper, I. R. Hooper, and S. A. R. Horsley, Code repository (2026), doi:10.17605/OSF.IO/3V5EM.
  66. L. Qi, Some simple estimates for singular values of a matrix, Linear Algebra Appl. 56, 105 (1984).
  67. M. Carlsson and O. Rubin, A Hilbert-space variant of Geršgorin's circle theorem, Math. Nachr. 297, 3095 (2024).
  68. A. M. Ostrowski, Solution of Equations and Systems of Equations: Pure and Applied Mathematics: A Series of Monographs and Textbooks, edited by P. A. Smith and S. Eilenberg (Academic Press, New York, 1966), Vol. 9.
  69. C. Boyd and N. Snigireva, On the analyticity of the Fredholm determinant, Monatshefte Math. 190, 675 (2019).
  70. G. W. Hanson and A. B. Yakovlev, Introductory linear operator theory, in Operator Theory for Electromagnetics: An Introduction (Springer, New York, 2002), p. 129.
  71. J. Zweck, Y. Latushkin, and E. Gallo, A regularity condition under which integral operators with operator-valued kernels are trace class, Bol. Soc. Mat. Mex. 31, 38 (2025).
  72. S. Steinberg, Meromorphic families of compact operators, Arch. Ration. Mech. Anal. 31, 372 (1968).
  73. M. Ahues, A. Largillier, and B. Limaye, Spectral Computations for Bounded Operators, Applied Mathematics (Chapman & Hall/CRC, Philadelphia, 2001).
